Defy MAXIMAID 800 DAW 327 Owner's Manual

Smart drive
Hide thumbs
Table of Contents

Advertisement

Quick Links

INDEX
2.
Introduction and special
features
Installation
Unpacking
Transport fittings
3.
Positioning the machine
Connection to the cold water
supply
Connecting the drain hose
Electrical connection
4.
Know your machine
Exterior
Accessories
Detergent drawer
5.
Safety notes
Preparing clothes before
washing
6.
The control panel
Button descriptions
7.
Safety Lock
Operating the machine
8.
Wash programme guide
9.
Cotton programme
10.
Eco programme
11.
Synthetic programme
12.
Delicate programme
13.
Wool programme
14.
Hand wash programme
15.
Quick wash
Spin only
16.
Maintenance
17.
Cleaning
International fabric care labels
18.
Stain removal guide
19.
Problem washing
Trouble shooting
20.
Specifications
Wiring diagram
Owner's responsibility
21.
Defy Service Centres
22.
Warranty
23.
Notes
24.
Purchase details
PAGE 1 OF24
You can rely on Defy. To simplify
OWNER'S MANUAL
MAXIMAID 800
DAW 327(Metallic)
DAW 328 (White)
Automatic Washing Machine
www.defy.co.za

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAXIMAID 800 DAW 327 and is the answer not in the manual?

Questions and answers

France
July 23, 2025

No on at all

0
Peter Goldner
April 13, 2025

Rhd Displayed on machine

0

Related Manuals for Defy MAXIMAID 800 DAW 327

Summary of Contents for Defy MAXIMAID 800 DAW 327

  • Page 1 INDEX Introduction and special features Installation Unpacking Transport fittings You can rely on Defy. To simplify Positioning the machine Connection to the cold water supply Connecting the drain hose OWNER’S MANUAL Electrical connection Know your machine Exterior MAXIMAID 800 Accessories...

  • Page 2: Installation

    Thank you for choosing Defy Congratulations, you have purchased one of the finest and most modern washing machines that today’s technology can produce. This manual will tell you all you need to know about your machine, what it will do and how to do it.

  • Page 3: Positioning The Machine

    Do not connect the machine through a double adaptor. It requires a dedicated power point  If the power cord should ever need replacing, use only a genuine cord ( Type ‘X’) available from the nearest Defy Service Centre. PAGE 3 OF24...

  • Page 4: Know Your Machine

    Know your machine EXTERIOR Inlet hose connected Power cord and plug Detergent drawer connected to a 15A earthed wall socket Control panel Drain hose feeding Door into a dedicated drain pipe or sink Pump cover Adjustable levelling feet ACCESSORIES Inlet hose Manual Plugs DETERGENT DRAWER...

  • Page 5: Safety Notes

    Safety notes  The appliance must be installed and connected in accordance with the manufacturer’s instructions.  The appliance must only be used domestically and for the purposes for which it was designed.  This appliance is not intended for use by persons (including children) with reduced physical, senso- ry or mental capabilities, or lack of experience and knowledge, unless they have been given supervi- sion or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 6: The Control Panel

    The Control Panel POWER ON / OFF  Press this button to switch the power ON or OFF. POWER START / PAUSE  Press this button to start the selected operation. Pressing it once more stops the machine temporarily, allowing changes to a programme to be made. Select the programme, make START / PAUSE the changes and press the start / pause button once more to resume operation.

  • Page 7: Safety Lock

    Safety lock SAFETY LOCK  When activated, the Safety lock prevents accidental operation of the TIME SAVE TIME DELAY machine.  Activating the lock:  Press Time Save and Time Delay buttons simultaneously.  In Safety Lock mode, no other button will function except the Power ON / OFF button.

  • Page 8: Wash Programme Guide

    Wash programme guide PROGRAMME FABRIC TYPE TEMP SELECTABLE MAX. °C OPTIONS* LOAD COTTON MACHINE WASHABLE WHITE PRE-WASH 60°C COTTON, LINEN, TOWLING AND RINSE+ (95°C) BED SHEETS CREASE CARE COLOURFAST GARMENTS. PRE-WASH 40°C SHIRTS, NIGHT DRESSES, (COLD 30°C) RINSE+ LIGHTLY SOILED COTTON AND CREASE CARE (60°C) UNDERWEAR...

  • Page 9: Automatic Selection

    Programmes COTTON PROGRAMME Place the laundry in the wash drum and close the door. Add detergent and softener to the detergent compartment as required. Should you wish to use bleach, add the bleach to the main wash compartment of the de- tergent drawer.

  • Page 10: Eco Programme

    3) Without loading any washing, allow the machine to run through the full cycle. Defy recommends the use of Skip or Omo Auto concentrated liquid detergent when using the ECO programme - these dissolve rapidly and rinse out easily from the clothes.

  • Page 11: Synthetic Programme

    Programmes SYNTHETIC PROGRAMME Place the laundry in the wash drum and close the door. Add detergent and softener to the detergent compartment as required. Should you wish to use bleach, add the bleach to the main wash compartment of the de- tergent drawer.

  • Page 12: Delicate Programme

    Programmes DELICATE PROGRAMME Place the laundry in the wash drum and close the door. Add detergent and softener to the detergent compartment as required. Should you wish to use bleach, add the bleach to the main wash compartment of the de- tergent drawer.

  • Page 13: Wool Programme

    Programmes WOOL PROGRAMME Place the laundry in the wash drum and close the door. Add detergent and softener to the detergent compartment as required. Should you wish to use bleach, add the bleach to the main wash compartment of the de- tergent drawer.

  • Page 14: Hand Wash Programme

    Programmes HAND WASH PROGRAMME Place the laundry in the wash drum and close the door. Add detergent and softener to the detergent compartment as required. Should you wish to use bleach, add the bleach to the main wash compartment of the de- tergent drawer.
  • Page 15 Programmes QUICK 30 PROGRAMME Place the laundry in the wash drum and close the door. Add detergent and softener to the detergent compartment as required. Should you wish to use bleach, add the bleach to the main wash compartment of the de- tergent drawer.

  • Page 16: Maintenance

    Maintenance CLEANING THE DETERGENT DRAWER  To remove residual detergent, pull the dispenser drawer outward, press on the marked area of the siphon, and pull the drawer free.  To facilitate cleaning, the upper part of the fabric softener compartment may be removed. ...

  • Page 17: Cleaning The Exterior

    Cleaning CLEANING THE EXTERIOR  Wipe up any residual detergent , bleach and other spills as they occur.  Periodically wipe the outside of the machine with a damp soft cloth. CLEANING THE INTERIOR  Clean the interior with 250ml of chlorine bleach mixed with 500ml of detergent. ...

  • Page 18: Stain Removal Guide

    Stain removal guide  Stained, heavily soiled or greasy laundry may need to be pre-washed or soaked.  Pre-washing helps loosen soil before washing.  Soaking helps remove protein type stains like blood, milk or grass.  Hot water can set stains and should not be used . ...

  • Page 19: Troubleshooting

    Problem washing—Check list GREASY STAINS ON WASHING  Use more detergent if washing is heavily soiled.  Use both pre-wash and main wash programmes.  Check that the machine is not overloaded. GREY DIRTY LOOKING WASHING  Use more detergent if the washing is heavily soiled or if the machine is located in a hard water area. ...

  • Page 20: Specifications

    Specifications Model DAW327 Dimensions (mm) 595 x 610 x 850 (W x D x H ) Maximum load ( textiles) Machine Weight (Kg.) 54 (Net) / 58 (Gross) Standard water consumption (l) Spin Speed (RPM) 400 / 800 / 1000 / 1400 Operating water pressure 0.03MPa—0.8MPa Wiring Diagram...

  • Page 21: Defy Service Centres

    Service centres If you have followed the instructions and still have a problem, contact the nearest Defy Service Centre. They will be able to advise you on any aspect of the product or send a qualified technician to repair it.

  • Page 22: Warranty

    Warranty This certificate is issued by DEFY APPLIANCES (PTY) LIMITED manufacturers of Defy and Ocean products, hereinafter the Company, to the original purchaser only, of the appliance de- scribed on the certificate and shall constitute the only warranty given in respect of this appliance.

  • Page 23: Notes

    Notes PAGE 23 OF24...
  • Page 24 You can rely on Defy. To simplify OWNER’S MANUAL MAXIMAID 800 DAW 327(Metallic) DAW 328 (White) Automatic Washing Machine The Manufacturer strives for continuous improvements. The content of this book is therefore subject to change without notice. Record in the space below the listed information for future refer- ence.

This manual is also suitable for:

Maximaid daw 328Maximaid 800Daw 327Daw 328
