Functional Description

Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may result
in electric shock, fire and/or serious
injury.
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.
Intended Use
The machine is intended for planing of firmly sup-
ported wooden materials, such as beams and
boards. It is also suitable for beveling edges and
rebating.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Planing depth scale
2 Depth adjustment knob
3 Sawdust ejector(0 601 594 037 with two-sid-
ed sawdust ejector)
4 Lock-off button for On/Off switch
(0 601 594 037)
4 Lock-on button for On/Off switch
5 On/Off switch
6 Screw for belt cover
7 Belt cover
8 Planer base plate
9 V-grooves
10 Torx key*
11 Fastening screw for clamping jaw
12 Clamping jaw
13 Blade drum
14 Guide groove for planer blade
15 HSS planer blade
16 HSS planer-blade retainer
17 Fastening screw for HSS planer-blade retainer
18 Sharpening device for HSS planer blade*
19 Setting gauge for HSS planer blade*
20 Carbide blade (TC)
Bosch Power Tools
21 Parallel guide*
22 Scale for rebating width
23 Locking nut for adjustment of rebating width
24 Fastening bolt for parallel and beveling guide
25 Angle stop*
26 Locking nut for angle adjustment
27 Fastening bolt for rebating depth stop
28 Rebating depth stop*
29 Park rest
30 Drive belt
31 Large pulley
32 Small pulley
*The accessories illustrated or described are not in-
cluded as standard delivery.
Technical Data
Planer
Article number
Rated power input
Output power
No-load speed
Planing depth
Rebating depth
Planing width, max.
Weight according to
EPTA-Procedure 01/2003
Protection class
The values given are valid for nominal voltages [U] of
230/240 V. For lower voltage and models for specific
countries, these values can vary.
Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.
English | 9
GHO 10-82
Professional
0 601 594 0..
0 601 594 A..
W
710
W
400
rpm
16500
0 – 1.0
mm
mm
0 – 9
mm
82
kg
2.5
/ II
