Vector Computer:

Main Computer:
• The Vector computer has 3 buttons, 2 LED's and an LCD screen.
LED's:
• Amber LED:
• Red LED:

Remote Switch:

• The remote switch (optional, sold separately) is required to
access lap timer and rally mode extended feature sets.
• If not in lap timer or rally mode, the remote switch buttons function
as duplicates of the buttons on the main computer.
REMOTE
SWITCH
TOP
BUTTON
MIDDLE
BUTTON
BOTTOM
BUTTON
LEFT BUTTON
8
Lights up for temperature warning alert and
indicates fast laps in lap timer mode.
Lights up for over-temperature alert and
indicates slow laps in lap timer mode.
AMBER LED
CENTER BUTTON

Overview

LCD
SCREEN
RIGHT BUTTON
RED LED
