Elba EC 530 Instruction For The Use - Installation Advice

Elba EC 530 Instruction For The Use - Installation Advice

86x50 cooker; 50x50 cooker
Hide thumbs Also See for EC 530:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
5 5
0 0
x x
5 5
0 0
c c
o o
5 5
0 0
x x
5 5
0 0
c c
EC 530
8 8
6 6
x x
5 5
0 0
c c
8 8
6 6
x x
5 5
0 0
c c
EC 830
Instruction for the use
Installation advice
o o
k k
e e
r r
o o
o o
k k
e e
r r
o o
o o
k k
e e
r r
o o
o o
k k
e e
r r

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EC 530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elba EC 530

Summary of Contents for Elba EC 530

  • Page 1 EC 530 EC 830 Instruction for the use Installation advice...

  • Page 2: Dear Customer

    Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.

  • Page 3: Useful Hints

    USEFUL HINTS FIRST USE THE OVEN After removing the appliance from its packing, make sure of its integrity. In case of doubt, please apply to your It is advised to follow these instruc- supplier or to a qualified engineer. tions: The packing materials (plastic bags, polyfoam, nails, metal strips etc.) must –...
  • Page 4 1 - COOKING HOBS EC 530 Fig. 1.1 EC 830 Fig. 1.2 GAS COOKING HOBS (Fig. 1.1- 1.2) GENEREAL FEATURES: 1. Auxiliary burner (A) - 900 W 2. Semi-rapid burner (SR) - 1550 W 3. Rapid burner (R) - 2550 W...

  • Page 5: Control Panel

    2 - CONTROL PANEL EC 530 Fig. 2.1 EC 830 Fig. 2.2 CONTROLS DESCRIPTION (Figs. 2.1, 2.2) 1. Rear left burner control knob 2. Front left burner control knob 3. Front right burner control knob 4. Rear right burner control knob 5.

  • Page 6: Use Of The Hob Burners

    3 - USE OF THE HOB BURNERS Each burner is controlled by a gas tap LIGHTING OF TOP BURNERS WITH assuring the opening and the closing of ELECTRIC IGNITION the gas supply. Make the symbols printed on the knob - To light the burner turn the knob (fig. to match with the indicator on the con- 3.1) corresponding to the specific bur- trol panel, to obtain:...

  • Page 7: Choice Of The Burner

    CORRECT USE OF CHOICE OF THE BURNER DOUBLE-RING BURNER On the control panel, near every knob, there is a diagram that indicates which The flat-bottomed pans are to be placed burner is controlled by that knob. directly onto the pan-support. The suitable burner must be chosen according to the diameter and the capa- To use the WOK you need to place the...

  • Page 8: General Features

    4 - GAS OVEN OVEN BURNER The glass of the oven door rea- ches high temperatures during It carries out normal “oven cooking”. operation. The gas flow to the burner is regulated Keep children away. by a thermostat which allow to maintain the oven temperature constant.

  • Page 9: Oven Cooking

    IGNITION OF THE OVEN BURNER OVEN COOKING Before introducing the food, preheat the oven to the desired temperature. ATTENTION: Never turn For a correct preheating operation, it is thermostat tap before approaching a advisable to remove the tray from the flame to the hole “A”...

  • Page 10: General Advice

    5 - GENERAL ADVICE * When the appliance is not being used, it is advisable to keep the gas tap clo- sed. From time to time check to make sure that the flexible tube that connects the gas line or the gas cylinder to the appliance is in perfect condition and eventually substitute it, if it shows signs of wearing or damage.

  • Page 11: Installing The Battery

    INSTALLING THE BATTERY Insert a type C battery (1.5 Volt) into the battery compartment on the back of the cooker (fig. 5.1). This battery is the power supply for the electronic ignition of gas burners. Batteries last on average for about two years (alkaline battery) depending on how often the electronic ignition is used.

  • Page 12: Cleaning And Maintenance

    6 - CLEANING AND MAINTENANCE ENAMELLED PARTS GENERAL ADVICE It is advisable to clean when the All the enamelled parts must be cleaned appliance is cold and especially for clea- with a sponge and soapy water or other ning the enamelled parts. non-abrasive products.
  • Page 13 BURNERS, GRATES AND RACKS GAS TAPS These parts may be removed and In the event of operating faults in the washed with suitable products. gas taps, call the Service Department. The burners and their caps must be well dried after cleaning and put back perfec- tly into their slots.

  • Page 14: Installation

    Advice for the installer 7 - INSTALLATION IMPORTANT – Cooker installation and regulation must only be carried out by QUALIFIED TECHNI- CIANS and in compliance with local safety standards. – The surfaces of adjacent furniture and walls must be capable of withstanding tempe- ratures in excess of 75˚C.
  • Page 15 INSTALLATION Gas oven models afford class ‘1’ protection against overheating of surrounding surfaces. A space of at least 2cm must be left between the cooker and any adjacent furniture, which must not exceed the height of the cooktops (fig. 7.1 - 7.2). The walls of the units Fig.
  • Page 16 CHOOSING SUITABLE SURROUNDINGS In the room chosen to accommodate the gas appliance, there must be an adequa- te natural draft to allow combustion of the Extractor hood gas. for products of combustion The flow of air must come directly from one or more openings made in the outside walls with a free area of at least 100 cm...

  • Page 17: Gas Section

    8 - GAS SECTION If the appliance must be operated with The walls adjacent to the cooker a gas different than that indicated on must be of material resistant to heat. the plate, it is necessary to execute the following operations: 1) Gas connection GASES 2) Replacement of the top burner...

  • Page 18: Gas Connection

    Natural gas G 20 - City gas G 110 These operations must be carefully fulfil- led as follows. – Remove the holder “R”. – Connect the cooker to the gas net by a suitable rubber tube (inside diameter 1 - GAS CONNECTION 13 mm).

  • Page 19: Gas Cylinder Connection

    GAS CYLINDER CONNECTION IMPORTANT: Only max 13 kg cylinders may be used The connection between the hose con- in the cylinder compartment, and they nector on the cooker and the regulator must be positioned in such a way that of the gas cylinder must be made using the regulator and shut-off cock are easily a 60 cm long flexible hose conforming accessible.

  • Page 20: Injectors Replacement Of Top Burners

    2 - INJECTORS REPLACEMENT OF TOP BURNERS To replace the injectors, raise the cook- top in the following manner: – Litf the cooking top (fig. 8.5) – Loose the screw “M” of each injector and fully raise the adjusting air tube “A”...
  • Page 21 4 - ADJUSTMENT OF THE MINIMUN OF THE TOP BURNERS Considering that in the minimum position the flame must have a length of about 4 mm and must remain lit even with a bru- sque passage from the maximum posi- tion to that of minimum.
  • Page 22 5 - REPLACEMENT OF THE OVEN 6 - ADJUSTMENT OF THE PRIMARY BURNER INJECTOR AIR OF OVEN BURNER According to the type of gas, the oven With a screwdriver untighten the two injectors are to be similarly replaced, as screws (fig. 8.10 and move forward or stated on the table of the paragraph 2, backward to close or open the air flow, operating as follows:...
  • Page 23 7 - ADJUSTMENT OF THE MINIMUN OF OVEN BURNER – Light the oven taking the knob to posi- tion 10 (max) – remove the knob and by a thin screw- driver (3 mm section - 100 mm long) unscrew of about a half turn the by- pass, passing through the front panel hole (see picture below) –...
  • Page 24 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual neces- sary modifications for their construction or for commercial needs. Cod.
