- Page 1 GDS-1280N 1280 Ports Enterprise Class Communication System Installation Manual...
-
Page 2: Notification
Notification Notification is hereby given that Auto Telecom Company Ltd. reserves the right to modify, change, update or revise this document from time to time as required without the prior obligation to notify any person, company or organization. Further, Auto Telecom makes no warranty or representation, either express or implied, with respect to merchantability, or fitness of its products for a particular purpose. -
Page 3: Important Safety Instructions
4. Use caution when installing or modifying telephone lines. The HYBREX GDS-1280 utilizes a 3 pin grounding power supply cord. This cord is not to be attached to any building surfaces. When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. -
Page 4: Table Of Contents
HYBREX GDS-1280 Enterprise Class Communication System General Description - Installation Table of Contents NOTIFICATION ................................- 2 - IMPORTANT SAFETY INSTRUCTIONS ........................- 3 - INSTALLATION SAFETY PRECAUTIONS: ........................ - 3 - GENERAL DESCRIPTION - INTRODUCTION ........................ 1 FCC RULES AND REGULATION ............................1 FCC R .............................. - Page 5 Choosing the Right Environment ............................. 13 ..............................13 NSTALLATION HECKLIST EQUIPMENT REQUIREMENTS ............................14 INSTALLATION .................................. 15 ........................... 15 ABINET CABLING AND CONNECTION DIP Switch Adjustment ..............................19 POWER SUPPLY VOLTAGE OPTIONS FOR THE UNIT .................... 21 POWER ON AND OPERATIONAL TEST (IMPORTANT) ................... 21 ) .............................
-
Page 7: General Description - Introduction
FCC Registration Number The HYBREX GDS-1280 is registered with the FCC in a dual registration capacity enabling the system to operate as a key system only or as a hybrid system. The FCC Registration Numbers are US: 3A7MF03BGDS- 600 for key systems registration and US: 3A7KF03BGDS-600 for hybrid operation. -
Page 8: Compatibility Of The Telephone Network And Terminal Equipment
Compatibility of the Telephone Network and Terminal Equipment. Availability of telephone interface information. Technical information concerning interface parameters and specifications not specified in FCC Rules, including the number of Ringers which may be connected to a particular line, which is needed to permit Terminal Equipment to operate in a manner compatible with Telephone Company communications facilities, shall be provided by the Telephone Company upon customer's request. -
Page 9: Key Highlights Of The Gds-1280
GDS-1280N - General Description Description Today’s large enterprises need reliable, flexible, remotely accessible, easy-to-manage voice communications solutions. The GDS Enterprise Class Communication System is exactly the answer. The GDS Enterprise Class Communication System is an integrated, interactive solution for medium-sized businesses, large corporations, chained hotels and hospitals. -
Page 10: Flexibility Of System Applications
20 options for each station providing maximum flexibility for nearly any application. Varied Extension Alternatives You can connect an ISDN Modem, ISDN phone, proprietary HYBREX DK series Keyphone, Access Control Phone (ACP), Door Phone and conventional industry standard single line sets – Modem, Answering Machine, Cordless phone, etc. - Page 11 GDS-1280N - General Description HYBREX Telephone Model DK1-21 DK2-21...
-
Page 12: Type Of Phones
Type of Phones Model Description DK1-21 Multifunction Key Telephone. Includes 32 character LCD display, speakerphone, handsfree, headset jack, 20 dual color keys and 14 function keys for feature access, DSS, CO Lines and speed dial. DK2-21 Multifunction Key Telephone. Includes 64 character LCD display, speakerphone, handsfree, headset jack, 22 dual color keys and 17 function keys for feature access, DSS, CO Lines and speed dial. -
Page 13: Mechanical Specifications (Key Service Unit)
GDS-1280N - General Description Mechanical Specifications (Key Service Unit) CABINET DIMENSIONS 438 mm W 411 mm D 107 mm H 17.2” 16.2" 4.2” WEIGHT 15 Kg 33 lbs Environmental Specifications OPERATING CONDITIONS STORAGE CONDITIONS Temperature 0º to 45º C -40º to 66º C (32º... -
Page 14: Features
Features System Features Account Code Capability ISDN Attendant Console Assignment Call Charge Metering Information Attendant Overflow Caller Identification Automatic Line Access Direct Inward Dialing Automatic Line Search Call Forward Internal / External Automatic Ringdown Call Waiting Automatic Wake-up MSN (Multiple Subscriber Number) Battery Charger Sub-addressing Behind PABX Operation... -
Page 15: Station Features
GDS-1280 - General Description Station Features On Hook Dialing Advisory Messages Prime Line Select System Privacy Personal Privacy Release Access to System Programming Private Line Account Code Capability Pulse/Tone Conversion Auto Hold Ring Frequency Selection Auto Hold Recall Ringing Line Preference Automatic Call Back Saved Number Redial Automatic Answer-Intercom... -
Page 16: Parts & Peripherals
Parts & Peripherals System Modules Model Description G2-MMD1280 Master Device for 1280 Port System - Single Processor, Single Power Supply. G2-MMD1280RP Redundancy Pack for G2-MMD1280, including G2-MPU16 Single (not available yet) Master Process Unit for 1280 port System, G2-PWU16 Single Power Supply for G2-MMD1280 Master Device The system module includes the following cards G2-PSU16... -
Page 17: System Installation - Introduction
System Installation - Introduction This section provides directions for installing the system and optional equipment. The installation must be performed by qualified service personnel. Main components of the system are: Key Service Unit, which includes: Optional Cards: • • Power Supply Unit (G2-PSU16) CPU Unit (G2- MPU16) for redundant central •... -
Page 18: Key Service Unit - General Introduction
Key Service Unit - General Introduction Front Panel of G2-MPUN16 Description: LAN：LAN port RS232：RS232 port LAN：LED of LAN connection PLL Normal：LED of PLL in normal status PLL Lock：LED of PLL locked CPU 1：LED of CPU 1 CPU 2：LED of CPU 2 Normal：Jump of normal status setting Default：Jump setting of default setting 10. -
Page 19: Location
Rear Side of MMD1280 (Power) AC/DC AC/DC AC IN AC IN Switch Switch ○ Power Redundancy 48 VDC IN For Grounding (Optional) For Battery Location Choosing the Right Environment • System should be installed in a clean, dry, secure location. This location must have adequate ventilation, and a temperature from 0 ℃... -
Page 20: Equipment Requirements
Equipment Requirements • Unpack, Check and Verify Equipment - Unpack the telephone equipment boxes and verify the contents in accordance with the packing list provided. If any discrepancies are noticed, please contact Auto Telecom or Authorized Dealers. • Damaged Boxes - If you notice any damage to the packages, please notify both the shipper and Auto Telecom or Authorized Dealers at once. -
Page 21: Installation
Installation Standard cards will be installed before shipping. You will receive a complete master device. It is not necessary to install the cards by your own. Cabinet cabling and connection In order to make the cabling easier and distinguishable among the bundles of cables, we include "Label Sticker of Numbers"... - Page 22 For Cabinet 1 Install the G2-MEUN16 card in the G2-MPU slot at cabinet 1 Connect to G2-IXU and to PCM Port 1 with red cable Connect to G2-IPU and to HDLC Port 1 with blue cable...
- Page 23 For cabinet 9 Install the G2-MEUN card in the G2-MPU slot at cabinet 9 Connect to G2-IXU and to PCM Port 9 with red cable Connect to G2-IPU and to HDLC Port 9 with blue cable...
- Page 24 For the other cabinets Connect G2-IXU to PCM port with red cable Connect G2-IPU2 to HDLC port with blue cable Note: Above picture is an example for cabinet 2. Please connect the other cabinets (3,4,5,6,7,8,10,11,12,13,14,15,16)accordingly.
-
Page 25: Dip Switch Adjustment
DIP Switch Adjustment 1. You need to adjust the DIP Switch in each GDS 600 cabinet. Before doing it, please assure the system is POWERED OFF. 2. Adjust SW1 on G2-MBU for cabinets. Please refer to the table on the mother board. See the below picture. For the 1 and 9 cabinet... - Page 26 Complete Connection and Cabling (Only for reference) We suggest you install the GDS 1280 main service unit on the top of the rack. PCM1-16 ports GDS 1280 Unit HDLC1-16 ports G2-MEUN16 for Cabinet 1 and 9 G2-IPU2 G2-IXU For other cabinets...
-
Page 27: Power Supply Voltage Options For The Unit
Power Supply Voltage options for the unit 100 to 240 VAC Auto Switch (50/60Hz) . Power On and Operational Test (Important) Before connecting the G2-PSU to AC power: Verify that input voltage and input voltage selection on G2-PSU are correct before you power up the system. -
Page 28: Standard Card Introduction
Standard Card Introduction G2-MBU16 (Front) 1.) CN1：Socket to connect to the main CPU unit (G2-MPUN16/CN5) 2.) CN2：Socket to connect to the main CPU unit (G2-MPUN16/CN5) 3.) CN3：Socket to connect to the main Exchange unit (G2-MXU16/CN3) 4.) CN4：Socket to connect to the main HDLC unit (G2-MHU16/CN4) G2-MBU16 (Back) 1.) CN5：Socket to connect to the main Power unit (G2-PSU16/CN2) 2.) CN6：Socket to connect to the main Power unit (G2-PSU16/CN2) -
Page 29: G2-Mpu16
G2-MPUN16 1. CN5: Socket to connect to the main Mother Board unit (G2-MBUN16) 2. Reset button 3. Jumper Terminator – Normal/Default ( Keep it at ‘Normal’ position, unless you need default setting.) 4. LED: flash green slow: CPU2 is working normally 5. -
Page 30: G2-Mhu16
G2-MHUN16 Top View 1. CN3：Socket to connect to the main Mother Board unit (G2-MBU16/CN4) 2. Please see below picture 3. Please see below picture Front View Ports to connect to Cabin 1-8 for HDLC 9-16 Ports to connect to Cabin 9-16 for HDLC CN3：Socket to connect to the main Mother Board unit (G2-MBU16/CN4) -
Page 31: G2-Mxu16
G2-MXUN16 1. CN3：Socket to connect to the main Mother Board unit (G2-MBU16/CN3) 2. Please see below picture 3. Please see below picture Top View Front View Ports to connect to Cabin 1-8 for PCM 9-16 Ports to connect to Cabin 9-16 for PCM CN3：Socket to connect to the main Mother Board unit (G2-MBU16/CN3) -
Page 32: G2-Psu16
G2-PSU16 1. CN2：Socket to connect to G2-MBU16/CN5 (6) -
Page 33: G2-Meun16
G2-MEUN16 1. Connect to G2-IXU PCM with red cable 2. PCM connection to GDS1280 KSU of PCM Port 1 or Port 9 with red cable 3. Connect to G2-IPU HDLC with blue cable 4. HDLC connection to GDS1280 KSU of HDLC Port 1 or Port 9 with blue cable 5. - Page 34 AUTO TELECOM COMPANY LTD. 10F, NO. 3, LANE 16, SEC. 2, SHIH CHUAN ROAD BAN QIAO CITY, TAIPEI, TAIWAN www.hybrex.com AUTO TELECOM (AUSTRALIA) PTY.LTD. Unit 7, 3 Gibbes Street, Chatswood, NSW 2067 www.hybrex.com.au AUTO TELECOM NEW ZEALAND LTD. PO Box 75-614 Manurewa Auckland, New Zealand www.hybrex.com.nz...
