HYBREX G1E Installation & Programming Manual

Hybrid ip telephone system isdn digital telephone system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
The Business Telephone Specialists
G1E/G1E+
Hybrid IP Telephone System
ISDN Digital Telephone System
Installation &
Programming
Manual
V 3.3.2

Advertisement

Table of Contents
loading

Related Manuals for HYBREX G1E

Summary of Contents for HYBREX G1E

  • Page 1 The Business Telephone Specialists G1E/G1E+ Hybrid IP Telephone System ISDN Digital Telephone System Installation & Programming Manual V 3.3.2...

  • Page 2: Notification

    Notification Notification is hereby given that Auto Telecom Company Ltd. reserves the right to modify, change, update or revise this document from time to time as required without the prior obligation to notify any person, company or organization. Further, Auto Telecom makes no warranty or representation, either express or implied, with respect to merchantability, or fitness of its products for a particular purpose.
  • Page 3 4. Use caution when installing or modifying telephone lines. The HYBREX G1E utilizes a 3-pin grounding power supply cord. This cord is not to be attached to any building surfaces. When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1.

  • Page 4: Table Of Contents

    ............................... 12 PTIONAL NTERFACE ARDS SYSTEM INSTALLATION - INTRODUCTION ......................13 G1E MAIN EQUIPMENT WITH MSC, VMC, 2 TKU’S & 2 STU’S INSTALLED............14 G1E+ MAIN EQUIPMENT..............................15 ..................................... 16 OCATION Choosing the Right Environment ............................16 Issue 3.3.2 /. April, 2011...
  • Page 5 INSTALL G1E+-RPC REMOTE PROGRAMMING CARD TO G1E+ MBU2 ............32 INSTALL G1E-TKU 4PORT CO LINE CARD ........................ 33 INSTALL G1E-SIU 3 BRA CARD ............................34 INSTALL G1E-ITU IP TRUNK UNIT 4/8 PORT (FOR G1E+ ONLY) ................. 35 INSTALL G1E-VIU 3 VOIP TRUNK CARD (OBSOLETE) ( FOR G1E) ..............36...
  • Page 6 ULTIPLE USIC ON ONNECTIONS RS232 P ..............................50 ONNECTION VMU SETUP..................................51 INTERNAL MUSIC ON HOLD SOURCE......................... 51 EXTERNAL MUSIC ON HOLD SOURCE – G1E......................51 ............................ 52 OWER N AND PERATIONAL ................................52 PERATIONAL ESTS SPECIAL IMMUNITY PROTECTION FOR SYSTEM AND TERMINALS..............52 ..............................
  • Page 7 PROGRAM 05-02-IP : SYSTEM TIMING PARAMETERS – 02 .................. 64 01. SLT D :............................. 64 IMEOUT 02. SLT I : ............................64 NTER IGIT IMEOUT 03. A – PSTN :......................... 64 EDIAL INGING LINES 04. SLT R :..............................64 ELEASE IGNAL 05.
  • Page 8 PROGRAM 05-08-IP : SYSTEM TIMING PARAMETERS – 08................... 76 01. R : ............................76 ETTING 02. DSS A :......................... 76 CCESS THER RUNK GROUP 03. SLT C : ..............................76 04. DISA T :..............................76 RANSFER ROUP 05. SLT P : ............................
  • Page 9 04. R ..................................88 ESERVED 05. DISA DTMF D : ..........................88 ETECT ELAY 06. CID D ..............................89 ELAY 07. R : ..................................89 ESERVED PROGRAM 05-15-IP : SYSTEM TIMING PARAMETERS – 15 .................. 90 01. VMU D : ............................90 TAMP ETHOD 02.
  • Page 10 PROGRAM 05-24-IP : SYSTEM TIMING PARAMETERS – 24................. 108 01. R :..................................108 ESERVED 02.R : ..................................108 ESERVED 03. R :..................................108 ESERVED 04. G1E M ..........................108 ONITOR YSTEM RACKING 05. R :..................................108 ESERVED 06. G1E M : ............................... 109...
  • Page 11 PROGRAM 11-IP : DATE AND TIME SETTING ......................118 PROGRAM 12-NN : SYSTEM ALARM CLOCK ......................118 PROGRAM 13-NN : PASSWORD........................... 119 PROGRAM 14-01-IP : SMDR SPECIFICATIONS ....................... 120 01. C :............................120 ALL DURATION START TIME 02. R : ............................120 ECORD NCOMING ALLS...
  • Page 12 04. S : ..............................139 TATION 05. A :................................139 CCESS AGING 06. R : ................................. 139 ECEIVE AGING 07. S : .............................. 139 ECURITY CODE STATUS 08. F : .............................. 139 ORCED ACCOUNT CODE PROGRAM 41-STN-IP : STATION SPECIFICATIONS....................140 01.
  • Page 13 PROGRAM 68-GP-IP : HUNT GROUP ASSIGNMENT – DAY ................. 162 PROGRAM 69-GP-IP : HUNT GROUP ASSIGNMENT – NIGHT & LUNCHTIME ..........163 PROGRAM 70-CD-IP : ISDN INTERFACE SPECIFICATIONS PROGRAM – G1E..........164 PROGRAM 71-CD-IP : CALLING LINE IDENTIFICATION PRESENTATION ..........165 PROGRAM 72-ST : ISDN CALLED PARTY EXTENSION NUMBER ASSIGNMENT.........
  • Page 14 PROGRAM 84-IP : HOME AREA CODE ........................173 PROGRAM 85-NN-IP : OVERLAY AREA CODE......................173 PROGRAM 86-NNN-IP : OFFICE CODE REDIAL PATTERN.................. 174 PROGRAM 87-CN-IP : ASSIGN DOORPHONE FOR KEY CARD ................176 PROGRAM 88-DP : REGISTER KEY CARD........................ 176 PROGRAM 89-CN-IP : DELETE KEY CARD ......................
  • Page 15 VOICE MAIL INTEGRATION ............................188 PROGRAMMING OPERATIONS ........................... 189 ACD-1 OPERATION................................189 DISA AND AUTO ATTENDANT OPERATION ......................191 INSTALLING ACP’S ................................. 194 SETTING UP DUET RING DETECT ..........................195 PC UPGRADE PROCESS FOR G1E/G1E+ SOFTWARE.................... 197 Hardware requirements –..............................197 Software requirements – ..............................197...
  • Page 16 Issue 3.3.2 /. April, 2011...

  • Page 17: General Description - Introduction

    Multi Cabinet System. The G1E+ system has the ability to be fitted with an MPU4 card to the MBU. The MPU4 card will allow the cabinet to be a master to between 1 and 4 cabinets and the operating system to be converted to the GDS software with all GDS feature sets available.

  • Page 18: Compatibility Of The Telephone Network And Terminal Equipment

    PSTN network termination point. In the event of problem, you should contact your equipment supplier in the first instance.’ ISDN Installation For the ISDN unit (G1E-SIU), the G1E+ only offers ISDN S/T interface connection behind an NT1 device. It should not be connected to a “U” interface directly. Issue 3.3.2 / April, 2011...

  • Page 19: Economy And Efficiency

    In addition to being cost effective at the initial phase and for expanding to it's maximum capacity, the G1E system also is economical to operate as it consumes about the same amount of electricity as a 60 watt light bulb at full configuration. A maximum of 8 CO lines (or 6 ISDN BRI’s) and 28 Extensions can be...
  • Page 20 Description – G1E+ With Multi Cabinet Option The G1E+ is an advanced ISDN Digital hybrid telephone system employing a microprocessor stored program and digitally controlled solid state Time-division switching. The G1E+ system is specifically designed for small and middle business as well as residential applications. At the forefront of the system design is a universal concept to adapting and connecting with a variety of communications devices.

  • Page 21: Easy Installation

    Easy Installation • “Factory Ready” - All G1E Telephone systems are "ready to go" right out of the box. A well thought out default database is factory installed on each system which meets the needs for most installations. This alleviates hours of on site time, minimizing installation costs for both dealer and customer.

  • Page 22: Full Isdn And Voip Features

    Full ISDN and VOIP features The G1E system allows you to access different outside line types (PSTN & ISDN and VOIP) in one box and use Full ISDN Features when accessing an ISDN Line - such as: Call Charge Metering Information...
  • Page 23 G1E - General Description DK1-21/DK1-31 (Obsolete) ACP and DOORPHONES DK2-21 DK2-21 with DSS Console DK3-21 DK3-33...

  • Page 24: Mechanical Specifications (Key Service Unit)

    Specifications MAXIMUM LOOP RESISTANCE/IMPEDANCE Key Telephone Less than 40 ohms 26 AWG / 200 m Single Line telephone Less than 800 ohms 26 AWG / 800 m DoorPhone Less than 40 ohms INTERNAL RELAY CONTACTS Type SPST Rating 1 AMP, 24VDC Function Door Switch, Music on Hold, etc CABLE REQUIREMENTS...

  • Page 25: Features

    G1E - General Description Features System Features Account Code Capability ISDN Attendant Console Assignment Call Charge Metering Information Attendant Overflow Caller Identification Automatic Line Access Direct Inward Dialling Automatic Line Search Call Forward Internal / External Automatic Ringdown Call Waiting...

  • Page 27: Station Features

    G1E - General Description Station Features Advisory Messages Access to System Programming Account Code Capability Auto Hold Auto Hold Recall Automatic Call Back Automatic Answer-Intercom Automatic Line Access Automatic Redial Automatic Volume Increase Brokers Call Call Duration Timer (LCD Phones)

  • Page 28: Parts & Peripherals

    Trunk Card : 4 CO lines G1E-SIU-3 ISDN S/T interface with 3 circuits G1E-VIU 3 Channel VOIP card - To be superseded by G1E-ITU during Q2 2009 G1E-STU-8 Station Card : 8 Digital ports G1E-SLU-1 Single Line Card : 8 SLT ports / with CLIP (Caller ID) function...

  • Page 29: System Installation - Introduction

    Multi-Service Card (G1E-MSC) G1E only • Voice Mail Card (G1E-VMC) • Voice services Card - Future NOTE: Please follow the directions step by step. The G1E-G1E+ system should be installed in strict accordance with this manual. (Cabinet1) (Cabinet 4) (HDLC 4)

  • Page 30: G1E Main Equipment With Msc, Vmc, 2 Tku's & 2 Stu's Installed

    G1E Main Equipment with MSC, VMC, 2 TKU’s & 2 STU’s Installed Issue 3.3.2 / April, 2011...

  • Page 31: G1E+ Main Equipment

    G1E Programming Manual G1E+ Main Equipment...

  • Page 32: Location

    Site Requirements Location Choosing the Right Environment • System should be installed in a clean, dry, secure location. This location must have adequate ventilation, and a temperature from 0 ℃ to 30℃ (32℉ to 86℉), with 10% to 95% non-condensing relative humidity.

  • Page 33: Installation

    G1E Programming Manual Installation Caution 1. This system should be installed by qualified service personnel. 2. Do not connect the Power Cord unless you have read the following instructions and completed all the installation and wiring. 3. STATIC SENSITIVE DEVICES! Please handle with care.

  • Page 34: Card Introduction

    3.CN6+CN7 :AC220 :180~260VAC 4.CN10 :Battery Connection +24V to +27V DC 5.LED2 : LED2 6.LED1 :G1E-PWU DC +32V indication 7.CN2 : Cable connection from G1E-PWU to G1-RGU CN1 8.CN1 : Cable connection from G1E-PWU to G1E-MBU Issue 3.3.2 / April, 2011...

  • Page 35: G1E-Mpu4 G1E+ Main Processing Unit(Optional For G1E+)

    The MPU4 is installed in Cabinet 1 only. Once installed the software in the MBU must be changed to a GDS-G1E version and then the G1E+ programming method will be replaced by GDS programming method using a Web browser via a network connection.

  • Page 36: G1E-Mxu G1E+ Main Exchange Unit

    The MXU4 is installed in Cabinet 2-4 only. Once installed the software in the MBU’s must be changed to a GDS-G1E version and then the G1E+ programming method will be replaced by GDS programming method using a Web browser via the network connection in Cabinet 1.

  • Page 37: G1E+ Mbu G1E+-36 Main Board Unit

    G1E Programming Manual G1E+ MBU G1E+-36 Main Board Unit CN1: Power connection to G1E-PWU CN1 LED2: DSP LED CN2: To G1E-TKU CN1 /G1E-VIU CN1 CN7: To ISDN/VOIP or G1E-SIU CN1 SW1: Reset Switch LED1: System operation indication when LED1 slow flashing is normal...

  • Page 38: G1E-Mbu G1E-36 Main Board Unit

    5.SW1 : Reset Switch 6.LED1 : Power LED 7.JP1 : Clear Flash Memory / Normal Operation NOTE: PLEASE READ MBU MARKINGS CAREFULLY. THERE ARE 2 DIFFERENT MBU LAYOUTS IN G1E+ MBU’S WITH DIFFERENT ORIENTATIONS OF JUMPERS. 8.CN4 : To G1E-MSC CN1 9.CN6 : To G1E-VMC CN1...

  • Page 39: G1E-Tku 4 Port Co Line Card

    G1E Programming Manual G1E-TKU 4 Port CO Line Card 1.CN1 : To G1E+ MBU CN2 2.CN2 : Power fail connection to G1E-SLU CN3 3.CN3 : TK 1 to 4 input from Central Office 4. K15 Ground 5.JP1 :TKU1/TKU2 switch to select TKU1/CO1~CO4 or TKU2/CO5~CO8 G1E-SIU 3 BRA ISDN Card 1.CN1 : BRA 1 to 3 input from Central Office...

  • Page 40: G1E-Viu 3 Port Voip Card (Obsolete)

    4. J4 : RS232 port. 5. J1 : LAN Port 6. J2 : PC Port 7. CN2 : To G1E+ MBU CN7 8. CN1 : To G1E+ MBU CN2 9.JP1 :VIU1/VIU2 switch to select VIU1/CO1~CO3 or VIU2/CO5~CO7 Issue 3.3.2 / April, 2011...

  • Page 41: G1E-Itu Ip Trunk Unit 4/8 Port (For G1E+ Only)

    ITU switch to select ITU1 or ITU2 (Must be set ITU2 position) The G1E-ITU card is only able to be used in TK2 position. If ITU only is installed the system will still see as TK2 but trunks will start from 801. If ITU card only is installed up to 12 VOIP trunks are available depending on ITC card installed.

  • Page 42: G1E-Stu 8 Port Digital Station Card

    1.CN1 : Connection to G1E+-MBU CN3 2.CN2 : Connections for ST1~ST8 3.CN3 : Power fail connection to G1E-TKU CN2 (CO1-4 or CO5-8) to ST1~ST4 4.JP1 : Switch to select SLU1 ports 21 ~ 28 or SLU2 ports 31 ~ 38 Note G1E-SLU requires the installation of the G1-RGU for correct operation Issue 3.3.2 / April, 2011...

  • Page 43: G1-Rgu-Ring Generator Unit

    G1E Programming Manual G1-RGU-Ring Generator Unit 1.CN1 : (DC 32V)/(DC 70V) to G1E-PWU CN2 G1E-MSC Multi Service Card (G1E Only) 1.CN1 : Connection to G1E-MBU CN4 2.CN2 RS232: RS232 connection to PC for SM5, Winloader, SMDR etc. 3.CN3 Relay/Sensor: G1E-RPC Remote Programming Card G1E+ Only...

  • Page 44: G1E-Vmc 4Port Voice Mail Card

    60 Secs 1000 G1E-VMU2- 1Gig- 4 Channels / 29 Hours Message Storage (Future) For a description of the VMU and Auto Attendant setup and configuration including how to record messages see the section at the end of the Installation Manual...

  • Page 45: G1E-Ams (Future)

    G1E Programming Manual G1E-AMS (Future) 1. Connection to G1E-MBU CN6 2. USB port 3. LAN port 4. WAN port 5. Reset Switch 6. LED 1~4: LED 1: LAN Port Connection status indicator. LED 2: WAN Port Connection status indicator. LED 3: Heart beat of IPP (Flashing means work normally) LED 4: Communication Status between VSU and CPU on board ７.

  • Page 46: Install G1E-Stu 8 Port Digital Station Card

    Install G1E-STU 8 Port Digital Station Card Installing the first expansion card Power off the system Set the Jumper on the card to STU1 Install 4 brass spacers to the MBU by removing screws from the MBU and replacing with spacers...

  • Page 47: Install G1E-Slu 8Port Single Line Station Card

    Make certain that the cable is pushed home firmly into the connector Power fail Power fail is available from a G1E-TKU card to the first 4 ports of an G1E- SLU card by connecting the supplied cable from CN3 on SLU card to CN2 on G1E-TKU card...

  • Page 48: Install G1-Rgu- Ring Generator Unit

    Make certain that the cable is pushed home firmly into the connector Install G1E+-RPC Remote Programming Card To G1E+ MBU2 The RPC card will only be able to be fitted to second generation G1E+ MBU’s Issue 3.3.2 / April, 2011...

  • Page 49: Install G1E-Tku 4Port Co Line Card

    Plug the cable from the MBU to the first TKU to the second TKU and then fasten TKU to spacers using the 4 screws removed from the first TKU. The cable from TKU card CN2 can be connected to CN3 of the G1E-SLU for power fail operation.

  • Page 50: Install G1E-Siu 3 Bra Card

    Install G1E-SIU 3 BRA Card Installing the first ISDN Trunk card Power off the system Set the Jumper on the card to SIU1 position Mount the SIU to the case using the provided screws Plug the cable into the MBU...

  • Page 51: Install G1E-Itu Ip Trunk Unit 4/8 Port (For G1E+ Only)

    ITU switch to select ITU1 or ITU2 (Must be set ITU2 position) Installing the IP Trunk card The first card must be a G1E-TKU or G1E-SIU card. The ITU will always be the second card. Power off the system Set the Jumper on the card to ITU2 position (if fitted)

  • Page 52: Install G1E-Viu 3 Voip Trunk Card (Obsolete) ( For G1E)

    4 screws removed from the first VIU. Make certain that the cable is pushed home firmly into the connector To Install G1E-VIU in G1E+ it will be necessary to cut 3 wires on the large Ribbon cable starting at pin 1. Contact Tech support for details...

  • Page 53: Install G1E-Vmc 4Port Voice Mail Card

    G1E Programming Manual Install G1E-VMC 4Port Voice Mail Card Power off the system before installing card Remove the screw from MBU and replace with Spacer Long spacer for G1E, short spacer for G1E+ Mount G1E-VMC CN1 to G1E/G1E+-MBU CN6 Screw VMC to Brass spacer...

  • Page 54: Installing G1E-Ams (Future)

    3. If you can access GDS/TDS system, there is a special screen on the GDS/TDS system to show you the IPP’s IP address. Refer to “FAQ about IP products” In the G1E plus IP system, press [6] to see the system version information and then press [6] again to see the IP address.

  • Page 55: Installing The Equipment

    G1E Programming Manual Installing the Equipment Backboard Be sure to plan and allow enough space to mount and connect the key service unit, power supply and system battery back up if applicable. Key Service Unit Use the enclosed paper template to locate the mounting position for the Key Service Unit.

  • Page 56: Charging The Battery

    Charging the Battery The rechargeable batteries are automatically charged when the KSU is plugged in. When System is in a full-load condition (eight CO Trunks and twenty-four Extensions all in use), the batteries provide a minimum of 1 hour's consecutive use. Change the batteries every two years. Installing or Replacing Batteries Caution To Reduce the Risk of Fire or Injury to persons, Read and Follow these Instructions.

  • Page 57: Connecting Stations

    G1E Programming Manual Connecting Stations The station cabling for the G1E should be a home run from the jack to the telephone room. The termination should be at conventional 66 type connecting blocks or Krone blocks or directly to the provided station connectors.

  • Page 58: Digital Key Telephone - Dk1-21/Dk2-21/Dk3-21/Dk3-31/Dk6

    For DK6 phones the switch is on the underside of the phone and should always be set to first position. Dip to right: the 1 station. CAUTION!: Avoid shorting Tip and Ring together. It may damage the G1E-MBU or G1E-STU board. Issue 3.3.2 / April, 2011...
  • Page 59 Connect Sensor for applications such as door open alarm to the ACP connector (6 contacts). Mount ACP connector on to ACP itself. Select the 1 station jumper as shown in diagram below. Mount ACP on the wall. CAUTION!: Avoid shorting Tip and Ring together. It may damage the G1E-MBU or G1E-STU board.

  • Page 60: Single Line Telephone (Connected To G1E-Slu)

    Single Line Telephone (connected to G1E-SLU) Station cables can enter from the bottom of the KSU. Remove the cover and route the station cable through the hole. Terminate the station wires with the connectors that are provided. The stations will connect to the KSU as shown on the main panel on connector locations 21-28 or 31 – 38 (Needs G1E-SLU/s installed) or 41-44.

  • Page 61: Isdn S/T Connections

    G1E Programming Manual CO/PABX Connections Make your CO line connection to the telephone company on this connector. Pins 3 and 4 of the connector are for the CO line. RJ-11C (2 wire) modular connector is required. 2-conductor wiring is required.
  • Page 62 If the connection is Point to Point then the terminator must be installed always. Unless there is a specific need for Point to Multi Point connection it is strongly recommended that Point to Point ONLY is used. Issue 3.3.2 / April, 2011...
  • Page 63 G1E Programming Manual T-Interface Connection: If the user has programmed the ISDN interface of SIU to a T-Interface, the wiring should be: S-Interface Connection: If the user has programmed the ISDN interface of SIU to a S-Interface, the wiring should be as the...
  • Page 64 Bus Configurations on the S/T Interface: Point to Point: d1: 750m ~ 1000m; Length limitation by attenuation of 6dB at 96kHz. Short Passive Bus: d2: 100m ~ 200m; Length limitation by round trip delay 10us to 14us, not by attenuation. d3: Recommendation with a cord having a minimum length of 5m and not more than 10m.(5m≦...

  • Page 65: Optional Cabling

    Programming Mode 39 -- Sensor Assignment. Paging Output (G1E+) The Paging output is available on G1E+ only. The Paging output is available on pins 3 and 4. Refer to Illustration Door Switch / Sensor Music on Hold Connection – G1E •...

  • Page 66: Rs232 Port Connection

    Notice: Do not exceed the cable length limitation (15M / 50 feet.) for the RS232 connection Connect old style 2 wire devices such as follows. Device TD (4) Gnd. (2) Gnd. DTR (1) links to DSR (5) on G1E end only. Issue 3.3.2 / April, 2011...

  • Page 67: Vmu Setup

    External Music on Hold Source – G1E The G1E system does not have an external Music port but relies on using the 2 Minute MOH message recorded on the MBU Flash ram. This message can be recorded by the customer to allow them to use their own message or an SLT port can be used to connect an external Music source if required.

  • Page 68: Power On And Operational Test

    Power On and Operational Test Before connecting the G1E-PWU to AC power: Verify that input voltage and input voltage selection jumper on G1E-PWU are correct before you power up the system. Recheck the cabling for incorrect connections, loose wires and wiring fragments that may cause short-circuits.

  • Page 69: Programming Information

    G1E Programming Manual PROGRAMMING INFORMATION...

  • Page 70: Programming Information

    Model G1E/G1E+ - Programming Manual Programming Information This document contains the system forms required to program the G1E and an explanation of the parameters. New Systems We recommend that all new systems have the system memory reset before system programming takes place.
  • Page 71 8.LCD display "XXXX Ready! " (xxxx = 0000~26FF) LED 1 will quick flash when finished, around 1 minute then power off system and take off VMC card 9.Power on B system the customer has G1e-E02g version. -- VMC Software upgrades - Remote -- 1.Two systems have VMC card...
  • Page 72 Basic Programming Commands: Note: Keys listed between [ ] indicate the default keys shown on a telephone set. Keys listed between { } indicate keys displayed by the programming overlay. See illustration Programming Overlay on the next page. These commands are active while in the system programming mode [F4]{PRG} Moves to the Top Level Programming Mode Display (does not save information entered into any field unless [SAVE] is pressed first).
  • Page 73 On the DK2-3 phone the function keys (21-29) will follow the same numbering scheme as the DK6 phone on a G1E. Connecting a DK2 on a softkey plan designed for a DK6 will still allow all function keys to work as per the markings on the phone as well as DSS buttons 1 to 22. When programming a new softkey plan for a DK2/3 it will be necessary to program all function keys as if for a DK6 and that will then translate correctly to the DK2/3.
  • Page 74 Issue 3.3.2 / April, 2011...
  • Page 75 G1E Programming Manual PROGRAM MODES...

  • Page 76: Program 01-Tk-Ip : Day Ringing And Ringing Line Preference Assignment

    Program 01-tk-IP : Day Ringing And Ringing Line Preference Assignment 01-tk-IP FLX DAY Tk = 01-12, IP = Item Pointer (01-26) Assigned station number. 111 000 000 000 General: This program assigns each incoming line to ring the programmed stations. The ringing methods can be LINEAR (ring the first available station), CIRCULAR (Ring the next station following the last station who just answered an incoming call), HUNT (Ring the first assigned station for a set period of time (program mode 05-08-01) then if no answer ring the next ring assigned station then the next etc.) or COMMON...

  • Page 77: Program 03-01-Ip : Door Phone Ringing Assignment

    G1E Programming Manual 6. Lunch ringing is programmed in Mode 94. Program 03-01-IP : Door Phone Ringing Assignment IP = 01-26 03-01-IP Door Assigned station number. 111 112 113 114 General: This program assigns the Door Phone/s to ring the programmed stations.

  • Page 78: Program 05-01-Ip : System Timing Parameters - 01

    Program 05-01-IP : System Timing Parameters – 01 IP = 01-08 05-01-IP SYS PAR System Default. 1 1 1 1 4 2 2 1 Item Display Timing Pointer Data Programming Data Description Table Default ----------- ---------- -------------------------------------------- ----------- --------------- Hold Recall Time 1=60 Sec.

  • Page 79: Busy Remind Cycle Time (Off-Hook Ringing)

    G1E Programming Manual 05. Busy Remind Cycle Time (Off-Hook Ringing): This parameter selects the length of time an incoming trunk call rings the system before a busy ring assigned station is reminded of the call. A muted, one-second ring will be given to the station through the speaker to indicate the call.

  • Page 80: Program 05-02-Ip : System Timing Parameters - 02

    Program 05-02-IP : System Timing Parameters – 02 IP = 01-08 05-02-IP SYS PAR System Default. 5 5 1 2 1 0 2 4 Item Display Timing Pointer Data Programming Data Description Table Default ---------- ----------- --------------------------------------------- ---------- ------------- SLT Dial Tone Timeout 5=15 Sec.

  • Page 81: Exchange Line Flash Time - Key Phone & Analogue Phone

    G1E Programming Manual 05. Exchange Line Flash Time - Key Phone & Analogue Phone: This parameter permits the selection of Flash time for Key stations when pressing the [TRF/FL] key or an analogue phone which presses flash and then dials 800 while connected to an outside line. After dialling 800 the flash signal will be sent to the exchange line and the analogue phone will reconnect to the exchange line.

  • Page 82: Program 05-03-Ip : System Timing Parameters - 03

    Program 05-03-IP : System Timing Parameters – 03 05-03-IP SYS PAR IP = 01-08 System Default. 0 0 1 9 0 3 0 6 Item Display Pointer Data Programming Data Description Default --------- ---------- ----------------------------------------------------------- ------------- Make / Break Ratio 0=33/66 Automatic Trunk Search 0=Yes...

  • Page 83: Toll Access Code

    This parameter assigns the number of digits used for the station numbering plan. 2, 3, or 4 digits may be used. In the G1E the system will set this parameter to 3 digits automatically at the time of system initialisation.

  • Page 84: Program 05-04-Ip : System Timing Parameters - 04

    ISDN test procedure that will cause conflict with Call Accounting. 115200 is for G1E monitor program and software upgrade for G1E only. G1E+ software upgrade is done at 56000. There is no need to change settings in this mode to upgrade software. G1E Monitor must be enabled in mode 05-24. 0=1200...

  • Page 85: Slt Hookflash Answer Delay

    G1E Programming Manual 05. SLT Hookflash Answer Delay: This parameter when enabled will prevent an SLT phone from activating a Hookflash until the time set has expired. 0 = disable 1 = 1 sec. 2 = 2 sec. ……… 9 = 9 sec.

  • Page 86: Program 05-05-Ip : System Timing Parameters - 05

    Program 05-05-IP : System Timing Parameters – 05 IP = 01-08 05-05-IP SYS PAR System Default. 0 0 0 0 3 1 1 0 Item Display Pointer Data Programming Data Description Default -------- ----------- ---------------------------------------------------------- ------------ Morning Call Type 0=MBU Message Meter Pulse Detect 0=Enable Speed Dial Unrestricted-1...

  • Page 87: Name Function

    G1E Programming Manual 05. Name Function: This parameter enables the naming feature for trunks, extensions and speed dials. Features \ Values Display Name instead of number for Extension Directory Dial for Speed Dial Directory Dial for Extension V: The feature is enabled.

  • Page 88: Program 05-06-Ip : System Timing Parameters - 06

    Program 05-06-IP : System Timing Parameters – 06 05-06-IP SYS PAR IP = 01-08 System Default. 7 4 0 0 0 3 0 0 Item Display Timing Pointer Data Programming Data Description Table Default --------- ----------- --------------------------------------------------- ------------ --------------- TRF Busy Recall Timeout 7=60 Sec.

  • Page 89: Operator Code

    G1E Programming Manual 05. Operator Code: This parameter is to set whether to dial "0" or "9" for the operator or for accessing a CO. line. 1 = Dial "9" for operator, "0" for C.O. line. 0 = Dial "0" for operator, "9" for C.O. line.

  • Page 90: Program 05-07-Ip : System Timing Parameters - 07

    Program 05-07-IP : System Timing Parameters – 07 IP = 01-08 05-07-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Timing Pointer Data Programming Data Description Table Default ---------- ---------- -------------------------------------------------- ------------- ------------- Intercom Searching 0=Disable Toll Override Prevention from quick dial 0=Disable...

  • Page 91: Toll Restriction Override Prevention

    G1E Programming Manual 05. Toll Restriction Override Prevention: If the setting is Disable, after accessing a line a user will be able to use a DTMF generator directly to the network rather than the DTMF signal generated within the KSU. The result of this is that Toll restrictions can be over-ridden.

  • Page 92: Program 05-08-Ip : System Timing Parameters - 08

    Program 05-08-IP : System Timing Parameters – 08 IP = 01-08 05-08-IP SYS PAR System Default. 3 0 3 0 7 2 4 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- -------------------------------------------------- ---------- ------------ Ring Hunt Time Setting 3=6 Sec.

  • Page 93: Disa Transfer Time No Answer

    G1E Programming Manual 06. DISA Transfer Time No Answer: An incoming call is answered by the DISA voice message and transferred to the called extension. If the called extension does not answer after this time duration the voice card will announce the status of the station (no answer).

  • Page 94: Program 05-09-Ip : System Timing Parameters - 09

    Program 05-09-IP : System Timing Parameters – 09 IP = 01-08 05-09-IP SYS PAR System Default. 0 1 0 0 0 1 5 2 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- -------------------------------------------------- ---------- ------------ Reserved Busy Console Queuing (Intercom Calls) 1=Enable Clear Forward - Loop Disconnect Detection...

  • Page 95: Reserved

    G1E Programming Manual 3 = Mexico busy tone (420 Hz, 250ms on/off) 4 = South African busy tone (400 Hz, 500ms on/off) 5 = Spanish busy tone (420 Hz, 200ms on/off) 6 = New Zealand Busy Tone (400Hz, 250ms on/off)

  • Page 96: Program 05-10-Ip : System Timing Parameters - 10

    (d). Example: The HYBREX is set to 2 digit numbering but the voice mail requires 4 digits. The voice mail also requires a pause between answering the call and the tones being sent. Set this parameter to the following...
  • Page 97 G1E Programming Manual Enhanced Protocol Internal Call Call Forward - All Calls (Ext) C11 + STB + STA Call Forward - Busy (Ext) C12 + STB + STA Call Forward - No Answer (Ext) C13 + STB + STA Direct Call From Extension...

  • Page 98: Program 05-11-Ip : System Timing Parameters - 11

    This parameter selects what the incoming caller will hear during Ring Transfer and Hold Recall conditions. The feature is designed for Australia to prevent the caller incorrectly recognizing the HYBREX's International Ring Back Tone as a disconnect or engaged signal and hanging up even though their call is still in progress.

  • Page 99: 05: Disa Special Function Access

    G1E Programming Manual 05: DISA Special Function Access: This parameter sets which of the system functions are able to be accessed by DISA callers. 0 = DISA can access an outside line by [9]/[0] + Password. User can access mail box from external call by [#] 1 = DISA cannot access an outside line by [9]/[0] + Password.

  • Page 100: Program 05-12-Ip : System Timing Parameters - 12

    2 = Use Key phone’s call transfer method and TRF for Trunk To Trunk. 3 = Use single line telephone’s call transfer method and TRF for Trunk To Trunk. Note: When parameter is set to 2 or 3 the G1E-VSC must be Installed in the G1E system. Not necessary in G1E+ 02.

  • Page 101: Voice Mail Call Forward Protocol Selection And Muting Leading Digits

    G1E Programming Manual 05. Voice Mail Call Forward Protocol Selection and Muting Leading Digits : This parameter selects between Standard Voice Mail Call Forward Protocol and the Enhanced Protocol. For a full description of Voice Mail Protocol see Mode 05-10.It will also set the muting of the leading...

  • Page 102: Program 05-13-Ip : System Timing Parameters - 13

    Program 05-13-IP : System Timing Parameters – 13 05-13-IP SYS PAR IP = 01-08 System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ Intercom Hot Key Dialling 0=No Immediate SMDR output 0=Disable...

  • Page 103: Cli Record Storing Method For Lcd Phones

    G1E Programming Manual 05. CLI Record Storing Method For LCD Phones: This parameter chooses which records and how many are stored for LCD phones when CLI is fitted to the system.. 0= Store CLI telephone numbers. 1= Store CLI names...

  • Page 104: Program 05-14-Ip : System Timing Parameters - 14

    Program 05-14-IP : System Timing Parameters – 14 IP = 01-08 05-14-IP SYS PAR System Default. 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- -------------------------------------------------- ---------- ------------ SLT LCR Switch on Delay for PSTN 0=Disable Reserved Reserved...

  • Page 105: Cid Delay Ring Time

    G1E Programming Manual 06. CID Delay Ring Time This parameter delays the DISA transfer to ensure that CID information is available and is transferred with the DISA call to the receiving station. If Mode 05-17-07 CID Call Screening is enabled it will not work unless this parameter is enabled.

  • Page 106: Program 05-15-Ip : System Timing Parameters - 15

    Program 05-15-IP : System Timing Parameters – 15 IP = 01-08 05-15-IP SYS PAR System Default. 0 0 0 0 0 0 0 1 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- -------------------------------------------------- ---------- ------------ VMU Date Stamp Method 0=Disable 3.1K Audio for SLT 0=3.1K...

  • Page 107: Reserved

    G1E Programming Manual 05. Reserved: 06. Reserved: 07. Reserved: 08. CLI & CFW LED Indication: This parameter controls the LED Indication of CLI Status and Call Forward Indication on DK6 and DK7 phones. 0 = LED flashes (DK6 green, DK7 red)

  • Page 108: Program 05-16-Ip : System Timing Parameters - 16

    Program 05-16-IP : System Timing Parameters – 16 05-16-IP SYS PAR IP = 01-08 System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ Midnight Reset 0=Disable Reserved DISA Single Digit Dialling Level...

  • Page 109: Reserved

    G1E Programming Manual 05. Reserved: 06. Reserved: 07. ACP Data Output Format: This parameter sets the format of ACP data output. The output can be in plain text or CTI output format. 0=CTI format output to RS232, and ACP data output=ON...

  • Page 110: Program 05-17-Ip : System Timing Parameters - 17

    Program 05-17-IP : System Timing Parameters – 17 05-17-IP SYS PAR IP = 01-08 System Default. 0 1 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ DSP Trunk Conference (not recommended) 0=Disable VMU Compression 1=32k...

  • Page 111: Dtmf Cid Leading Digits

    G1E Programming Manual 05. DTMF CID Leading Digits : This parameter enables/disables the display of Leading digits on DTMF Call ID example: D0289661356C Leading code =D Trailing code = C 0= no code 1=A 2=B 7=only display telephone number 06. DTMF CID Trailing Digits:...

  • Page 112: Program 05-18-Ip : System Timing Parameters - 18

    Program 05-18-IP : System Timing Parameters – 18 IP = 01-08 05-18-IP SYS PAR System Default. 0 0 0 0 0 0 8 5 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ Led Maintenance 0= Disable Reserved Dial out History Feature...

  • Page 113: Security Alarm And Fire Alarm Stop Timer

    G1E Programming Manual 05. Security Alarm and Fire Alarm stop timer: This parameter sets the time that the Security Alarm or Fire Alarm will ring when the feature is triggered. 0 = no limit 1 = 1 min 9 =9min Reserved: 06.

  • Page 114: Program 05-19-Ip : System Timing Parameters - 19

    Program 05-19-IP : System Timing Parameters – 19 IP = 01-08 05-19-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ Console Common Audible/Linear Ring 0= Linear Reserved Reserved...

  • Page 115: Distinctive Ring Select Australia/New Zealand

    G1E Programming Manual 05. Distinctive Ring Select Australia/New Zealand: This parameter selects which distinctive Ring Cadence the system will select, Australian (Duet) or New Zealand (Faxability). Trunks with Distinctive Ringing will need to be enabled in Mode 95-tk-06. 0 = Australia 1 = New Zealand 06.

  • Page 116: Program 05-20-Ip : System Timing Parameters - 20

    Program 05-20-IP : System Timing Parameters – 20 IP = 01-08 05-20-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ Reserved DISA Overflow to Virtual Mailbox 0=No Reserved...

  • Page 117: R Eserved

    G1E Programming Manual 07. Reserved: 08. Reserved:...

  • Page 118: Program 05-21-Ip : System Timing Parameters – 21

    Program 05-21-IP : System Timing Parameters – 21 IP = 01-08 05-21-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ Reserved Reserved Reserved Reserved...

  • Page 119: R Eserved

    G1E Programming Manual 07. Reserved: 08. Reserved:...

  • Page 120: Program 05-22-Ip : System Timing Parameters – 22

    Program 05-22-IP : System Timing Parameters – 22 IP = 01-08 05-22-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ Reserved Reserved Reserved Reserved...

  • Page 121: R Eserved

    G1E Programming Manual 07. Reserved: 08. Reserved:...

  • Page 122: Program 05-23-Ip : System Timing Parameters – 23

    Program 05-23-IP : System Timing Parameters – 23 IP = 01-08 05-23-IP SYS PAR System Default. 0 0 0 0 0 0 1 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- ----------------------------------------------------------- ---------- ------------ Reserved Reserved Reserved Reserved...

  • Page 123: Dsp W Atchdog R Eset

    G1E Programming Manual 07. DSP Watchdog Reset: This parameter when enabled will reset the DSP when it fails 0 = Disable 1 = Enable 08. Remote and Local Program Update Verification: This parameter enables verification of program updates either local or Remote.

  • Page 124: Program 05-24-Ip : System Timing Parameters – 24

    01. Reserved: 02.Reserved: 03. Reserved: 04. G1E Monitor System Tracking This parameter enables the G1E monitor system and handset tracking features. 0= Disable 2 = enable monitor Tx to DK phone trace 3 = enable monitor Tx to DK phone trace...

  • Page 125: G1E M Onitor O Utput

    3 = enable monitor DSP trace, monitor DSP Write Codec & download External program 08. G1E Monitor VMC Trace: This parameter enables /disables the G1E monitor VMC (Voice Mail Card) trace. 0 = Disable 1 = enable monitor VMC trace 2 = enable monitor VMC R/W CF card pointer table &...

  • Page 126: Program 06-Ip : Relay Assignment

    Program 06-IP : Relay Assignment IP = 01 06-000-01 Relay System Default. Item Display Pointer Data Description -------- -------- --------------------------- 00(00) 00-06 Relay of MSU/MSC xxxx 00-06 Relay of ACP (extension: xxxx) Description: MSU/MSC card and ACP device have 1 dry contact relay. No voltage is provided by the system, the installer will have to provide their own source to suit the application.
  • Page 127 G1E Programming Manual...

  • Page 128: Program 07-Gp-Ip : Flexible Key Group Assignment

    Each Key phone can be assigned to use two groups (Mode 41-st-(02 & 03)). Important NOTE: The G1E+ was designed with the DK6 as the main phone for use with the softkey plan. New softkey plans should be written for a DK6 phone particularly in regards to...
  • Page 129 G1E Programming Manual ff Code Function Door Phone Console- Set up Alarm Security Feature Console- Set up System Time Directory key (for name search) Pre-dial key Message Select Day / Night Day/Night/Lunch key Call Forward Forward Busy Forward No Answer...
  • Page 130 On the DK1/2/3 phone the function keys will follow the same numbering scheme as the DK6 phone on a G1E. Connecting a DK2 on a softkey plan designed for a DK6 will still allow all function keys to work as per the markings on the phone.

  • Page 131: Program 08-Gp-Ip : Flexible Dss Console Key Group Assignment

    G1E Programming Manual Program 08-gp-IP : Flexible DSS Console Key Group Assignment Gp = 01 IP = 01-66 (DSS Key Number) 08-gp-IP KEY GRP TK number for the key TK: nn Gp=01 IP=01-66 (DSS Key Number) 08-gp-IP KEY GRP Station number for the key...

  • Page 132: Program 09-Nnn-Dp : System Speed Dial

    Program 09-nnn-DP : System Speed Dial 09-nnn-DP TK:tt nn nnn = 100-999 DP = 01-30 tt = 01-10 nn = 40-43 Telephone number. nnnnnnnnnnnnnnnn General: This program permits the assignment of up to 900 sets of system speed dialling codes. If Names are enabled (default) then only 500 Speed dials are available.

  • Page 133: Program 10-Gp-Ip : Intercom Single Digit Assignment

    G1E Programming Manual Program 10-GP-IP : Intercom Single Digit Assignment Gp = 01-08, IP = 01-05 (digit 1 to 5) 10-gp-IP S.D.I. Station number for digit 1 to 5 000 000 000 000 000 General: This program permits the stations in one or more station groups to call a specific station by dialling one digit only.

  • Page 134: Program 11-Ip : Date And Time Setting

    This program permits the setting of system Date & Time. Description: The Date & Time will be held during a power failure on the G1E. There is no need to reset the Time after power is restored. Program 12-nn : System Alarm Clock...

  • Page 135: Program 13-Nn : Password

    G1E Programming Manual Program 13-nn : Password nn = Password Assigned (01-08) 13-nn Password Setting password dddddddd General: This program permits the assignment of 9 different passwords in the system. Description: The password length is from 1 to 8 digits. All unused digit positions must have ’d’ entered in them.

  • Page 136: Program 14-01-Ip : Smdr Specifications

    Program 14-01-IP : SMDR Specifications IP = 01-08 14-01-IP S.M.D.R. System Default 0 0 0 0 0 21 0 0 Item Display Programming Data Pointer Data Description -------- ---------- ------------------------------------------- ----------------------- Call Duration Start Time 0=00 Sec. Record Incoming Call 0=Record Record Local Call 0=Record...

  • Page 137: Number Of Records Between The Title

    Mode 45-st-08. This will prevent the system memory from being used to record calls unnecessarily. If administration phones are allowed to record their calls and are not checked out regularly then they will fill the system memory and prevent other calls being recorded. The G1E can store up to 350 records.
  • Page 138 SMDR OUTPUT DATA FORMAT TK S TELEPHONE NUMBER Account MM/DD START DURATION RING UNIT 001188629645752 12345678 10/02 08:35 00:02'35" Incoming 87654321 10/02 08:45 00:10'20" 00'10" Incoming no answer 10/02 12:00 00'35" 001188629645752 FAC:01 10/02 12:10 00:02'00" 03 X FAC or PSW error 10/02 12:30 05 X 001...
  • Page 139 (294150100) of the calling party and the extension number (112) of the calling party. The extension number shown is what the system will receive if the call is from another Hybrex with ISDN. The format may be different or non-existent from other telephone systems or on PSTN lines. The system can be programmed on a station by station basis to select whether calls to that station will display the Indial number dialled or the CLI information of the incoming caller.

  • Page 140: Program 17-Nn : Forced Account Code

    Program 17-nn : Forced Account Code nn = Forced Account Code (01-99) 17-nn FCAC CODE Forced account code (8 digits max.) Day level-Night Level __________ General: This program creates 99 Forced Account codes. Description: The forced account code will temporarily override a station's toll restrictions. 99 codes of up to 8 digits maximum are allowed.

  • Page 141: Program 18-Nn-Tk : Assign Toll Plans To Trunk Lines

    G1E Programming Manual Program 18-nn-TK : Assign Toll Plans To Trunk Lines nn = Toll plan number (00-09), tk = (01-10) 18-nn-tk Toll Toll class for each trunk (class 0-9) 0000000000 General: This Mode assigns Toll Plans to trunk lines. The Toll plans are to be written in Modes 51 to 59 and 61 to 66.

  • Page 142: Program 20-Nn- : Set Day - Time / Lunch Time Schedule

    Program 20-nn- : Set Day – Time / Lunch Time Schedule 20-nn Day Time nn = Day schedule pointer (00-06) Setting data 00 00 00 00 00 General: This program assigns day, night and lunch time from Sunday to Saturday for automatic night switching. Description: The system is capable of switching automatically between day / lunch break / night settings using the time parameters set in this Mode.

  • Page 143: Program 25 : Reset Data To System Default

    G1E Programming Manual Program 25 : Reset Data to System Default 25 - Reset Data 0 - 9 Default General: This program resets all data to System Default. All new systems must be reset to default before any programming in case corruption has been caused during handling or shipping. It will also be necessary to reset to default after a software upgrade is installed.

  • Page 144: Program 29-Tk-Ip : Trunk Specifications - 2

    Program 29-tk-IP : Trunk Specifications – 2 tk = 01-12, IP = 01-08 29-tk-IP TK SPEC System Default 0 0 0 2 0 0 0 0 Item Display Pointer Data Programming Data Description Default -------- ---------- ------------------------------------------------ ------------- Trunk Receive Gain 0= 0db ACD-1 Function Enable 0=Disable...

  • Page 145: Set Ring Frequency (Dk Handsets)

    G1E Programming Manual 04. Set Ring Frequency (DK handsets): This feature allows each trunk to ring at DK handsets with its own individual ring frequency and override the frequency set by the user for all calls. = As per the key phone’s ring setting.

  • Page 146: Program 35-Tk-Ip : Trunk Specifications - 1

    0 = CO. = Trunk line is Central Office line. 1 = PABX. = Trunk line is installed behind a PABX or Centrex. 35-tk-01=1 incoming not delay ring (05-14-06) for paging trunk (G1E only). 02. Trunk Signal: 0 = Pulse = Trunk dialling signal is Dial Pulse.

  • Page 147: Pick Up

    G1E Programming Manual 05. Pick Up: 0 = Day - can not Night - can not 1 = Day - can not Night - can 2 = Day - can Night - can not 3 = Day - can Night - can Can = An incoming call on this line can be answered by non-ringing stations.

  • Page 148: To Set A Trunk Name

    As described in Program 02-tk-IP, there are four ringing methods plus a Private line setting: All settings in item 08 are the same as item 07. 0 = Night - COMMON AUDIBLE 1 = Night - LINEAR 2 = Night - CIRCULAR 3 = Night - HUNT 4 = Night - PRIVATE To set a trunk name -...

  • Page 149: Program 36-Gp-Tk : Trunk Group Assignments

    G1E Programming Manual Program 36-gp-tk : Trunk Group Assignments gp = 01-08, IP = 01-12 36-gp-IP TK GRP trunks to be included 01 02 03 04 05 General: This program permits each trunk line to be assigned to different Trunk groups. There are eight groups in total.

  • Page 150: Program 37-Tk : Busy Out Trunks

    Program 37-tk : Busy Out Trunks tk = 01-12 37-tk Busy Out Busy out Type 0000000000 General: This program permits the trunk line to be locked by a Technician. Description: This feature is used when the user does not want to use the trunk or to remove a problem line. When the trunk is set to BUSY OUT, the LCD display on the phone will display "...

  • Page 151: Program 38-Gp-Tk : Dial 87 Trunk Group Assignments

    G1E Programming Manual Program 38-gp-tk : Dial 87 Trunk Group Assignments gp = 01-08, IP = 01-12 38-gp-IP TK GRP trunks to be included 01 02 03 04 05 General: This program permits each trunk line to be assigned to different Trunk groups which can be accessed by dialling [87].

  • Page 152: Program 39-Ip : Sensor Assignments

    00-18 SENSOR #1 on G2-MSU Card SENSOR #1 Contact Type Description: The G1E-MSU and each ACP provide1 Sensor. FN= Function No. S=Sensor Type Each Sensor can be assigned one of the following 18 functions in items 39-ST in the GDS-600.
  • Page 153 G1E Programming Manual If door key has been set in mode 07 and mode 39 and the sensor of the door phone is in use, the Door key on DSS will get the following indications: LED Indication Door Phone Status...

  • Page 154: Program 40-Stn-Ip : Station Class Of Service - 1

    Program 40-stn-IP : Station Class of Service – 1 st = Extension NO.(2-4 digits). IP = 01-08 40-stn-IP STCOS System Default 0 0 0 0 0 0 0 00 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------------- ----------- Override Level 0= Not allowed...

  • Page 155: Bell:

    G1E Programming Manual 04. Station Loud Bell: Refer to Program 06 to assign Relay to operate for a Loud Bell. 0 = No operation 1 = Operate relay on the MSC card when calls are received on this station. The system does not provide any voltage from the assigned relay. A separate ring voltage and ring device will need to be provided by the installer.

  • Page 156: Program 41-Stn-Ip : Station Specifications

    Program 41-stn-IP : Station Specifications st = Extension NO.(2-4 digits). IP = 01-07 41-stn-IP STSPE System Default 1 1 0 1 0 0 CN Item Display Pointer Data Programming Data Description Default ---------- ---------- ---------------------------------------------------------------- ----------- Station Group Key Group For Key phone Shift Key Group For Key phone 0=None Dial 9 trunk group...

  • Page 157: Ight

    This is for checking only, the system will automatically show the correct port number. It is not possible for the user to change or remove this parameter. In the G1E, the port number consists of 2 digits 11~18: station ports on the G1E-MBU 21~28: station ports on the 1 G1E-STU or G1E-SLU card.

  • Page 158: Program 42-Stn-Ip : Register Memory Blocks For Individual Speed Dial

    Program 42-stn-IP : Register Memory Blocks for Individual Speed Dial st = Station No. (2-4 digits) IP = 01-02 42-stn-IP SPD-T blocks (2 max.) for a Station b1 b2 Block 1 of Individual Speed Dial Codes (00-09 or DSS11~DSS20) Block 2 of Individual Speed Dial Codes (DSS1-10) (Digital phone only) General: This program divides sets of Individual Speed Dial into blocks for use by Stations.

  • Page 159: Program 43-Cn-Ip : Port Specifications

    = Position Number on Card (11-68) 11~18: station port on G1E-MBU 21~28: station port on the 1 G1E-STU card. 31~38: station port on the 2 G1E-STU or G1E-SLU card. 41~44: SLT ports on G1E-SIU MBU. Item Display Pointer Data Programming Data Description...

  • Page 160: Box Capacity-Virtual Mail Box:

    Virtual mailboxes can also be entered into a Hunt Group and using the settings in Mode 29-tk-07/08 allow the ring assignment of a G1E+ to overflow to a virtual mailbox for taking messages.

  • Page 161: Essage L Ength

    G1E Programming Manual 06. Maximum Message Length: To prevent a caller using up all the mail boxes capacity with a single message the length of each individual message is limited to 1 Voice segment in default. The size of voice segments will change with the size of the CF card and the compression rate used.
  • Page 162 Program 44-stn-IP : Station Class of Service – 2 st = Station No. (2-4 digits) IP = 01-08 44-stn-IP STCOS System Default 0 0 0 0 1 0 0 0 Item Display Pointer Data Programming Data Description Default ---------- ----------- ----------------------------------------------------------- ---------- System Alarm...

  • Page 163: P Assword

    G1E Programming Manual 04. Manual Line: If the setting is Enable, lifting the handset of the station will call the operator directly without dialling any digits. 0 = Disable 1 = Enable 05. Headset feature: When headset feature is enabled by the user (code is SPK 775) they can then use the [SPK] key to go on or off hook.

  • Page 164: Program 45-Stn-Ip : Station Class Of Service – 3

    Program 45-stn-IP : Station Class of Service – 3 st = Station No. (2-4 digits) IP = 01-08 45-stn-IP STCOS System Default 0 0 0 0 0 0 0 0 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- ------------- Intercom Call Limitation...

  • Page 165: Alarm:

    G1E Programming Manual 05. Intercom Calls to Different Station Groups: If this function is disabled then stations will not be able to make intercom calls outside their own station group (Mode 41-st-01). This parameter is for use in tenancy arrangements where each company wish's to remain totally separate although some stations can still be allowed this function, for instance a shared Receptionist.

  • Page 166: Program 46-Stn-Ip : Station Class Of Service – 4

    1 = MIC permanently on. 2 = MIC will switch on for Intercom calls For Single Line Telephone (Connected to G1E-SLU card or MBU SLT Port): This enables system to send internal and external CLIP(Caller ID) signals to the single line telephone...

  • Page 167: Ndial R Ecall C Apability

    G1E Programming Manual 04. DISA/ISDN Indial Recall Capability: If this parameter is enabled then when a DISA or ISDN Indial call rings an extension but the station is busy or does not answer (depending on setting) after the voice message announcing the status of the station is heard then the system will recall the operator after the assigned DISA transfer time.
  • Page 168 Program 47-stn-IP : Hot Line Assignment 47-stn HOT LINE St = Station No. (2-4 digits) Data. ( Extension Mode ) St= Station No. (2-4 digits) 47-stn HOT LINE Data. ( SPEED DIAL Mode ) SPD:000 General: This feature allows a user to lift the handset and directly call a specific outside party through System Speed Dial or an Intercom Extension without dialling any digits.
  • Page 169 G1E Programming Manual...

  • Page 170: Program 48-Stn-Ip : Station Class Of Service – 7

    Program 48-stn-IP : Station Class of Service – 7 st = Station No. (2-4 digits) IP = 01-08 48-stn-IP STCOS System Default 0 0 0 0 0 0 0 0 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- ----------- Auto Recording Incoming Calls...

  • Page 171: R Eserved

    G1E Programming Manual 05.Reserved: 06.Reserved: 07.Reserved: 08.Reserved:...

  • Page 172: Program 50-Stn-Ip : Station Class Of Service – 5

    This setting also allows the naming of Indials or CLI numbers using System Speed Dial Name / numbers. If this setting is a 1 then when an incoming call with CLI or an Indial number rings the G1E will search the System Speed dials and if this number is entered then the name associated with it will be displayed on the screen.

  • Page 173: Vm Leading Digit For Intercom Call:

    ACP’S and Door unlocking are used. 0= Use ACP relay. 1= Use G1e-MSC Relay (mode 06-00 needs to be assign to ‘2’ ) and ACP relay Related System Programming Mode: 05-12-04, 06 07. ACP Door Open Control This parameter sets what action is required to open the door lock from an ACP / RFID phone.

  • Page 174: Program (51 To 59)-Code-Ip : Toll Plans – Allowed Digits – Class 1 To 9

    Program (51 to 59)-code-IP : Toll Plans – Allowed Digits – Class 1 to 9 code = code no 01-16, IP = 01-12 51-code-01 Allow System default - - - - - - - - - - - - - General: This program sets allowed exception numbers for Toll Class 1.

  • Page 175: Program (61 To 66)-Code-Ip : Toll Plans – Restricted Digits – Class 1 To 6

    G1E Programming Manual Program (61 to 66)-code-IP : Toll Plans – Restricted Digits – Class 1 to 6 Code = code no 01-16, IP = 01-12 61-code-01 Restrict System default dddddddddddd General: This program sets Restricted numbers for Toll Class 1. These Modes should be read in conjunction with Modes 51 to 56.
  • Page 176 This example is based on the Australian network for the city of Sydney (area code 02, local calls start with the digits 8 and 9) where an 8 digit local numbering scheme is in place and allows local calls plus mobiles (04x) Set Mode 41-11-05/06 = 7 When this mode is set and Mode 57 is still at default then station 11 will be totally restricted.

  • Page 177: Program 67-Gp-Ip : Hunt Group Pilot Number

    01. Hunting Group Pilot Number: There are 10 Hunt Groups available in the G1E. Each Hunt Group is assigned a Pilot Number in this Mode. The pilot number can be any valid unused number and will have the same number of digits as the station-numbering scheme used in the system (2, 3 or 4).

  • Page 178: Program 68-Gp-Ip : Hunt Group Assignment – Day

    System default 000 000 000 000 General: This program sets Stations into Hunting Groups 1 to 10 for the G1E and assigns the order in which they will be accessed during Daytime. Description: There are 10 Hunt Groups available and 16 stations can be assigned into each group for Day and Night time.

  • Page 179: Program 69-Gp-Ip : Hunt Group Assignment – Night & Lunchtime

    System default 000 000 000 000 General: This program sets Stations into Hunting Groups 1 to 10 for the G1E assigns the order in which they will be accessed during Night time and Lunchtime. Description: There are 10 Hunt Groups available and 16 stations can be assigned into each group for Day and Night time.

  • Page 180: Program 70-Cd-Ip : Isdn Interface Specifications Program – G1E

    This application is normally for other ISDN devices (e.g. ISDN TA, ISDN video conference, ISDN card, …) that are hooked to the NT1 with the G1E. For Australian networks the usual connection is Point To Point. Network features such as Diversion will...

  • Page 181: Program 71-Cd-Ip : Calling Line Identification Presentation

    G1E Programming Manual Program 71-Cd-IP : Calling Line Identification Presentation Cd = 01-06, IP = 01-12 71-Cd-IP CLIP Table System default dddddddddddd General: To assign up to 6 specific numbers that an extension can present to the Exchange on an outgoing call.

  • Page 182: Program 72-St : Isdn Called Party Extension Number Assignment

    Program 72-St : ISDN Called Party Extension Number Assignment St= Extension Number 72-Stn ST NUM System default dddddddddddd 00 General: To assign an ISDN MSN/DDI number to a station or station hunting group. Description: Each incoming ISDN MSN or DDI number can ring a station or a hunting group. If ISDN MSN or DDI number is assigned for a station in this mode and this station is used to make an external call, the called party will receive the ISDN CLI number from this station.

  • Page 183: Program 75-Num-Ip : Lcr - Analysis Table

    G1E Programming Manual Program 75-Num-IP : LCR - Analysis Table Num = 001-500 75-Num-IP Dg Tab System Default. - - - - - - - - - - Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- -----------...

  • Page 184: Program 76-Num-Tm : Lcr – Routing Table

    Program 76-Num-Tm : LCR – Routing Table 76-Num-Tm Rou Ta Num = 01~60 Tm = Time Schedule A, B, C System Default. 00 00 0 00 0 00 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- ----------- 01,02 00~23 Start Hour of this Route Table...

  • Page 185: Program 77-Num : Lcr – Modifying Table

    G1E Programming Manual Program 77-Num : LCR – Modifying Table 77-Num-IP Mo Tab Num = 01~99 System Default. 0 0 d d d d d d d d d d Item Display Pointer Data Programming Data Description Default ---------- ----------...

  • Page 186: Program 78-Stn-Ip : Station Class Of Service – 6

    Program 78-stn-IP : Station Class of Service – 6 st = Station No. (2-4 digits) IP = 01-08 78-stn-IP STCOS System Default 0 0 0 0 0 0 0 0 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- ----------- LCR - Routing Level...

  • Page 187: Call Forward Busy Transfer Group:

    G1E Programming Manual 04. Call Forward Busy Transfer Group: This parameter sets the Permanent Call Forward Busy destination Hunt Group for the Station. If the Station user sets a Call Forward manually then it will override this setting but after cancelling the manual Call forward then this setting will be enabled again.

  • Page 188: Program 83-St-Ip : Register Memory Block For Cli History Buffer

    Program 83-st-IP : Register Memory Block for CLI history buffer st = Station No. (2-4 digits) IP = 01-02 83-st-IP CLI-T blocks (2 max.) for a Station b1 b2 b1/b2: Block 1/2 of CLI buffer for each extension General: This program divides sets of CLI history buffer into blocks for use by extensions. Description: Program 05-13-03, the Individual CLI history buffers are assigned: 05-13-03...

  • Page 189: Program 84-Ip : Home Area Code

    Sydney area code is '2' Set mode 84 to '02d'. When ISDN rings in to G1E system, the received number is 2-80710002. If you have set mode 84 as above, system will delete '2' and dial 80710002 for smart redial.

  • Page 190: Program 86-Nnn-Ip : Office Code Redial Pattern

    Program 86-nnn-IP : Office Code Redial Pattern nnn = office code 86-nnn N = Redial Pattern General: This program assigns the redial pattern for different office codes. Description: 0 = Redial pattern is NXX-XXXX (Local call: 7 Digit) 1 = Redial pattern is 1-NXX-XXXX (Local Toll: 1 + 7 Digit) 2 = Redial pattern is 1-NXX-NXX-XXXX (Local Toll: 1 + 10 Digit) CID Redial Feature for USA Market Retrieve the...
  • Page 191 G1E Programming Manual CID Redial Feature for USA Market Retrieve the CID number from the history buffer Action D / Area Code = Dial 1-NXX- Overlay Area NXX-XXXX Code ? (Case 6) Area Code = Home Area Code ? Action B /...

  • Page 192: Program 87-Cn-Ip : Assign Doorphone For Key Card

    Program 87-CN-IP : ASSIGN DOORPHONE FOR KEY CARD nn = card Number 01~99 87-nn-01 Card In IP = 01-24 = ACP port number 000000000000000 General: This program assigns which Key cards can be used on which ACP port to unlock a door. Description: Before a key card can be used to operate a door relay it must be enabled in this program mode.

  • Page 193: Program 89-Cn-Ip : Delete Key Card

    G1E Programming Manual Program 89-CN-IP : DELETE KEY CARD nn = card number 89-nn-01 Serial FFFFFFFF General: This program assigns allows the De-registration of the key cards from a system. Description: Enter the number (01-99) of the key card to de-register...

  • Page 194: Program 91-Tm : Acp Time Lock – Assign Time

    Program 91-TM : ACP TIME LOCK – Assign Time TM = Time Schedule (00~15) 91-TM Table 00 00 00 00 General: This program assigns different time schedules for the ACP time lock. Cards assigned in such programmed period can be used to open the ACP door. Description: The first 4 digits are starting time and the last 4 digits are stopping time.

  • Page 195: Program 93 : Mini Call Accounting Aoc Additional Number Charging

    G1E Programming Manual Program 93 : MINI CALL ACCOUNTING AOC ADDITIONAL NUMBER CHARGING 01 = Table (01~20) 93-01 Table 01 ------ 00 00 General: This program assigns additional charging for numbers dialled under Mini Call Accounting that is not provided By the Central Office.
  • Page 196 Mode 93 = 412ddd 01 06 (AA = 01, BB = 06) [HOTEL][4] = 04 00 (CC = 04, DD = 00) - One call is 3’50” (TT= 230 seconds) The Call Charge will be: Call Charge = Round(TT/BB) x AA x CC x DD = Round(230/06) x 01 x 4 x 0.01 = 1.56 The Mini-Call-Accounting output will be: 07.09 05:38 ROOM 11 DATE...

  • Page 197: Program 94-Tk-Ip : Lunchtime Ringing And Ringing Line Preference Assignment

    (program mode 05-08-01) then if no answer ring the next ring assigned station then the next etc.) or COMMON AUDIBLE (All stations will ring simultaneously). See Program Mode: 35-tk-08 to assign. The G1E Lunchtime ring type will follow the night ring type. An overflow Ring Hunt Group can be assigned to make additional stations ring after a time interval in addition to this ring assignment.

  • Page 198: Program 95-Tk-Ip : Trunk Specifications – 3

    Program 95-tk-IP : Trunk Specifications – 3 95-tk-IP TK SPEC tk = 01-12, IP = 01-08 0 0 0 0 0 0 0 0 System Default Item Display Pointer Data Programming Data Description Default -------- ---------- ------------------------------------------------ ------------- Detect Fax Signal 0=Disable Reserved Trunk Call Duration...

  • Page 199: R Eserved

    06. DUET (Distinctive Ringing) Setting : This feature is to enable the G1E to detect different ring cadences and direct incoming calls to different ring assigned stations depending on ring cadence in System Programming Mode 01-tk or Mode 02-tk when different rings are received.

  • Page 200: Programming Cross Reference

    Programming Cross Reference Incoming Calls INGING SSIGNMENT 01-tk-stn Day Ringing And Ringing Line Preference Assignment 02-tk-stn Night Ringing And Ringing Line Preference Assignment 05-01-05 Busy Reminder Tone Interval (Off-Hook Ringing / Busy - Camp-On) 05-02-07 Ring On Timer (Minimum ring to be detected) 05-02-08 Ring Off Timer (Time to hold signal during silent period) 05-08-01...

  • Page 201: Intercom Calls

    G1E Programming Manual 45-st-07 Speed Dial Unrestricted / Station EDIAL 05-02-03 Auto-Redial Off Hook (wait for answer) Timer 05-03-02 Automatic Trunk Search 05-05-07 Auto-Redial Attempts (Quantity) 05-05-08 Auto-Redial Time (Inter-Call) between attempts Intercom Calls NTERCOM IGNALLING 05-03-03 Intercom call signalling to electronic telephone sets...

  • Page 202: Disa

    PLIT 44-stn-03 Call Split RANSFER 05-06-01 Transfer Recall Timer Blind transfer (Camp-On / Busy) 05-06-02 Transfer Recall Timer blind transfer (No Answer) 05-08-06 DISA No Answer Recall (To Message) Timer 05-08-07 DISA Transfer Time (No Digits Dialled) ESSAGE AITING EVEL 46-stn-02 Message Waiting Level VERRIDE...

  • Page 203: Call Control

    G1E Programming Manual ‘9/0' T RUNK ROUPS 36-grp-trk Assign trunks to groups for Dial ‘9/0' 41-stn-04 Assign stations a Dial ‘9' group ‘87' T RUNK ROUPS 38-grp-trk Assign trunks to groups for Dial ‘87' 46-stn-01 Assign stations a Dial ‘87' group...

  • Page 204: Station Numbering

    20-nn Day/Night schedule Definition YSTEM LARM 12-nn System Alarm Clock 44-stn-01 Stations to include (notify) in system alarms P CALLS 05-05-01 Wake up signalling type Station Numbering 05-03-06 Digit length selection (2, 3, or 4 digits) 43-port-01 Station number (extension) Assignment Single Line Telephone 05-02-01 Dial Tone Timeout...

  • Page 205: Programming Operations

    Auto Attendant (DISA) operation rather than ACD-1. ACD-1 is standard on the G1E/G1E+ and operates on the built in voice messages The DSP has 4 channels available to handle incoming calls simultaneously but as it releases the call after playing the message a 4 channel VSC can handle many more trunks in ACD-1 operation.
  • Page 206 05-09-06 ACD-1 Answer Delay time 05-09-07 ACD-1 Message 2 Delay time 05-09-08 ACD-1 Disconnect Message Delay Time 29-tk-02 ACD enable Recording the ACD-1 Messages A Console must be used to record messages. In default the Console station 111. From the console dial 8901and enter the password when prompted, if AVMC is fitted then dial 8902 to record ACD-1 messages on the VMC.

  • Page 207: Disa And Auto Attendant Operation

    G1E Programming Manual DISA and Auto Attendant operation DISA operation includes the Auto Attendant for handling Caller selected routing for incoming calls and the option to dial through the system utilizing system trunks to dial to another destination.. It operates on any inwards ringing trunk except for Direct Indial calls ringing their assigned station.
  • Page 208 46-st-04 DISA action for unsuccessful call for each station Recording the DISA Messages A Console must be used to record messages. In default the Console station is111. From the console dial 8901 and follow the voice prompts to record Company Greeting messages. Full instructions for recording greetings are given by the Voice prompts.
  • Page 209 G1E Programming Manual Programming Single Digit DISA Single Digit DISA uses all the same programming modes plus the following Set mode 05-11-08 to enable single digit DISA and select which time periods single Digit DISA will be activated (Day/Night etc) Single digit dialling destinations in the G2 system are to Hunt Groups 1 to 8 corresponding to digits 1 to 8 dialled by the caller.

  • Page 210: Installing Acp's

    Installing ACP’s The ACP is similar in appearance to a normal doorphone with a numeric keypad, 2 extra keys(Call and PRG) and a 4 character LED display. The ACP has a built in relay, a sensor output and a case alarm for security.

  • Page 211: Setting Up Duet Ring Detect

    200ms followed by a 2 second silence then repeated. The second number cadence is 3 bursts of ring about 250ms long followed by a 1600ms silence period. The G1E software will detect the different Cadences and direct them to different ring assignment positions. Relevant Programming Modes...
  • Page 212 Mode 95-tk-06 selects which of the Item Pointers in Mode 01 and 02 will ring for the first cadence and which will ring for the second cadence. For example the following setting will allow all calls that are rung with the first cadence to ring any of the 22 phones set in Mode 01-tk-01 to 01-tk-22. Any calls that ring with the second cadence will ring the stations set in Mode 01-tk-23 to mode 01-tk-26.

  • Page 213: Pc Upgrade Process For G1E/G1E+ Software

    2. 6 Wire Line cord and RJ to DB9 Adapter Software requirements – 1. Winloader.EXE (G1-Programming Software – Windows Version) Start Winloader. Connect the RS232 cable from G1E MSU card or from G1E+ MBU RS232 connector to PC using RJ-11 to DB9 Female connector to PC COM port .
  • Page 214 Open Winloader and Check settings are correct for Com Port and 56000 Baud Rate If Baud rate or Com port are incorrect press configure and Communications. For G1E+ Select 56000 baud rate and select the COM port.
  • Page 215 For G1E Select 115000 baud rate and select the COM port. Press [OK]. the display will show: Select [File]->[Open] to load the upgrade software version from disk.
  • Page 216 Select the address of software. (Use default; there is no need to change these settings). The system will select automatically. Click OK...
  • Page 217 Select [Download] to start the upgrade. Upgrade Successful, press [Finish] to exit Winloader.exe and disconnect the cable. If you leave the cable connected and the program open the G1E will not restart if for some reason you turn it off and back on again.
  • Page 219 6F, 1, LANE 16, SEC. 2, SHIH CHUAN ROAD PAN CHIAO CITY, TAIPEI, TAIWAN http://www.hybrex.com AUTO TELECOM (AUSTRALIA) PTY.LTD. Unit 7, 3 Gibbes Street, Chatswood, NSW 2067 All data and specifications are subject to change without notice. P/N: 5503 4900 0000...

This manual is also suitable for:

G1e+

Table of Contents
