- Page 1 KOBE Brand Range Hood Model No. RA9436SQF RA9436SQB RA-094 SERIES INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS Important Safety Instructions....................1 Components of Package....................... 3 Installation..........................4 Operation Instructions......................8 Maintenance ......................... 9 Specifications........................10 Measurements & Diagrams....................11 Parts List..........................12 Circuit Diagram........................14 Disclaimer........................... 15 Warranty..........................16 Product Registration...................... -
Page 3: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 4 What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
Baffle Handle – 3 Hood-Mounting Bracket – 2 Screws Package – 1 Screws Package – 1 Item No. AF-9436 (Model No. RA9436SQF) Aluminum Filter – 3 *Attached to Hood... -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate the length of the installation, please refer to Table 1. (All calculations are measured in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended... - Page 7 Preparation before Installation Figure 1 NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. (Figure 1) A straight, short venting run will allow ...
- Page 8 Secure and tighten the mounting screws. Figure 5 CAUTION: MAKE SURE THE HOOD IS SECURE BEFORE RELEASING. Ductwork Installation Using Reference E from Table 1 and measurements on Page 11, mark the leveling point for duct cover-mounting bracket. Secure the duct cover-mounting bracket to the wall with two screws (not provided).
- Page 9 inner duct cover with two (4x8 mm) Figure 9 screws (provided). 12. Fasten outer duct cover to plastic plate on the hood with four (4x8 mm) screws (provided). Install Accessories 13. Place aluminum/baffle filters underneath the hood. Refer to Figure 10. Final Assembly 14.
-
Page 10: Operation Instructions
OPERATION INSTRUCTIONS This KOBE hood is equipped with four electronic controls with a 10-second standby startup & 30- second delay shutoff, one powerful centrifugal squirrel with baffle or aluminum filters, and two bright 12- volt 20-watt halogen lights. The four electronic controls are Light Control, Speed Control A, Speed Control B and the Power Control (On/Off). -
Page 11: Maintenance
To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. Regular care will help preserve your KOBE Range Hood’s fine appearance. 1. Use only mild soap or detergent. Dry surface using a soft cloth. 2. If hood looks splotchy (stainless steel hood), use an orange base cleaner to clean the surface of the hood. -
Page 12: Specifications
SPECIFICATIONS MODEL / SIZE RA9436SQF / 36" (RA-9436 + AF-9436) RA9436SQB / 36” (RA-9436 + BF-9436) COLOR # 304 Commercial Grade Stainless Steel CONSUMPTION / AMPERE 215W / 1.79A VOLTAGE 120V 60Hz NUMBER OF MOTORS DESIGN 18-Gauge Seamless / Satin Finish... -
Page 13: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS Front View Bottom View... -
Page 14: Parts List
PARTS LIST MODEL NO.: RA9436SQF RA9436SQB DESCRIPTION MODEL / SIZE PART NO. Duct Cover-Mounting Bracket C1-0203-0092 Duct Cover RA9236DC B102-0192 Plastic Plate C1-0506-0092 6” round Plastic Exhaust C1-0505-0001 Hood-Mounting Bracket C1-0221-0001 Rubber Stand C1-0510-0101 Hood Casing RA-25900-A Wiring Box C1-0231-2590... - Page 15 MODEL NO.: RA9436SQF RA9436SQB Complete Set: Model No. RA9436SQF – Required RA-9436 & AF-9436 Model No. RA9436SQB – Required RA-9436 & BF-9436...
-
Page 16: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: RA9436SQF RA9436SQB... -
Page 17: Disclaimer
2. PLEASE INSPECT CONTENTS OF PACKAGE (S) CAREFULLY UPON RECEIPT! We must be notified in writing of any damages and/or missing parts within the allocated days upon your receipt of package(s). Contact your local KOBE dealer or distributor or call KOBE for the time limit. -
Page 18: Warranty
WARRANTY WARRANTY CERTIFICATE KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component, which its examination shall disclose to be so defective. - Page 19 Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, which vary from state to state. SERVICE For service, please contact: KOBE Range Hoods, Inc. 4934 Walnut Grove Avenue Suite 202 San Gabriel, CA 91776 U.S.A...
-
Page 20: Product Registration
Any covered failure occurring within two years of original purchase arising from defective workmanship or material in manufacture will be repaired or at our option, replaced free of charge by an authorized KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
