HYBREX G1-824 Installation & Programming Manual

Digital telephone system
Hide thumbs Also See for G1-824:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
The Friendly HYBRid EXchange
G1-824
G2-1648
Digital Telephone System
ISDN Digital Telephone System
Installation &
Programming
Manual

Advertisement

Table of Contents
loading

Related Manuals for HYBREX G1-824

Summary of Contents for HYBREX G1-824

  • Page 1 The Friendly HYBRid EXchange G1-824 G2-1648 Digital Telephone System ISDN Digital Telephone System Installation & Programming Manual...

  • Page 2: Notification

    Notification Notification is hereby given that Auto Telecom Company Ltd. reserves the right to modify, change, update or revise this document from time to time as required without the prior obligation to notify any person, company or organization. Further, Auto Telecom makes no warranty or representation, either express or implied, with respect to merchantability, or fitness of its products for a particular purpose.
  • Page 3 4. Use caution when installing or modifying telephone lines. The HYBREX G1-824 utilizes a 3-pin grounding power supply cord. This cord is not to be attached to any building surfaces. When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1.

  • Page 4: Table Of Contents

    HYBREX G1-824 ISDN Digital Telephone System General Description - Installation - Programming Manual Table of Contents NOTIFICATION ................................II GENERAL DESCRIPTION - INTRODUCTION ......................2 FCC RULES AND REGULATION ..........................2 FCC R ............................2 EGISTRATION UMBER ............................2 INGER QUIVALENCE UMBER ........................2 OTIFICATION OF THE...
  • Page 5 EQUIPMENT REQUIREMENTS..........................14 INSTALLATION................................15 ........................15 NSTALLING EXPANSION AND OPTIONAL CARDS G1-CFC- Conference Card ............................16 G1-MSC- Multi Service Card............................16 G1-VSC- Voice Service Card ............................16 G1-TKU- 4 Port CO Line Card ..........................17 G1-CIC- Caller ID Card ............................17 G1-SIU ISDN S/T Interface Card ..........................18 G1-STC Digital Station Adapter Card........................19 G1-SLC Single Line Station Adapter Card ........................20 G1-RGU - Ring Generator Unit (for G1-SLC) ......................20...
  • Page 6 INSTALLATION................................41 ............................41 NSTALLING THE QUIPMENT Backboard ................................41 Key Service Unit ...............................41 ................................41 OWER UPPLY ........................41 NSTALLING EXPANSION AND OPTIONAL CARDS G2-IPU ..................................43 SW1: Reset button ............................43 G2-MSU- Multi Service Card............................44 JP1: Grounding Jumper for some specific external paging device ..............44 G2-VSC- Voice Service Card ............................45 G2-STU Digital Station Card............................45 G2-SLU Analog Station Card............................46...
  • Page 7 03. A – PSTN : ......................62 EDIAL INGING LINES 04. SLT R :.............................62 ELEASE IGNAL 05. E & A : ................63 XCHANGE LASH HONE NALOGUE HONE 06. SLT H : ..............................63 IGNAL 07. R : ................................63 08. R : ...............................63 PROGRAM 05-03-IP : SYSTEM TIMING PARAMETERS –...
  • Page 8 08. L – W 2 ......................86 EAST OUTING EEKLY OLIDAY PROGRAM 05-14-IP : SYSTEM TIMING PARAMETERS – 14................87 01. ISDN R (G1-824)............................87 ECOVERY 02. G2-PIU C :..............................87 G2-PIU C : ..............................87 03. ISDN PRI T : ..............................87 04. MDC M : ......................88...
  • Page 9 PROGRAM 05-15-IP : SYSTEM TIMING PARAMETERS – 15................89 VMU S :..........................89 XTENDED ERVICE 05. ISDN P A:......................89 RIMARY RUNK UMBERS ISDN P B: ......................89 RIMARY RUNK UMBERS PROGRAM 05-16-IP : SYSTEM TIMING PARAMETERS – 16................91 07. O : ..........................91 UTPUT CCESS ONTROL 08.
  • Page 10 PROGRAM 35-TK-IP : TRUNK SPECIFICATIONS – 1 ..................114 01. T :.................................114 RUNK 02. T : ..............................114 RUNK IGNAL 03. E - ECF:.........................114 XTERNAL ORWARD 04. DISA/ECF (D ): ............114 IRECT NWARD YSTEM CCESS XTERNAL ORWARD 05. P :................................115 06. L :................................115 07.
  • Page 11 PROGRAM 68-GP-IP : HUNT GROUP ASSIGNMENT – DAY................144 PROGRAM 69-GP-IP : HUNT GROUP ASSIGNMENT – NIGHT ................145 PROGRAM 70-CD-IP : ISDN INTERFACE SPECIFICATIONS PROGRAM – G1-824........146 PROGRAM 70-CD-IP : ISDN(BRI/PRI) INTERFACE SPECIFICATIONS PROGRAM G2-1648.......147 PROGRAM 72-ST : ISDN CALLED PARTY EXTENSION NUMBER ASSIGNMENT........149 PROGRAM 73-ST : ISDN EXTENSION SUB-ADDRESS ASSIGNMENT ............149...
  • Page 12 PROGRAM 76-NUM-TM : LCR – ROUTING TABLE....................151 PROGRAM 77-NUM : LCR – MODIFYING TABLE ....................153 PROGRAM 78-ST-IP : STATION CLASS OF SERVICE – 6 ..................154 01. LCR R ............................154 OUTING EVEL 02. LCR – D ..........................154 IRECT CCESS A RUNK 06.
  • Page 15 G1-824 - General Description...

  • Page 16: General Description - Introduction

    FCC Registration Number The HYBREX G1-824 is registered with the FCC in a dual registration capacity enabling the system to operate as a key system only or as a hybrid system. The FCC Registration Numbers are 3A7TAI-35152-KF-E for key systems registration and 3A7TAI-36015-MF-E for hybrid operation.
  • Page 17 G1-824 - General Description set out in Subpart E of Part 68 of FCC Telephone Equipment Rules.

  • Page 18: Compatibility Of The Telephone Network And Terminal Equipment

    PSTN network termination point. In the event of problem, you should contact your equipment supplier in the first instance.’ ISDN Installation For the ISDN unit (G1/G2-SIU), the G1-824/G2-1648 only offers ISDN S/T interface connection behind an NT1 device. It should not be connected to a “U” interface directly. Issue 1.5 / May, 2002...

  • Page 19: Economy And Efficiency

    Single Line Telephone sets, with any combination of the two types. In addition to being cost effective at the initial phase and for expanding to it's maximum capacity, the G1-824 system also is economical to operate as it consumes about the same amount of electricity as a 60 watt light bulb at full configuration. A maximum of 8 CO lines (or 3 ISDN BRI’s) and 24 Extensions can be accommodated.

  • Page 20: Easy Installation

    Easy Installation • “Factory Ready” - All G1-824 Telephone systems are "ready to go" right out of the box. A well thought out default database is factory installed on each system which meets the needs for most installations. This alleviates hours of on site time, minimizing installation costs for both dealer and customer.

  • Page 21: Full Isdn Features

    G1-824 - General Description Full ISDN features The G1 system allows you to access two different outside line types (PSTN & ISDN) in one box and enjoy Full ISDN Features when accessing an ISDN Line - such as: Call Charge Metering Information...

  • Page 22: Mechanical Specifications (Key Service Unit)

    Specifications MAXIMUM LOOP RESISTANCE/IMPEDANCE Key Telephone Less than 40 ohms 26 AWG / 200 m Single Line telephone Less than 800 ohms 26 AWG / 800 m DoorPhone Less than 40 ohms Music Source Input Impedance 600 ohms Maximum Input 0.775 VRMS INTERNAL RELAY CONTACTS Type...

  • Page 23: Features

    G1-824 - General Description Features System Features Account Code Capability ISDN Attendant Console Assignment Call Charge Metering Information Attendant Overflow Caller Identification Automatic Line Access Direct Inward Dialling Automatic Line Search Call Forward Internal / External Automatic Ringdown Call Waiting...

  • Page 25: Station Features

    G1-824 - General Description Station Features Advisory Messages System Personal Access to System Programming Account Code Capability Auto Hold Auto Hold Recall Automatic Call Back Automatic Answer-Intercom Automatic Line Access Automatic Redial Automatic Volume Increase Brokers Call Call Duration Timer (LCD Phones)

  • Page 26: Parts & Peripherals

    Parts & Peripherals System Modules Model Description G1-408P KSU with 4 CO lines, 4 Digital twin ports G1-408i KSU with 2 ISDN S/T , 4 Digital twin ports G1-608i KSU with 3 ISDN S/T , 4 Digital twin ports G1-TKU-4 Trunk Card : 4 CO lines G1-TKU1-4 Trunk Card : 4 CO lines / with CLIP (Caller ID) upgrade option...

  • Page 27: System Installation - Introduction

    G1-CIC Card (Caller ID Card - four port circuits) • Conference Card (G1-CFC) • Multi-Service Card (G1-MSC) • Voice Service Card (G1-VSC) NOTE: Please follow the directions step by step. The G1-824 system should be installed in strict accordance with this manual.

  • Page 28: Site Requirements

    Site Requirements Location Choosing the Right Environment • System should be installed in a clean, dry, secure location. This location must have adequate ventilation, and a temperature from 0 to 45 to 113 ), with 10% to 95% non-condensing relative humidity. DO NOT install the equipment near sources of static electricity, excessive vibration, or water.

  • Page 29: Installation

    GDS-600 - General Description Installation Caution 1. This system should be installed by qualified service personnel. 2. Do not install the Power Supply unless you have read the following instructions and completed all the installation and wiring. 3. STATIC SENSITIVE DEVICES! Please handle with care. Installing expansion and optional cards In this step you will be installing printed circuit cards on to header pins of the main board in the basic cabinet.

  • Page 30: G1-Cfc- Conference Card

    Installing expansion and option cards (continued) G1-CFC- Conference Card Install this card on CN6 of the G1-MBU. Be sure that the component side of the G1-CFC is facing in towards right of KSU. CFC card is necessary for expanding system from 6 x16 to 8x G1-MSC- Multi Service Card Align CN1 of the MSC card with CN4 of the G1-MBU.

  • Page 31: G1-Tku- 4 Port Co Line Card

    GDS-600 - General Description G1-TKU- 4 Port CO Line Card Align four holes of G1-TKU with the standoffs on top of the existing G1-TKU or G1-SIU card provided for in the basic key service unit. Once aligned, place the four screws into the standoff securing the G1-TKU card. Set SW1 on the newly installed G1-TKU to ‘TKU1’...

  • Page 32: G1-Siu Isdn S/T Interface Card

    G1-SIU ISDN S/T Interface Card If the ISDN interface – G1-SIU is to be installed in the original basic key service unit (G1-408P), the existing G1-TKU needs to be uninstalled first. Replace the PVC plate with the attached one on the main panel. Align four holes of G1-SIU with the screw holes on the plastic cabinet, place the four standoffs into the holes securing the G1-SIU card.

  • Page 33: G1-Stc Digital Station Adapter Card

    GDS-600 - General Description G1-STC Digital Station Adapter Card For the 1 G1-STC card: Set SW2 on G1-STC to ‘STC1’ position. Align CN2 of the G1-STC card with CN2 of the G1-MBU. Align four screw holes on G1-STC with the standoff. Once aligned push the G1-STC on the connector.

  • Page 34: G1-Slc Single Line Station Adapter Card

    G1-SLC Single Line Station Adapter Card Install G1-SLC on G1-MBU: Connect the attached cable between CN1 of G1-SLC card to CN7 of the G1-MBU. Align four screw holes on the G1-SLC with the standoffs. Place the screws into the standoffs securing the G1- SLC card.

  • Page 35: G1-Rgu1 - Ring Generator Unit (For G1-Slc1 (Clip Version))

    GDS-600 - General Description G1-RGU1 - Ring Generator Unit (for G1-SLC1 (CLIP version)) The ring generator installs inside the power supply unit. Remove the cover of the power supply by taking out the 4 screws located on each corner. Inside the G1-RGU1 are 4 screws and a connecting cable.

  • Page 36: Installing The Equipment

    Installing the Equipment Backboard Be sure to plan and allow enough space to mount and connect the key service unit, power supply and system battery back up if applicable. Mounting Tabs Key Service Unit Use the enclosed paper template to locate the mounting position for the Key Service Unit.

  • Page 37: Charging The Battery

    GDS-600 - General Description Charging the Battery The rechargeable batteries are automatically charged when the KSU is plugged in. When System is in a full-load condition (eight CO Trunks and twenty-four Extensions all in use), the batteries provide a minimum of 1 hour's consecutive use. Change the batteries every two years. Installing or Replacing Batteries Caution To Reduce the Risk of Fire or Injury to persons, Read and Follow these Instructions.

  • Page 38: Connecting Stations

    Refer to the wiring diagram located on the inside of the cable cover for all connections Connecting Stations The station cabling for the G1-824 should be a home run from the jack to the telephone room. The termination should be at conventional 66 type connecting blocks or Krone blocks or directly to the provided station connectors.

  • Page 39: Digital Key Telephone - Dk1-21/22/31/33

    GDS-600 - General Description Digital Key Telephone – DK1-21/22/31/33 A cable cover is provided with the KSU. Station cables can enter from either the top or bottom as desired. Remove one or both ends of the cover as required and route the station cable through the hole. Terminate the station wires with the connectors that are provided.

  • Page 40: Digital Key Telephone - Dk1-21H

    Digital Key Telephone – DK1-21H A cable cover is provided with the KSU. Station cables can enter from either the top or bottom as desired. Remove one or both ends of the cover as required and route the station cable through the hole. Terminate the station wires with the connectors that are provided.

  • Page 41: Access Control Telephone - Acp

    GDS-600 - General Description Access Control Telephone – ACP A cable cover is provided with the KSU. Station cables can enter from either the top or bottom as desired. Remove one or both ends of the cover as required and route the station cable through the hole. Terminate the station wires with the connectors that are provided.

  • Page 42: Single Line Telephone (Connected To G1-Slc)

    Single Line Telephone (connected to G1-SLC) A cable cover is provided with the KSU. Station cables can enter from either the top or bottom as desired. Remove one or both ends of the cover as required and route the station cable through the hole.

  • Page 43: Single Line Telephone ( Connected To Dk-Sld)

    GDS-600 - General Description Single Line Telephone (connected to DK- SLD) A cable cover is provided with the KSU. Station cables can enter from either the top or bottom as desired. Remove one or both ends of the cover as required and route the station cable through the hole.

  • Page 44: Co/Pabx Connections

    CO/PABX Connections Make your CO line connection to the telephone company on this connector. Pins 3 and 4 of the connector are for the CO line. RJ-11C (2 wire) modular connector is required. 2-conductor wiring is required. ISDN S/T Connections Make your CO line connection to the telephone company on this connector.
  • Page 45 GDS-600 - General Description T-Interface Connection: If the user has programmed the ISDN interface of SIU to a T-Interface, the wiring should be as follows: S-Interface Connection: If the user has programmed the ISDN interface of SIU to a S-Interface, the wiring should be as the following:...
  • Page 46 Bus Configurations on the S/T Interface: Point to Point: d1: 750m ~ 1000m; Length limitation by attenuation of 6dB at 96kHz. Short Passive Bus: d2: 100m ~ 200m; Length limitation by round trip delay 10us to 14us, not by attenuation. d3: Recommendation with a cord having a minimum length of 5m and not more than 10m.(5m d3 10m) Extended Passive Bus:...

  • Page 47: Optional Cabling

    2-conductor wiring is required. Connect the door switch to pins 1 and 6 of the RJ-11 connector. Sensor Connection The Sensor connector on G1-824 may be used for the External Sensor input. The sensor may be configured for normally open or normally closed operation.

  • Page 48: Rs232 Port Connection

    RS232 Port Connection Use the RJ-11 connector to terminate the RS232 cable. Then connect the RJ-11 to the KSU with a 6 conductor line cord. Insert the line cord into the connector labelled RS-232. Notice: Don’t connect the RS232 cable over the length limitation (15M / 50 feet.) Issue 1.5 / May, 2002...

  • Page 49: Power On And Operational Test

    GDS-600 - General Description Power On and Operational Test Before connecting the G1-PWU to AC power: Verify that input voltage and input voltage selection jumper on G1-PWU are correct before you power up the system. Recheck the cabling for incorrect connections, loose wires and wiring fragments that may cause short-circuits.
  • Page 50 GENERAL DESCRIPTION G2-1648 Issue 1.5 / May, 2002...
  • Page 51 At the forefront of the system design is a universal concept to adapting and connecting with a variety of communications devices. Productive HYBREX Digital Key Telephones offer thoughtfully designed productive feature access to keep you connected with one another and customers.

  • Page 52: Mechanical Specifications (Key Service Unit)

    Mechanical Specifications (Key Service Unit) CABINET DIMENSIONS XXXmm W XXmm D XXXmm H XXX” " WEIGHT XX Kg (Configuration: XX lbs Mechanical Specifications (Battery Back Up Housing) CABINET DIMENSIONS 15.5” W 3.0” D 5.75” H WEIGHT With Batteries -16 lbs Without Batteries- 4 lbs. Mounting Screws 12.25”...

  • Page 53: Peripheral Devices

    GDS-600 - General Description color keys and 14 function keys for feature access, DSS, CO Lines and speed dial. DK1-33 Multifunction Key Telephone. Includes speakerphone, headset jack, 8 dual color keys and 14 function keys for feature access, DSS, CO Lines and speed dial.

  • Page 54: System Installation - Introduction

    System Installation - Introduction This section provides directions for installing the system and optional equipment. The installation must be performed by qualified service personnel. Main components of the system are: Key Service Unit, which includes: Optional Expansion Cards: • • Power Supply Unit (G2-PWU) Trunk Card (G2-TKU / G2-SIU / G2-PIU) •...

  • Page 55: Installation

    G1-824 Programming Manual Installation Caution 1. This system should be installed by qualified service personnel. 4. Do not install the Power Supply unless you have read the following instructions and completed all the installation and wiring. 5. STATIC SENSITIVE DEVICES! Please handle with care.
  • Page 56 Card Introduction 1.) CN1: Power socket to connect to the main power unit (G2-PWU) 2.) JP1: Reset jumper for flash memory 3.) SW1: Cabinet position selection 4.) CN2: LNU/MPU slot 5.) CN3: VMU 1 slot 6.) CN4: VMU 2 slot 7.) CN5: MSU slot 8.) CN6: IPU slot: G2-IPU slot 9.) CN8: DC power output...

  • Page 57: G2-Ipu

    G1-824 Programming Manual Installing CPU and option cards (continued) G2-IPU 1.) SW1: Reset button 2.) JP1: Terminators for bus expansion of multi-cabinet. 3.) JP2: Terminators for bus expansion of multi-cabinet. 4.) Socket for the HDLC controller for bus expansion of multi-cabinet.

  • Page 58: G2-Msu- Multi Service Card

    G2-MSU- Multi Service Card 1.) JP1: Grounding Jumper for some specific external paging device 2.) MODEM connector for the external MODEM connection to the system 3.) RS232 connector 4.) Relay / Sensor / External Paging connector 5.) CN3: Door Phone Interface (for DPU05) 6.) CN2: External Music on Hold Interface Issue 1.5 / May, 2002...

  • Page 59: G2-Vsc- Voice Service Card

    G1-824 Programming Manual G2-VSC- Voice Service Card G2-STU Digital Station Card Install this G2-STU card on STU1, STU/SLU2, …, STU/SLU5 slot of the G2-MBU.

  • Page 60: G2-Slu Analog Station Card

    G2-SLU Analog Station Card Install this G2-SLU card on STU/SLU2, …, STU/SLU5, SLU6 slot of the G2-MBU. G2-TKU- 4 Port CO Line Card Install G1-CIC card or G1-MDC card on G2-TKU (optional). Install this G2-TKU card on TKU1/TKU2/TKU3/TKU4 slot of the G2-MBU. Connect an attached cable between CN4 of G2-TKU to CN3 of G2-SLU for power failure transfer.

  • Page 61: G2-Cic- Caller Id Card

    G1-824 Programming Manual G2-CIC- Caller ID Card Adjust JP1 of G1-CIC card for G2 use. And then install G1-CIC card on CN6/CN7 of G2-TKU card. Miss alignment could damage both cards or the system.

  • Page 62: G2-Siu Isdn S/T Interface Card

    G2-SIU ISDN S/T Interface Card Install this G2-SIU card on TKU1/SIU1 or TKU2/SIU2 slot of the G2-MBU. JP3(A,B,C): DC feeding jumper. Default is no DC output. If the internal ISDN device does not offer local power and need DC feeding to work. The related jumper of this internal ISDN interface needs to be set to “on”. Caution: 1.

  • Page 63: G2-Piu Isdn Pri / T1 / E1 Interface Card

    G1-824 Programming Manual G2-PIU ISDN PRI / T1 / E1 Interface Card Install this G2-PIU card on TKU1/SIU1 slot of the G2-MBU. 1. RJ 45 Connector: Pin 1,2: for TX. Pin 4,5: for RX. 2. LED 2: For Sync with network.

  • Page 64: Preparing The External Battery Backup

    Replace Cover With the expansion and option cards installed and the battery insulator removed, replace the cover and install the 4 screws removed earlier. This concludes the installation of expansion and option cards! Preparing The External Battery Backup The Key Service Unit has two external backup batteries in series (12 volts each) for emergency power when a power failure takes place.

  • Page 65: System Ground

    G1-824 Programming Manual instructions and limitations specified in this manual. 2. Observe proper polarity orientation between the batteries and battery charger. 3. Do not mix old and new batteries in this product. 4. Do not mix batteries of different sizes or from different manufacturers in this product.

  • Page 66: Power On And Operational Test

    Power On and Operational Test Before connecting the G2-PWU to AC power: Verify that input voltage and input voltage selection jumper on G2-PWU are correct before you power up the system. Recheck the cabling for incorrect connections, loose wires and wiring fragments that may cause short-circuits. Plug the power cord into a power outlet.

  • Page 67: Programming Information

    G1-824 Programming Manual PROGRAMMING INFORMATION...

  • Page 68: Programming Information

    Model G1-824/G2-1648 - Programming Manual Programming Information This document contains the system forms required to program the G1-824 and an explanation of the parameters. New Systems We recommend that all new systems have the system memory reset before system programming takes place.

  • Page 69: Basic Programming Commands

    For the first time or infrequent installer, a programming overlay is provided with each Key Service Unit. This overlay, when placed on a HYBREX LCD telephone set indicates keys used during programming for easy reference. Experienced installers may program without the overlay. Both key designations are listed below.

  • Page 70: Alphanumeric Entry

    DSS Key 2 = Cursor Forward If an entry is made that is not within valid system parameters, the HYBREX system will not accept the entry when [SAVE] is pressed. The Speaker on the programming set will return a busy tone and the LCD Display will place the programming cursor under the offending entry.
  • Page 71 G1-824 Programming Manual PROGRAM MODES...

  • Page 72: Program 01-Tk-Ip : Day Ringing And Ringing Line Preference Assignment

    Program 01-tk-IP : Day Ringing And Ringing Line Preference Assignment Tk = 01-10, IP = Item Pointer (01-16) 01-tk-IP FLX DAY Assigned station number. 11 12 13 14 15 General: This program assigns each incoming line to ring the programmed stations. The ringing methods can be LINEAR (ring the first available station), CIRCULAR (Ring the next station following the last station who just answered an incoming call), HUNT (Ring the first assigned station for a set period of time (program mode 05-08-01) then if no answer ring the next ring assigned station then the next etc.) or COMMON AUDIBLE (All stations will ring...

  • Page 73: Program 03-01-Ip : Door Phone Ringing Assignment

    This program assigns the Analogue door phone to ring the programmed stations. Description: 1. There is one Analogue door phone port available in the G1-824. 2. Eight stations can be assigned to ring for the Analogue door phone. 3. To clear all entries press [REDIAL].

  • Page 74: Program 05-01-Ip : System Timing Parameters - 01

    Program 05-01-IP : System Timing Parameters – 01 IP = 01-08 05-01-IP SYS PAR System Default. 1 1 1 1 4 2 2 1 Item Display Timing Pointer Data Programming Data Description Table Default ----------- ---------- -------------------------------------------- ----------- --------------- Hold Recall Time 1=60 Sec.

  • Page 75: Busy Remind Cycle Time (Off-Hook Ringing)

    G1-824 Programming Manual This parameter sets the time duration that a DISA trunk will ring prior to connection with return dial tone or VSC message. (Stations can answer during this time.) 0 = Automatic connection, no ring to the stations.

  • Page 76: Program 05-02-Ip : System Timing Parameters - 02

    Program 05-02-IP : System Timing Parameters – 02 IP = 01-08 05-02-IP SYS PAR System Default. 5 5 1 4 4 1 2 4 Item Display Timing Pointer Data Programming Data Description Table Default ---------- ----------- --------------------------------------------- ---------- ------------- SLT Dial Tone Timeout 5=15 Sec.

  • Page 77: Exchange Line Flash Time - Key Phone & Analogue Phone

    G1-824 Programming Manual 05. Exchange Line Flash Time - Key Phone & Analogue Phone: This parameter permits the selection of Flash time for Key stations when pressing the [TRF/FL] key or an analogue phone which presses flash and then dials 800 while connected to an outside line. After dialling 800 the flash signal will be sent to the exchange line and the analogue phone will reconnect to the exchange line.

  • Page 78: Program 05-03-Ip : System Timing Parameters - 03

    Program 05-03-IP : System Timing Parameters – 03 IP = 01-08 05-03-IP SYS PAR System Default. 1 0 0 9 0 2 0 9 Item Display Pointer Data Programming Data Description Default --------- ---------- ----------------------------------------------------------- ------------- Make / Break Ratio 1=40/60 Automatic Trunk Search 0=Yes...

  • Page 79: Toll Access Code

    This parameter assigns the number of digits used for the station numbering plan. 2, 3, or 4 digits may be used. In the G1-824 the system will set this parameter to 2 digits automatically at the time of system initialisation.

  • Page 80: Program 05-04-Ip : System Timing Parameters - 04

    0=Disable Message Waiting Method - Analogue Phones 1=Ring Description: 01. System Baud Rate Setting: This parameter sets the system Baud rate setting for SMDR and CTI applications for the G2-1648. The G1-824 is fixed at 2400 BPS. 0=1200 1=2400 2=4800...

  • Page 81: Speed Dialling Distribution

    G1-824 Programming Manual 05. Reserved 06. Speed Dialling Distribution: This parameter sets the number of speed dial numbers allocated to the system speed dial. Adding extra numbers to system Speed Dial reduces the number of personal Speed Dial numbers available to share between individual stations.

  • Page 82: Program 05-05-Ip : System Timing Parameters - 05

    Program 05-05-IP : System Timing Parameters – 05 IP = 01-08 05-05-IP SYS PAR System Default. 1 0 0 0 0 1 1 0 Item Display Pointer Data Programming Data Description Default -------- ----------- ---------------------------------------------------------- ------------ Morning Call Type 1=Music Meter Pulse Detect 0=Enable Speed Dial Unrestricted-1...

  • Page 83: Name Function

    G1-824 Programming Manual 05. Name Function: This parameter enables the naming feature for trunks, extensions and speed dials. Features \ Values Display Name instead of number for Extension Directory Dial for Speed Dial Directory Dial for Extension V: The feature is enabled.

  • Page 84: Program 05-06-Ip : System Timing Parameters - 06

    Program 05-06-IP : System Timing Parameters – 06 IP = 01-08 05-06-IP SYS PAR System Default. 1 0 0 1 0 3 0 0 Item Display Timing Pointer Data Programming Data Description Table Default --------- ----------- --------------------------------------------------- ------------ --------------- TRF Busy Recall Timeout 1=60 Sec.

  • Page 85: Operator Code

    G1-824 Programming Manual 05. Operator Code: This parameter is to set whether to dial "0" or "9" for the operator or for accessing a CO. line. 1 = Dial "9" for operator, "0" for C.O. line. 0 = Dial "0" for operator, "9" for C.O. line.

  • Page 86: Program 05-07-Ip : System Timing Parameters - 07

    Program 05-07-IP : System Timing Parameters – 07 IP = 01-08 05-07-IP SYS PAR System Default. 0 0 2 0 0 0 0 0 Item Display Timing Pointer Data Programming Data Description Table Default ---------- ---------- -------------------------------------------------- ------------- ------------- Intercom Searching 0=Disable Toll Override Prevention from quick dial 0=Disable...

  • Page 87: Toll Restriction Override Prevention

    G1-824 Programming Manual 0 = Recall To Operator 1 = No Recall To Operator No dialling after the first voice The VSC has already announced that the The VSC has already announced the Value announcement of VSC. called station is busy or no answer.

  • Page 88: Program 05-08-Ip : System Timing Parameters - 08

    Program 05-08-IP : System Timing Parameters – 08 IP = 01-08 05-08-IP SYS PAR System Default. 0 0 0 0 7 1 4 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- -------------------------------------------------- ---------- ------------ Ring Hunt Time Setting 0=0 Sec.

  • Page 89: Slt Programming Digit

    G1-824 Programming Manual 05. SLT Programming Digit: This feature changes the programming digit used by an Analogue phone to perform its programmable features. For example call forward is normally 701, If this parameter is set to 3 the call forward code will be 301. If the setting is 0 then the analogue phones cannot do programming.
  • Page 90 Issue 1.5 / May, 2002...

  • Page 91: Program 05-09-Ip : System Timing Parameters - 09

    G1-824 Programming Manual Program 05-09-IP : System Timing Parameters – 09 IP = 01-08 05-09-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- --------------------------------------------------...

  • Page 92: Enable Time

    6 = Type 2 and 3 7 = Type 1, 2, 3. 8 = Type 4. 9 = Australian 06. ACD-1 Enable Time: This parameter is to set the time duration before the system answers an incoming call when the ring assigned station(s) are busy, if a VSC card is fitted.

  • Page 93: Program 05-10-Ip : System Timing Parameters - 10

    (d). Example: The HYBREX is set to 2 digit numbering but the voice mail requires 4 digits. The voice mail also requires a pause between answering the call and the tones being sent. Set this parameter to the following...
  • Page 94 Voice Mail from his key phone (on hook) and if they wish can lift the handset and take the call back from the Voice Mail. To enable the user presses [SPK] [7][7][3][1] and to disable presses [SPK] [7][7][3][0]. This feature is in the software of the HYBREX Digimail unit also. Record Function: This function is dependant on the Recording Unit being capable of inserting the recording tone to alert the caller they are being recorded.

  • Page 95: Program 05-11-Ip : System Timing Parameters - 11

    This parameter selects what the incoming caller will hear during Ring Transfer and Hold Recall conditions. The feature is designed for Australia to prevent the caller incorrectly recognizing the HYBREX's International Ring Back Tone as a disconnect or engaged signal and hanging up even though their call is still in progress.

  • Page 96: 05: Disa Special Function Access

    05: DISA Special Function Access: This parameter sets which of the system functions are able to be accessed by DISA callers. 0 = Allow users to access the DISA special functions by pressing [8],[9],[*],[#]. 1 = Allow users to access the DISA special functions by pressing [*],[#]. Disallow users to access the DISA special functions by pressing [8],[9].

  • Page 97: Program 05-12-Ip : System Timing Parameters - 12

    G1-824 Programming Manual Program 05-12-IP : System Timing Parameters – 12 IP = 01-08 05-12-IP SYS PAR System Default. 0 0 0 2 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- --------------------------------------------------...

  • Page 98: Voice Mail Call Forward Protocol Selection And Muting Leading Digits

    05. Voice Mail Call Forward Protocol Selection and Muting Leading Digits This parameter selects between Standard Voice Mail Call Forward Protocol and the Enhanced Protocol. For a full description of Voice Mail Protocol see Mode 05-10.It will also set the muting of the leading digits Setting Value VMS Leading Digit Type Short Long...

  • Page 99: Program 05-13-Ip : System Timing Parameters - 13

    G1-824 Programming Manual Program 05-13-IP : System Timing Parameters – 13 IP = 01-08 05-13-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- -----------------------------------------------------------...

  • Page 100: Cti-Trunk Status Report

    05. CLI Record Storing Method For LCD Phones: This parameter chooses which records and how many are stored for LCD phones when CLI is fitted to the system.. 0= Store CLI telephone numbers . 1= Store CLI telephone numbers and names together. If mode 05-13-05 = 1, pressing [CLI History] key, system will display CLI number and name.

  • Page 101: Program 05-14-Ip : System Timing Parameters - 14

    0=High Meter Pulse Detection Sensitivity - 2 0=High Description: 01. ISDN Recovery (G1-824) This parameter enables different recovery functions for ISDN line under poor ISDN connection or environment. 0= Disable 1= Recover every minute while idle 2= Recover every minute always THIS PARAMETER MUST ONLY BE USED IF THE ISDN IC’S ON THE SIU ARE V1.1 (SIEMENS MANUFACTURED)

  • Page 102: Mdc Meter Pulse Detecting Frequency

    04. MDC Meter Pulse Detecting Frequency: 0= 12K Hz 1= 16K Hz 05. ISDN CLI Send This parameter disables the sending of individual caller id information from stations during Call setup. Once a DID number is programmed to an extension then this number will be forwarded to the Central Office during Call Setup with possible undesirable results.

  • Page 103: Program 05-15-Ip : System Timing Parameters - 15

    G1-824 Programming Manual Program 05-15-IP : System Timing Parameters – 15 IP = 01-08 05-15-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- --------------------------------------------------...
  • Page 104 Issue 1.5 / May, 2002...

  • Page 105: Program 05-16-Ip : System Timing Parameters - 16

    G1-824 Programming Manual Program 05-16-IP : System Timing Parameters – 16 IP = 01-08 05-16-IP SYS PAR System Default. 0 0 0 0 0 0 0 0 Item Display Programming Data Timing Pointer Data Description Table Default ---------- ---------- -----------------------------------------------------------...
  • Page 106 Issue 1.5 / May, 2002...

  • Page 107: Program 06-Ip : Relay Assignment

    G1-824 Programming Manual Program 06-IP : Relay Assignment IP = 01 06-St-01 Relay System Default. Item Display Pointer Data Description -------- -------- --------------------------- 00(00) 00-06 Relay of MSU/MSC xxxx 00-06 Relay of ACP (extension: xxxx) Description: MSU/MSC card and ACP device have 1 dry contact relay.

  • Page 108: Program 07-Gp-Ip : Flexible Key Group Assignment

    Program 07-gp-IP : Flexible Key Group Assignment Gp = 01-08 IP = 01-25 (DSS Key Number) 07-gp-IP KEY GRP TK number for the key TK: nn Gp=01-08 IP=01-25 (DSS Key Number) 07-gp-IP KEY GRP Station numbe r for the key Gp=01-08 IP=01-25 (DSS Key Number) 07-gp-IP KEY GRP Function number for the key...
  • Page 109 G1-824 Programming Manual Alarm Assign ff Code Function Door Phone Console- Set up Alarm Reserved Console- Set up System Time Message Select Directory key (for name search) Pre-dial key Day / Night Call Forward Forward Busy Forward No Answer Meet me Page...
  • Page 110 Issue 1.5 / May, 2002...

  • Page 111: Program 08-Gp-Ip : Flexible Dss Console Key Group Assignment

    G1-824 Programming Manual Program 08-gp-IP : Flexible DSS Console Key Group Assignment Gp = 01-02 IP = 01-60 (DSS Key Number) 08-gp-IP KEY GRP TK number for the key TK: nn 08-gp-IP KEY GRP Gp=01-02 IP=01-60 (DSS Key Number) Station number for the key...

  • Page 112: Program 09-Nnn-Dp : System Speed Dial

    Program 09-nnn-DP : System Speed Dial nnn = 100-599 DP = 01-30 tt = 01-10 09-nnn-DP TK:tt Telephone number. nnnnnnnnnnnnnnnn General: This program permits the assignment of up to 500 sets of system speed dialling codes. Description: = 100-599 = Speed dial code, up to 500 sets in total. = 01-30 = Digit Pointer for telephone number.

  • Page 113: Program 10-Gp-Ip : Intercom Or Disa Single Digit Assignment

    G1-824 Programming Manual Program 10-GP-IP : Intercom or DISA Single Digit Assignment Gp = 01-08, IP = 01-05 (digit 1 to 5) 10-gp-IP S.D.I. Station number for digit 1 to 5 00 00 00 00 00 General: This program permits the stations in one or more station groups to call a specific station by dialling one digit only.

  • Page 114: Program 11-Ip : Date And Time Setting

    This program permits the setting of system Date & Time. Description: The Date & Time will be held during a power failure on the G1-824 if G1-MSC is fitted, there is no need to reset the Time after power is restored. The Real Time Clock is standard on the G2-824.

  • Page 115: Program 13-Nn : Password

    G1-824 Programming Manual Program 13-nn : Password nn = Password Assigned (01-08) 13-nn Password Setting password dddddddd General: This program permits the assignment of 9 different passwords in the system. Description: The password length is from 1 to 8 digits. All unused digit positions must have ’d’ entered in them.

  • Page 116: Program 14-01-Ip : Smdr Specifications

    Program 14-01-IP : SMDR Specifications IP = 01-08 14-01-IP S.M.D.R. System Default 0 0 0 0 0 21 0 0 Item Display Programming Data Pointer Data Description -------- ---------- ------------------------------------------- ----------------------- Call Duration Start Time 0=00 Sec. Record Incoming Call 0=Record Record Local Call 0=Record...

  • Page 117: Number Of Records Between The Title

    G1-824 Programming Manual 06. Number of records between the Title: This parameter permits the assignment of the number of records between each Title. If the Number = 00, The whole SMDR feature will be disabled. 07. Reserved: 08. Polarity Reversal: If reversal is disabled, the system will start the call timer after accessing a CO line.
  • Page 118 SMDR OUTPUT DATA FORMAT TK S TELEPHONE NUMBER Account MM/DD START DURATION RING UNIT 001188629645752 12345678 10/02 08:35 00:02'35" Incoming 87654321 10/02 08:45 00:10'20" 00'10" Incoming no answer 10/02 12:00 00'35" 001188629645752 FAC:01 10/02 12:10 00:02'00" 03 X FAC or PSW error 10/02 12:30 05 X 001...
  • Page 119 (294150100) of the calling party and the extension number (112) of the calling party. The extension number shown is what the system will receive if the call is from another Hybrex with ISDN. The format may be different or non-existent from other telephone systems or on PSTN lines. The system can be programmed on a station by station basis to select whether calls to that station will display the Indial number dialled or the CLI information of the incoming caller.

  • Page 120: Program 17-Nn : Forced Account Code

    Program 17-nn : Forced Account Code nn = Forced Account Code (01-48) 17-nn FCAC CODE Forced account code (8 digits max.) Day level-Night Level __________ General: This program creates 48 Forced Account codes. Description: The forced account code will temporarily override a station's toll restrictions. 48 codes of up to 8 digits maximum are allowed.

  • Page 121: Program 18-Nn-Tk : Assign Toll Plans To Trunk Lines

    G1-824 Programming Manual Program 18-nn-TK : Assign Toll Plans To Trunk Lines nn = Toll plan number (00-09), tk = (01-10) 18-nn-tk Toll Toll class for each trunk (class 0-9) 0000000000 General: This Mode assigns Toll Plans to trunk lines. The Toll plans are to be written in Modes 51 to 59 and 61 to 66.

  • Page 122: Program 19-Cn-Ip : Voice Service (Vsc) Assignment-G1 824

    VOICE MESSAGES MUST BE RECORDED FROM A MASTER CONSOLE ONLY. There is a channel available in the G1-824 and this is accessed by dialling 86 from the console. Each channel can be divided into 1 to 8 segments depending on requirements.
  • Page 123 G1-824 Programming Manual Dial 0 and after the tone has stopped, record the company greeting message, VOICE PORT (1) RECORDING....When completed Dial 1 and the screen display will be, VOICE PORT (1) (2) 0=REC 7=PLAY The 2 in brackets indicate that the second message segment is ready to record. Dial 0 and record the message...

  • Page 124: Program 20-Nn- : Set Day - Time / Lunch Time Schedule

    Program 20-nn- : Set Day – Time / Lunch Time Schedule nn = Day schedule pointer (00-06) 20-nn Day Time Setting data 00 00 00 00 00 General: This program assigns daytime from Sunday to Saturday for automatic night switching and sets lunchtime to allow the VSU to play a different message for this period.

  • Page 125: Program 25 : Reset Data To System Default

    G1-824 Programming Manual Program 25 : Reset Data to System Default 25 - Reset Data 0 - 9 Default General: This program resets all data to System Default. All new systems must be reset to default before any programming in case corruption has been caused during handling or shipping. It will also be necessary to reset to default after a software upgrade is installed.

  • Page 126: Program 29-Tk-Ip : Trunk Specifications - 2

    Program 29-tk-IP : Trunk Specifications – 2 tk = 01-10, IP = 01-08 29-tk-IP TK SPEC System Default 0 0 0 0 0 0 0 0 Item Display Pointer Data Programming Data Description Default -------- ---------- ------------------------------------------------ ------------- CO Line Loop Resistance Audio boost 0=0 Km.

  • Page 127: Set Ring Frequency (Dk Handsets)

    G1-824 Programming Manual InBlock Sending. The ISDN Central Office will send “Extension Called Party Number” or “Extension Sub-address Number” during the Setup procedure. Overlap Sending. The ISDN Central Office does not send “Extension Called Party Number” or “Extension Sub-address Number” during the Setup procedure. After the Setup procedure has been established, this information will be sent by Central Office.

  • Page 128: Program 35-Tk-Ip : Trunk Specifications - 1

    Related System Programming Mode: 29-Tk-07, 29-Tk-08, 67, 68, 69 Program 35-tk-IP : Trunk Specifications – 1 35-tk-IP TK SPEC tk = 01-10, IP = 01-08 0 1 0 0 3 0 0 0 System Default Item Display Pointer Data Programming Data Description Default -------- ----------...

  • Page 129: Pick Up

    G1-824 Programming Manual * Enable = Listed feature is operational. This feature needs G1-VSC or G1-SLC-8 installed. 05. Pick Up: 0 = Day - can not Night - can not 1 = Day - can not Night - can 2 = Day - can...

  • Page 130: Inward Line Ringing Method Assignment

    08. Inward Line Ringing Method Assignment (Night): As described in Program 02-tk-IP, there are four ringing methods plus a Private line setting: All settings in item 08 are the same as item 07. 0 = Night - COMMON AUDIBLE 1 = Night - LINEAR 2 = Night - CIRCULAR 3 = Night - HUNT 4 = Night - PRIVATE...

  • Page 131: Program 36-Gp-Tk : Trunk Group Assignments

    G1-824 Programming Manual Program 36-gp-tk : Trunk Group Assignments gp = 01-08, IP = 01-10 36-gp-IP TK GRP trunks to be included 01 02 03 04 05 General: This program permits each trunk line to be assigned to different Trunk groups. There are eight groups in total.

  • Page 132: Program 37-Tk : Busy Out Trunks

    Program 37-tk : Busy Out Trunks tk = 01-10 37-tk Busy Out Busy out Type 0000000000 General: This program permits the trunk line to be locked by a Technician. Description: This feature is used when the user does not want to use the trunk or to remove a problem line. When the trunk is set to BUSY OUT, the LCD display on the phone will display "...

  • Page 133: Program 38-Gp-Tk : Dial 87 Trunk Group Assignments

    G1-824 Programming Manual Program 38-gp-tk : Dial 87 Trunk Group Assignments gp = 01-08, IP = 01-10 38-gp-IP TK GRP trunks to be included 01 02 03 04 05 General: This program permits each trunk line to be assigned to different Trunk groups which can be accessed by dialling [87].

  • Page 134: Program 39-Ip : Sensor Assignments

    Program 39-IP : Sensor Assignments 39-ST-IP Sensor FN SS 39-ST-IP Sensor FN SS FN SS FN S Display Programming Data Data Description ----------- -------- -------- ------------------------------------------------------ 00(00) 00-18 SENSOR #1 on G2-MSU Card 00-06 SENSOR #1 Contact Type and Activating Time ACP Ext.
  • Page 135 G1-824 Programming Manual .The Sensor detects the signal disappears, all extensions will stop ringing. The LCD display will show BREAK ALARM !!!! when the alarm is activated. Individual stations can be programmed to not receive the Break Alarm in Mode 45-st-06.

  • Page 136: Program 40-St-Ip : Station Class Of Service - 1

    Program 40-st-IP : Station Class of Service – 1 st = Extension NO.(2-4 digits). IP = 01-08 40-st-IP STCOS System Default 1 1 0 0 0 0 0 00 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------------- ----------- Override Level 1=Low...

  • Page 137: Station Loud Bell

    G1-824 Programming Manual 04. Station Loud Bell: Refer to Program 06 to assign Relay to operate for a Loud Bell. 0 = No operation 1 = Operate relay on the MSC card when calls are received on this station. The system does not provide any voltage from the assigned relay. A separate ring voltage and ring device will need to be provided by the installer.

  • Page 138: Program 41-St-Ip : Station Specifications

    Program 41-st-IP : Station Specifications st = Extension NO.(2-4 digits). IP = 01-07 41-st-IP STSPE System Default 1 1 0 1 0 0 CN Item Display Pointer Data Programming Data Description Default ---------- ---------- ---------------------------------------------------------------- ----------- Station Group / Agent Group for ACD Key Group For Keyphone Shift Key Group For Keyphone / SLT Port as MOH Source 0=None...

  • Page 139: Dial 9 Trunk Group

    This is for checking only, the system will automatically show the correct port number. It is not possible for the user to change or remove this parameter. In the G1-824, the port number consists of 2 digits 11~18: station ports on the G1-MBU 21~28: station ports on the 1 G1-STC card.

  • Page 140: Program 42-St-Ip : Register Memory Block For Individual Speed Dial

    Program 42-st-IP : Register Memory Block for Individual Speed Dial st = Station No. (2-4 digits) IP = 01-02 42-st-IP SPD-T blocks (2 max.) for a Station b1 b2 Block 1 of Individual Speed Dial Codes (00-09 or DSS11~DSS20) Block 2 of Individual Speed Dial Codes (DSS1-10) General: This program divides sets of Individual Speed Dial into blocks for use by Stations.

  • Page 141: Program 43-Cn-Ip : Port Specifications

    Parameters for the port st 0 1 2 00 00 cn = Position Number on Card (11-68) In the G1-824, the port number consists of 2 digits 11~18: station port on G1-MBU 21~28: station port on the 1 G1-STC card.

  • Page 142: Flexible Key Pattern Group Assignments (Dss Console)

    Type 7 allows an SLT port to be used as an additional MOH input allowing tenanted systems to have different messages played to different trunk groups during Call Hold. Once an SLT port is set to MOH then in Mode 41- slt-03 the port can be allocated to all or individual trunks groups as a hold source.

  • Page 143: To Set An Extension Name

    G1-824 Programming Manual To set an extension name - 1. Enter system programming Mode 43. 2. Depress {Change} to enter the Name mode. 3. Input the name for the related extension by the following function keys. Key Pad Depress Depress...

  • Page 144: Program 44-St-Ip : Station Class Of Service - 2

    Program 44-st-IP : Station Class of Service – 2 st = Station No. (2-4 digits) IP = 01-08 44-st-IP STCOS System Default 0 0 0 0 0 0 0 0 Item Display Pointer Data Programming Data Description Default ---------- ----------- ----------------------------------------------------------- ---------- System Alarm...

  • Page 145: Manual Line

    G1-824 Programming Manual 04. Manual Line: If the setting is Enable, lifting the handset of the station will call the operator(s) directly without dialling any digits. 0 = Disable 1 = Enable 05. Headset feature: The user can then use the [SPK] key to go on or off hook. The user will overwrite this programming mode if they use [SPK 775] to switch between handset and headset mode.

  • Page 146: Program 45-St-Ip : Station Class Of Service - 3

    Program 45-st-IP : Station Class of Service – 3 st = Station No. (2-4 digits) IP = 01-08 45-st-IP STCOS System Default 0 0 0 0 0 0 0 0 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- ------------- Intercom Call Limitation...

  • Page 147: Receive Break Alarm

    G1-824 Programming Manual 06. Receive Break Alarm: If this parameter is disabled then the station will not receive the Break Alarm signal if one has been programmed in Mode 39. 0 = Enabled 1 = Disable 07. Allow Unrestricted Speed Dial Access: If this parameter is disabled then the station will not be able to access any of the Speed Dial numbers which have been unrestricted in Mode 05-05-03/04 if they conflict with the stations toll restrictions.

  • Page 148: Program 46-St-Ip : Station Class Of Service - 4

    Program 46-st-IP : Station Class of Service – 4 st = Station No. (2-4 digits) IP = 01-08 46-st-IP STCOS System Default 0 0 0 3 0 7 2 0 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- ----------- Dial [87] Trunk Group...

  • Page 149: Disa/Isdn Indial Recall Capability

    G1-824 Programming Manual 04. DISA/ISDN Indial Recall Capability: If this parameter is enabled then when a DISA or ISDN Indial call rings an extension but the station is busy or does not answer (depending on setting) after the voice message announcing the status of the station is heard then the system will recall the operator after the assigned DISA transfer time.

  • Page 150: Program 47-St-Ip : Hot Line Assignment

    Program 47-st-IP : Hot Line Assignment St = Station No. (2-4 digits) 47-st HOT LINE Data. ( Extension Mode ) St= Station No. (2-4 digits) 47-st HOT LINE Data. ( SPEED DIAL Mode ) SPD:000 General: This feature allows a user to lift the handset and directly call a specific outside party through System Speed Dial or an Intercom Extension without dialling any digits.
  • Page 151 G1-824 Programming Manual...

  • Page 152: Program 50-St-Ip : Station Class Of Service - 5

    Indials or CLI numbers using System Speed Dial Name / numbers. If this setting is a 1 then when an incoming call with CLI or an Indial number rings the G1-824 will search the System Speed dials and if this number is entered then the name associated with it will be displayed on the screen.

  • Page 153: Vms Leading Digits For Intercom Calls

    G1-824 Programming Manual 05. VMS Leading Digits For Intercom Calls: Enabling (disabling) this parameter allows the system to send (not send) the leading digit information of the extension when calling to the voice mail. This allows the operator to transfer someone’s call directly to the selected Voice mail box.

  • Page 154: Program (51 To 59)-Code-Ip : Toll Plans - Allowed Digits - Class 1 To 9

    Program (51 to 59)-code-IP : Toll Plans – Allowed Digits – Class 1 to 9 code = code no 01-16, IP = 01-12 51-code-01 Allow System default - - - - - - - - - - - - - General: This program sets allowed exception numbers for Toll Class 1.

  • Page 155: Program (61 To 66)-Code-Ip : Toll Plans - Restricted Digits - Class 1 To 6

    G1-824 Programming Manual Program (61 to 66)-code-IP : Toll Plans – Restricted Digits – Class 1 to 6 Code = code no 01-16, IP = 01-12 61-code-01 Restrict System default dddddddddddd General: This program sets Restricted numbers for Toll Class 1. These Modes should be read in conjunction with Modes 51 to 56.
  • Page 156 This example is based on the Australian network for the city of Sydney (area code 02, local calls start with the digits 8 and 9) where an 8 digit local numbering scheme is in place and allows local calls plus mobiles (04x) Set Mode 41-11-05/06 = 7 When this mode is set and Mode 57 is still at default then station 11 will be totally restricted.

  • Page 157: Program 67-Gp-Ip : Hunt Group Pilot Number

    Mode 68 (Day) and Mode 69 (Night). Each Hunt Group can be from 1 to 5 stations in the G1-824 and 1 to 16 stations in the G2-1648.

  • Page 158: Program 68-Gp-Ip : Hunt Group Assignment - Day

    System default 00 00 00 00 00 General: This program sets Stations into Hunting Groups 1 to 10 for the G1-824 assigns the order in which they will be accessed during Daytime. Description: There are 10 Hunt Groups available and 5 stations for the G1-824 and 16 for the G2-1684 can be assigned into each group for Day and Night time.

  • Page 159: Program 69-Gp-Ip : Hunt Group Assignment - Night

    System default 00 00 00 00 00 General: This program sets Stations into Hunting Groups 1 to 10 for the G1-824 assigns the order in which they will be accessed during Night time. Description: There are 10 Hunt Groups available and 5 stations for the G1-824 and 16 for the G2-1684 can be assigned into each group for Day and Night time.

  • Page 160: Program 70-Cd-Ip : Isdn Interface Specifications Program - G1-824

    Program 70-Cd-IP : ISDN Interface Specifications Program – G1-824 Cd = 01-04, IP = 01-03 70-Cd-IP S/T TYP System default General: To assign the ISDN interface to “S” interface or “T” interface. Description: Cd= 01 is to assign the “S” or “T” interface for the ISDN port on G1-SIU card.

  • Page 161: Program 70-Cd-Ip : Isdn(Bri/Pri) Interface Specifications Program G2-1648

    G1-824 Programming Manual Program 70-Cd-IP : ISDN(BRI/PRI) Interface Specifications Program G2-1648 Cd = 01-04, IP = 01-06 70-Cd-IP S/T TYP System default 111111 General: To assign the ISDN interface to “S” interface or “T” interface. Description: For ISDN BRI: Cd= 01 is to assign the “S” or “T” interface for the ISDN port on G2-SIU card.
  • Page 162 It sets the 1 ISDN interface to “T” interface and 3 interface to “S” interface. The user can program the station number in program mode 43, port 61~68. For ISDN PRI: Cd= 01 is to assign the “TE” or “NT” point for the G2-PIU card. 000000= “NT”...

  • Page 163: Program 72-St : Isdn Called Party Extension Number Assignment

    G1-824 Programming Manual Program 72-St : ISDN Called Party Extension Number Assignment St= Extension Number 72-St ST NUM System default dddddddddddd 00 General: To assign an ISDN MSN/DDI number to a station or station hunting group. Description: Each incoming ISDN MSN or DDI number can ring a station or a hunting group.

  • Page 164: Program 75-Num-Ip : Lcr - Analysis Table

    Assign an identifying Sub-Address Number 73-553 ST Sub Add 1234 to extension 553 for the ISDN incoming 1234 call. Program 75-Num-IP : LCR - Analysis Table Num = 001-500 75-Num-IP Dg Tab System Default. - - - - - - - - - - Item Display Pointer...

  • Page 165: Program 76-Num-Tm : Lcr - Routing Table

    G1-824 Programming Manual Program 76-Num-Tm : LCR – Routing Table 76-Num-Tm Rou Ta Num = 01~60 Tm = Time Schedule A, B, C System Default. 00 00 0 00 0 00 Item Display Pointer Data Programming Data Description Default ----------...
  • Page 166 Related system Programming: 05-13-07. 05-13-08, 36, 41-ST-04, 75, 76, 77, 78-st-01, 78-st-02 Issue 1.5 / May, 2002...

  • Page 167: Program 77-Num : Lcr - Modifying Table

    G1-824 Programming Manual Program 77-Num : LCR – Modifying Table Num = 01~99 77-Num-IP Mo Tab System Default. 0 0 d d d d d d d d d d Item Display Pointer Data Programming Data Description Default ---------- ----------...

  • Page 168: Program 78-St-Ip : Station Class Of Service - 6

    Program 78-st-IP : Station Class of Service – 6 st = Station No. (2-4 digits) IP = 01-08 78-st-IP STCOS System Default 0 0 0 0 0 0 0 0 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- ----------- LCR - Routing Level...
  • Page 169 G1-824 Programming Manual The 1A2 Emulation status is set below: 29-Tk-06 78-St-03 Status No access No access access with tone access with no tone Even if the 1A2 Emulation status is access, extensions can temporarily disable by pressing the Function key: [1A2 Emulation Privacy] –...

  • Page 170: Program 83-St-Ip : Register Memory Block For Cli History Buffer

    Program 83-st-IP : Register Memory Block for CLI history buffer st = Station No. (2-4 digits) IP = 01-02 83-st-IP CLI-T blocks (2 max.) for a Station b1 b2 b1/b2: Block 1/2 of CLI buffer for each extension General: This program divides sets of CLI history buffer into blocks for use by extensions. Description: Program 05-13-03, the Individual CLI history buffers are assigned: 05-13-03...

  • Page 171: Program 84-Ip : Home Area Code

    3-digit input maximum for this entry. The home area code can include the toll access code prefix. Example: For example, G1-824 is located in Taipei. Toll access code in Taiwan is '0' Taipei area code is '2' Set mode 84 to '02d'.

  • Page 172: Program 86-Nnn-Ip : Office Code Redial Pattern

    Program 86-nnn-IP : Office Code Redial Pattern nnn = office code 86-nnn N = Redial Pattern General: This program assigns the redial pattern for different office codes. Description: 0 = Redial pattern is NXX-XXXX (Local call: 7 Digit) 1 = Redial pattern is 1-NXX-XXXX (Local Toll: 1 + 7 Digit) 2 = Redial pattern is 1-NXX-NXX-XXXX (Local Toll: 1 + 10 Digit) CID Redial Feature for USA Market Retrieve the...
  • Page 173 G1-824 Programming Manual CID Redial Feature for USA Market Retrieve the CID number from the history buffer Action D / Area Code = Dial 1-NXX- Overlay Area NXX-XXXX Code ? (Case 6) Area Code = Home Area Code ? Action B /...

  • Page 174: Program 87-Cn-Ip : Assign Doorphone For Key Card

    Program 87-CN-IP : ASSIGN DOORPHONE FOR KEY CARD nn = card Number 87-nn-01 Card In IP = 01-40 = ACP port number 000000000000000 General: This program assigns which Key cards can be used on which ACP port to unlock a door. Description: Before a key card can be used to operate a door relay it must be enabled in this program mode.

  • Page 175: Program 89-Cn-Ip : Delete Key Card

    G1-824 Programming Manual Program 89-CN-IP : DELETE KEY CARD nn = card number 89-nn-01 Serial FFFFFFFF General: This program assigns allows the De-registration of the key cards from a system. Description: Enter the number (01-99) of the key card to de-register...

  • Page 176: Program 91-Tm : Acp Time Lock - Assign Time

    Program 91-TM : ACP TIME LOCK – Assign Time TM = Time Schedule (00~15) 91-TM Table 00 00 00 00 General: This program assigns different time schedules for the ACP time lock. Cards assigned in such programmed period can be used to open the ACP door. Description: The first 4 digits are starting time and the last 4 digits are stopping time.

  • Page 177: Programming Cross Reference

    G1-824 Programming Manual Programming Cross Reference Incoming Calls INGING SSIGNMENT 01-tk-stn Day Ringing And Ringing Line Preference Assignment 02-tk-stn Night Ringing And Ringing Line Preference Assignment 05-01-05 Busy Reminder Tone Interval (Off-Hook Ringing / Busy - Camp-On) 05-02-07 Ring On Timer (Minimum ring to be detected)

  • Page 178: Intercom Calls

    Intercom Calls NTERCOM IGNALLING 05-03-03 Intercom call signalling to electronic telephone sets 05-07-01 Intercom Step Call Type 41-stn-01 Station Group Assignment ATTERN 05-03-07 SLT Dial Tone Pattern Options 05-04-07 Intercom Single Digit Dialling 10-grp-xx Single Digit Dialling Assignment 41-stn-01 Station Group Assignment IRECT TATION ELECT...

  • Page 179: Disa

    G1-824 Programming Manual VERRIDE 40-stn-01 Override Level DISA 05-01-04 Delayed DISA Access Time 05-07-04 DISA Recall Capability 05-08-04 DISA Operator Recall Location ( No Answer) 05-08-06 DISA No Answer Recall Timer 05-08-07 DISA Transfer Timer - No digits dialled 05-11-06...

  • Page 180: System Clock

    ESTRICTION 05-05-03 Set a portion of system speed dial for no restriction (Hundreds) 05-05-04 Set a portion of system speed dial for no restriction (Tens) 05-03-05 Toll Access Code (Usually a ‘1') for SMDR only 18-pln-trk Assigning Toll Class by Toll Plan/Trunk used 41-stn-05 Station Day Toll Plan Assignment 41-stn-06...

  • Page 181: Miscellaneous

    G1-824 Programming Manual 05-02-02 Interdigit Timeout 05-02-04 Hookswitch Disconnect Timer 05-02-06 Minimum Flash Timer (used to recognize a hook switch flash for hold) 05-04-08 Message Waiting Status Setup 05-06-07 Single Line Telephone Hold Procedure 05-07-02 Toll fraud Protection (Calling Proof)
  • Page 182 6F, 1, LANE 16, SEC. 2, SHIH CHUAN ROAD PAN CHIAO CITY, TAIPEI, TAIWAN http://www.hybrex.com AUTO TELECOM (AUSTRALIA) PTY.LTD. Unit 7, 3 Gibbes Street, Chatswood, NSW 2067 All data and specifications are subject to change without notice. P/N: 5503 4900 0000...

This manual is also suitable for:

G2-1648

Table of Contents
