PLEASE BE SAFE WHEN RIDING . . .
ALWAYS WEAR A HELMET AND OBEY ALL LAWS!
Powered Personal Transportation
Electric Power Board
Product Handbook
FOR THE BLADEZ XTR SE
ELECTRIC POWER BOARD
Models: PB-SM 816-S
MODEL NUMBER
PB-SM 816
PB-SM 816S
PB-SM 817
PB-SM 816
PB-SM 817
Revised 6/09/05
ACCESSORIES INCLUDED
NONE
SEAT ONLY
SEAT AND BASKET

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB-SM 816-S and is the answer not in the manual?

Questions and answers

Related Manuals for BLADEZ PB-SM 816-S

Summary of Contents for BLADEZ PB-SM 816-S

  • Page 1 Powered Personal Transportation Electric Power Board Product Handbook FOR THE BLADEZ XTR SE ELECTRIC POWER BOARD Models: PB-SM 816-S PB-SM 816 PB-SM 817 Revised 6/09/05 MODEL NUMBER ACCESSORIES INCLUDED PB-SM 816 NONE PB-SM 816S SEAT ONLY PB-SM 817 SEAT AND BASKET PLEASE BE SAFE WHEN RIDING .
