- Page 1 Powered Personal Transportation Electric Power Board Product Handbook FOR THE BLADEZ XTR-COMP II ELECTRIC POWER BOARD Model: PB-SM 818 PLEASE BE SAFE WHEN RIDING . . . ALWAYS WEAR A HELMET AND OBEY ALL LAWS! Page 1...
-
Page 2: Battery Maintenance
DO NOT JUMP or ABUSE THIS PRODUCT! DO NOT RIDE IN WET CONDITIONS! Failure to follow these instruction or abuse will VOID YOUR WARRANTY! If you have any questions, please contact Bladez customer service (866) 325-2339 or visit us on the web at www.ebladez.com Page 2... - Page 3 IMPORTANT PLEASE READ THIS BEFORE USING THIS PRODUCT READ THIS FIRST! WARNING This product does not conform to Federal Motor Vehicle Standards and is not intended for operation on public streets, roads or highways. Serious injury can result from the unsafe operations of this product. Operator can minimize these risks by using certain safety equipment such as: safety helmet, goggles, gloves, elbow and kneepads and appropriate footwear.
- Page 4 ASSISTANCE, PLEASE CALL BLADEZ, TOLL FREE AT: (866) EBLADEZ (866) 325-2339 MONDAY thru FRIDAY, 8am to 5pm PST or visit us on the web at: www.ebladez.com NETWORK OF BLADEZ AND TANAKA SERVICING DEALERS FOR ALL YOUR POWERBOARD NEEDS Page 4...
-
Page 5: Table Of Contents
TABLE OF CONTENTS BATTERY MAINTENANCE………………………………………………………………….. 2 CHARGING INSTRUCTIONS………………………………………………………………… 2 GETTING TO KNOW YOUR BLADEZ POWER BOARD………………………………….6 GETTING STARTED…………………………………………………………………………... 6 FOLDING AND STORAGE………………………………………………………………….. 10 CHARGING SYSTEM…………………………………………………………………………11 RECOMMENDED TOOLS……………………………………………………………………11 BRAKING SYSTEM………………………………………………………………………….. 11 TIRES AND WHEELS………………………………………………………………………...12 ADJUSTING THE HEAD UNIT………………………………………………………………12 CHAIN CARE…………………………………………………………………………………..13 TROUBLESHOOTING GUIDE……………………………………………………………… 14 OTHER QUESTIONS…………………………………………………………………………... -
Page 6: Getting To Know Your Bladez Power Board
GETTING TO KNOW YOUR BLADEZ POWER BOARD Before operating your BLADEZ Power Board, please get acquainted with all of the features: 1. Accelerator Lever (Variable Speed) 10. Rear Mono-Shock Suspension 2. Brake Lever 11. 24V,12AH Batteries 3. Folding Handle 12. DC Charger 4. - Page 7 Installing the Handle Bar Before using your XTR-COMP II, loosen the 4 bolts from the Billet Aluminum Stem with the Allen Wrench provided, and then remove the stem cap as shown in Fig 1. Place handle bar onto the Billet stem with the hole facing down towards the threaded bolt as shown with arrow in Fig 2.
- Page 8 Charging Your XTR-COMP II should come charged out of the box. Bladez still recommends charging the unit for 6-8 hours prior to first use! Bladez also recommends charging your XTR-COMP II after every use and prior to storage. The batteries in the scooter are stored in a bag and are removable.
- Page 9 3. Locate the DC CHARGER and plug it into wall(the red light on the charger will turn on showing you have power). 4. Locate the charging port on the side of the scooter and plug in the charger to the scooter.
-
Page 10: Folding And Storage
Suspension The XTR-COMP II is equipped with a front triple clamp suspension and a rear swing arm single suspension. The suspension is adjusted at the factory and does not need to be adjusted. If you feel the suspension is too soft or stiff please take the scooter to your local service center for adjustment. -
Page 11: Charging System
Once the status light on the charger turns green, your Power Board is now fully charged and ready for use. RECOMMENDED TOOLS To make adjustments and to service the Bladez XTR-COMP II Power Board you will need the following tools: Allen Keys: 3/4/5/6mm. -
Page 12: Tires And Wheels
With continued use, the squeak should go away. TIRES AND WHEELS The Bladez XTR-COMP II uses an identical rim and tires assembly on the front and rear wheels, which means that the tires can be rotated. The wheels are actually two wheel halves (split rim) bolted together to make it easier to remove and replace the tire. -
Page 13: Chain Care
CHAIN CARE Proper chain care will increase the life and improve performance of your Power Board. Always keep the chain lubricated and tightened to the proper tension. Lubrication Always keep the chains lubricated with a good chain spray or grease (not chain wax). If the chain is allowed to run dry for a prolonged period it will fail, and the life of the chain will be severely shortened. -
Page 14: Troubleshooting Guide
If you have any additional questions, please contact Bladez Customer Service Department at (866) 325-2339 Thank you for purchasing a Bladez Power Board and please tell your friends about how much fun you had on the Bladez Power Board. Page 14... - Page 15 Bladez, Corp. 20155 Ellipse Foothill Ranch, CA 92610 Page 15...
