  • Page 1: User Manual

    USER MANUAL Model: LTM-4x4HDSDI 4x4 HD-SDI / SDI Router...
  • Page 2: Table Of Contents

    Protocol 2000 Figures Figure 1: LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Figure 2: Connecting the LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Figure 3: LTM-4x4HDSDI SETUP Dipswitches Figure 4: Connecting a PC without using a Null-modem Adapter Figure 5: RJ-45 PINOUT...
  • Page 3 Table 3: Machine # Dipswitch Settings Table 4: Crossover Cable RJ-45 PINOUT Table 5: Straight-through Cable RJ-45 PINOUT Table 6: Technical Specifications of the LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Table 7: LTM-4x4HDSDI Hex Codes for Switching via RS-232/RS-485 Table 8: Protocol Definitions...
  • Page 4: Introduction

    The LTM-4x4HDSDI is a true 4x4 matrix switcher for standard definition / high definition SDI signals that lets you simultaneously route any of the four inputs to any or all of the four outputs. In particular, the LTM-4x4HDSDI features: Input and output signals on BNC connectors Selector buttons that automatically light up in different colors—red,...
  • Page 5: Your Ltm-4X4Hdsdi 4X4 Hd-Sdi / Sdi Router

    Avoid interference from neighboring electrical appliances that may adversely influence signal quality and position your LTM-4x4HDSDI away from moisture, excessive sunlight and dust Your LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Figure 1, Table 1, and Table 2 define the LTM-4x4HDSDI 4x4 HD-SDI / SDI Router.
  • Page 6: Figure 1: Ltm-4X4Hdsdi 4X4 Hd-Sdi / Sdi Router

    Your LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Figure 1: LTM-4x4HDSDI 4x4 HD-SDI / SDI Router...
  • Page 7: Table 1: Front Panel Ltm-4X4Hdsdi 4X4 Hd-Sdi / Sdi Router

    Your LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Table 1: Front Panel LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Feature Function IR Receiver The red LED is illuminated when receiving signals from the Infra-red remote control transmitter POWER Switch Illuminated switch for turning the unit ON or OFF...
  • Page 8: Installing On A Rack

    Installing on a Rack Installing on a Rack This section describes what to do before installing on a rack and how to rack mount. Before Installing on a Rack How to Rack Mount Before installing on a rack, be sure that the environment is To rack-mount the machine: within the recommended range: Attach both ear brackets to the...
  • Page 9: Connecting Your Ltm-4X4Hdsdi 4X4 Hd-Sdi / Sdi Router

    The example in Figure 2 illustrates how to connect your LTM-4x4HDSDI: 1 Switch OFF the power on each device before connecting it to your LTM-4x4HDSDI. After connecting your LTM-4x4HDSDI, switch on its power and then switch on the power on each device...
  • Page 10: Figure 2: Connecting The Ltm-4X4Hdsdi 4X4 Hd-Sdi / Sdi Router

    Connecting Your LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Figure 2: Connecting the LTM-4x4HDSDI 4x4 HD-SDI / SDI Router...
  • Page 11: Dipswitch Settings

    LTM-4x4HDSDI unit is being controlled when several LTM-4x4HDSDI units connect to a PC or serial controller. Set the Machine # on a LTM-4x4HDSDI unit via SETUP DIPS 1, 2, 3 and 4, according to Table 3. When using a standalone LTM-4x4HDSDI unit, set the Machine # to 1.
  • Page 12: Controlling Via Rs-232 (For Example, Using A Pc)

    Connecting Your LTM-4x4HDSDI 4x4 HD-SDI / SDI Router 6.2 Controlling via RS-232 (for example, using a PC) To connect a PC to the LTM-4x4HDSDI unit, using the Null-modem adapter provided with the machine (recommended): Connect the RS-232 DB9 rear panel port on the LTM-4x4HDSDI...
  • Page 13: Controlling Via Ethernet

    Connecting the ETHERNET Port directly to a PC (Crossover Cable) You can connect the Ethernet port of the LTM-4x4HDSDI to the Ethernet port on your PC, via a standard crossover cable with RJ-45 connectors, as Table 4 and Figure 5 define.
  • Page 14: Figure 6: Local Area Connection Properties Window

    Connecting Your LTM-4x4HDSDI 4x4 HD-SDI / SDI Router Right-click Local Area Connection Properties. Select Properties. The Local Area Connection Properties window appears. Select the Internet Protocol (TCP/IP) and click the Properties Button (see Figure 6). Figure 6: Local Area Connection Properties Window Select Use the following IP Address, and fill in the details as shown in Figure 7.
  • Page 15: Connecting The Ethernet Port Via A Network Hub (Straight-Through Cable)

    Connecting the ETHERNET Port via a Network Hub (Straight- Through Cable) You can connect the Ethernet port of the LTM-4x4HDSDI to the Ethernet port on a network hub or network router, via a straight-through cable with RJ-45 connectors, as Table 5 defines:...
  • Page 16: Operating The Ltm-4X4Hdsdi

    7.2 Confirming Settings Choose to work in the AT ONCE or the CONFIRM mode (see section 7.2.1). When the LTM-4x4HDSDI operates in the AT ONCE mode, pressing an OUT-IN combination implements the switch immediately. In the CONFIRM mode, the TAKE button must be pressed to authorize the switch.
  • Page 17: Toggling Between The At Once And Confirm Modes

    Every action requires user confirmation, protecting against erroneous switching Execution is delayed until the user confirms the action Note that after ten seconds the LTM-4x4HDSDI will go to standby mode and the buttons and the 7-segment display will illuminate less brightly 7.2.1...
  • Page 18: Storing/Recalling Input/Output Configurations

    After pressing the same memory location the second time, the settings will take effect. 7.4 Locking the Front Panel To prevent changing the settings accidentally or tampering with the unit via your LTM-4x4HDSDI. Unlocking releases the the front panel buttons, lock protection mechanism. To lock the LTM-4x4HDSDI: Press the LOCK button for three seconds, until the LOCK button is illuminated.
  • Page 19: Technical Specifications

    ACCESSORIES: Power cord, Null-modem Adapter Table of Hex Codes for Serial Communication Table 7 lists the Hex values for a single machine (MACHINE # 1): Table 7: LTM-4x4HDSDI Hex Codes for Switching via RS-232/RS-485 IN/OUT 1 IN/OUT 2 IN/OUT 3...
  • Page 20: Protocol 2000

    Protocol 2000 10 Protocol 2000 The LTM-4x4HDSDI is compatible with Protocol 2000 (version 0.46) (below). This RS-232/RS-485 communication protocol uses four bytes of information as defined below. For RS-232, a null-modem connection between the machine and controller is used. The default data rate is 9600 baud, with no parity, 8 data bits and 1 stop bit.
  • Page 21: Table 9: Instruction Codes For Protocol 2000

    Protocol 2000 Table 9: Instruction Codes for Protocol 2000 Note: All values in the table are decimal, unless otherwise stated. INSTRUCTION DEFINITION FOR SPECIFIC INSTRUCTION NOTE DESCRIPTION INPUT OUTPUT RESET VIDEO SWITCH VIDEO Set equal to video input which is to Set equal to video output which is 2, 15 be switched...
  • Page 22 Protocol 2000 INSTRUCTION DEFINITION FOR SPECIFIC INSTRUCTION NOTE DESCRIPTION INPUT OUTPUT ERROR / BUSY For invalid / valid input (i.e. OUTPUT 0 - error 9, 25 byte = 4 or OUTPUT byte = 5), 1 - invalid instruction this byte is set as the input # 2 - out of range 3 - machine busy 4 - invalid input...
  • Page 23 Protocol 2000 INSTRUCTION DEFINITION FOR SPECIFIC INSTRUCTION NOTE DESCRIPTION INPUT OUTPUT VIDEO PARAMETER 1 – Input 0 - video gain SETTINGS FOR 2 – Output 1 - contrast INSTRUCTIONS 21, 2 - brightness 23, 26 3 - colour 4 - hue 5 - H-phase 6 - V-position CHANGE TO ASCII...
  • Page 24 Protocol 2000 NOTE 6 – If INPUT is set to 127 for these instructions, then, if the function is defined on this machine, it replies with OUTPUT=1. If the function is not defined, then the machine replies with OUTPUT=0, or with an error (invalid instruction code).
  • Page 25 Protocol 2000 For example, to connect input 4 to output 3 after a delay, send HEX codes (set for delayed switch) (switch code) then, after the required delay, send HEX codes (execute delayed switch) to implement the switch. NOTE 19 – After this instruction is sent, the unit will respond to the ASCII command set defined by the OUTPUT byte. The ASCII command to operate with the HEX command set must be sent in order to return to working with HEX codes.
  • Page 26: Safety Warning

    Safety Warning: Disconnect the unit from the power supply before opening/servicing. Caution P/N: 2900-000253...
