oticon ConnectLine Instructions For Use

People First People First is our promise
to empower people
to communicate freely,
interact naturally and
participate actively
What's in the box?
Microphone
Power supply (charger)
how the Microphone works
Microphone
up to 15 m
speaker
The Microphone will transmit the speech from the Speaker directly
to the Hearing instrument user.
Note: A Microphone will only work with one Streamer at a time
charging / power indicator
Battery Charge connector
(mini USB)
To charge the microphone, connect the power supply cord to the
mini USB connector placed at the bottom of the microphone.
Pairing / intial setup (only needed once)
1. streamer in pairing mode
6 secs
Press Hold until blue
light flashes
Carry pouch Lanyard
Important This manual
Information
Important product information
A statement that the emission limits for Human Exposure is
fulfilled; Connectline Microphone example:
The emission power from the Connectline Microphone is below
IMPORTANT NOTICE international emission limits for Human Exposure. For comparison,
the radiation of the Connectline Microphone is less than unintended
Please familiarise yourself with the entire contents of this booklet electromagnetic radiation from for example hair dryers, electric
before using your Connectline Microphone. It contains instructions shavers etc. The Connectline Microphone complies with international
and important information about the use and handling of your standards concerning Electromagnetic Compatibility.
Connectline Microphone.
Products complying with R&TTE:
Oticon hereby declares that this Connectline Microphone is in compli- Identification of member states or geographical areas within a mem-
ance with the essential requirements and other relevant provisions of ber state where the device is meant to be used. In original language,
Directive 1999/5/EC. Declaration of conformity is available at: in short form e.g. GB, FR, DE or with pictograms Information about
restrictions of use, if any. In original language. Example: Use of this
device in the UK requires an approval of frequency.
Oticon A/S
Kongebakken 9 USA and Canada
DK-2765 Smørum "Changes or modifications not expressly approved by the party
Denmark responsible for compliance could void the user's authority to operate
www.oticon.com the equipment."
Due to the limited size available on the device, many of the relevant
approval markings are found in this document.
This instrument is certified under:
0682 The device complies with Part 15 of the FCC rules and RSS-210 of
R 202NYLJMS0624458 Industry Canada.
Operation is subject to the following two conditions:
This device may not cause harmful interference. This device must
equipment must be Waste from electronic accept any interference received, including interference that may
handled according to cause undesired operation.
local regulations. N1175
Not a toy ID: U28MIC01
The Connectline Microphone is not a toy and therefore should be IC: 1350B-MIC01
kept out of the reach of children and anyone else who might swallow
parts or otherwise cause injury to themselves. Special attention Changes or modifications made to the equipment not expressly
approved by Oticon may void the FCC's authorisation to operate the
should be paid to the smaller components in order to prevent children equipment.
from swallowing them and choking. If a part is swallowed, see a doc-
tor immediately. Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
Use on aircrafts FCC Rules. These limits are designed to provide reasonable protec-
The Connectline Microphone should not be used onboard aircrafts tion against harmful interference in a residential installation. This
unless specifically permitted by the flight personnel. equipment generates, uses and can radiate radio frequency energy
Implantable devices and, if not installed and used in accordance with the instructions,
The Connectline Microphone is designed to comply with the most may cause harmful interference to radio communications. However,
stringent Standards of International Electromagnetic Compatibility. there is no guarantee that interference will not occur in a particular
installation.
However, Connectline Microphone might cause interference with
other medical devices such as defribillators and pacemakers. Please, If this equipment does cause harmful interference to radio or televi-
contact the manufacturer of your implantable device for information sion reception, which can be determined by turning the equipment
about the risk of disturbance. Interference can also be caused by off and on, the user is encouraged to try to correct the interference
power line disturbances, airport metal detectors, electromagnetic by one or more of the following measures:
fields from other medical devcies, radio signals and eletrostatic
discharges. • Reorient or relocate the receiving antenna.
Do not expose to great heat • Increase the separation between the equipment and receiver.
Never exposure the Connectline Microphone to great heat by putting • Connect the equipment into an outlet on a circuit different from
it in the oven, micro wave oven or burning it. There is a risk that it that to which the receiver is connected.
will explode and cause serious injury. • Consult the dealer or an experienced radio/TV technician for help.
Cleaning for more information see www.oticon.com
Oticon recommends cleaning on a regular basis, using a damp cloth
witout solvents. Do not immerse Connectline Microphone in water or
other liquids.
Only charge from UL/IEC approved equipment
The safety of recharging batteries with the USB connector only is
determined by the external equipment. When the USB connector is
connected to mainsoperated equipment, this equipment should be
UL approved or comply IEC 60950, IEC-60065, IEC-60601 or equiva-
lent safety standards.
Use of the Lanyard
If by accident the lanyard should get caught on something while
wearing it, the lanyard is constructed to release. Therefore, never
try to shorten or modify the lanyard in an unauthorized way. The
lanyard should not be used for children who weights less than 11 kg.
International Warranty
Detailed information as to the nature of the emitted radiation (type,
intensity and distribution), means of protecting the patient and the
user and on ways of avoiding misuse and of eliminating the risks
inherent in installation.
Streamer.
Should always
be worn with
the neck-loop
hearing Instrument user
2. Microphone in pairing mode
Press and hold for 6 seconds until orange
Light flashes rapidly
Page 1
InstructIons For use

Product overview

Status indicator
(orange)
Microphone input
(Voice)
Power indicator
(green)
On off button
Microphone input
(noise detector),
do not cover
clip
wearing
The microphone should point towards the speakers mouth with in a
distance of 10 to 20 cm.
constant
red light
Battery Low
Maximum 20 min.
speaking time left
Orange light is flashing
rapidly in pairing mode
6 secs
MIcroPhone
Wearing with
Lanyard
Blinking constant
green light green light
charging Fully charged
After approx. 1.5 hour.
Will last for 5 hours use
3. Microphone paired
1 min
Wait up to 1 minute until Streamer light
is orange and microphone light is orange
Wrong
wearing
