- Page 1 GN4 N AZIENDA CERTIFICATA ISO 9001 : 2000 high-efficiency cast iron boiler for liquid fuels and/or gas OPERATING, INSTALLATION AND MAINTENANCE INSTRUCTIONS caldaia di ghisa ad alto rendimento per combustibili liquidi e/o gassosi ISTRUZIONI PER L’USO L’INSTALLAZIONE E LA MANUTENZIONE chaudière en fonte a haut rendement pour combustibles liquides et/ou gazeux...
- Page 2 Carefully read this manual and keep it for future reference. The GN4 N is a high-effi ciency heat generator for the production of hot water for heating purposes, suitable for operation with jet burners on gas or liquid fuel.
-
Page 3: Operating Instructions
GN4 N 1. OPERATING INSTRUCTIONS 1.1 Control panel Ready for electronic control unit Thermometer Safety thermostat Control thermostat, 2 Stages Line switch “0 - I - TEST” Burner lockout indicator light fi g. 1 1.2 Ignition Move the main switch 5 to position “I” to power the boiler and the burner. Refer to the burner manual for the operation of this device. - Page 4 GN4 N 2.1 Water connections Make the water connections to the appliance according to the indications shown both next to each fi tting and in Figure 2 of this booklet. The connections must be made in such a way that the pipes are not under stress. The safety valve must be fi tted in the central heating circuit, as close as possible to the boiler, without there being any obstructions or on-off devices between the boiler and the valve.
- Page 5 GN4 N Connect the panels together, using the screws 1, the washers 2 and the nuts 3, reinforcing the bottom parts using the blades 4 fastened with the screws 5. Loosen the nuts “A”. Insert the side fastening bracket “B”...
-
Page 6: Service And Maintenance
All the adjustment, commissioning and maintenance operations must be performed by Qualifi ed Personnel, in compliance with the standards in force. FERROLI S.p.A. declines all liability for damage to persons and/or things deriving from the tampering with the appliance by unqualifi ed or unauthorised persons. -
Page 7: Technical Specifications
(NHV) kW volume drop drop Ø Ø Ø Modello ∆p mbar ∆t 10 ∆t 20 GN4 N 07 1040 161,3 GN4 N 08 1170 1010 185,1 GN4 N 09 1300 1140 208,9 1060 GN4 N 10 1430... - Page 8 37047 SAN BONIFACIO - VR - ITALY tel. 045/6139411 - tlx 480172 fax 045/6100233-6100933 www.ferroli.it...
