- Page 1 Powered Personal Transportation Electric Power Board Product Handbook FOR THE BLADEZ XTR Street II ELECTRIC POWER BOARD Model: PB-SM1816 PLEASE BE SAFE WHEN RIDING . . . ALWAYS WEAR A HELMET AND OBEY ALL LAWS! Page 1...
-
Page 2: Battery Maintenance
DO NOT JUMP or ABUSE THIS PRODUCT! DO NOT RIDE IN WET CONDITIONS! Failure to follow these instruction and abuse will VOID YOUR WARRANTY! If you have any questions, please contact Bladez customer service (866) 325-2339 or visit us on the web at www.ebladez.com Page 2... - Page 3 IMPORTANT PLEASE READ THIS BEFORE USING THIS PRODUCT READ THIS FIRST! WARNING This product does not conform to Federal Motor Vehicle Standards and is not intended for operation on public streets, roads or highways. Serious injury can result from the unsafe operations of this product. Operator can minimize these risks by using certain safety equipment such as: safety helmet, goggles, gloves, elbow and kneepads and appropriate footwear.
- Page 4 ASSISTANCE, PLEASE CALL BLADEZ, TOLL FREE AT: (866) EBLADEZ (866) 325-2339 MONDAY thru FRIDAY, 8am to 5pm PST or visit us on the web at: www.ebladez.com NETWORK OF BLADEZ AND TANAKA SERVICING DEALERS FOR ALL YOUR POWERBOARD NEEDS Page 4...
-
Page 5: Table Of Contents
TABLE OF CONTENTS BATTERY MAINTENANCE ………………………………………………………………….. 2 CHARGING INSTRUCTIONS………………………………………………………………… 2 GETTING TO KNOW YOUR BLADEZ POWER BOARD………………………………….6 GETTING STARTED…………………………………………………………………………... 6 UNFOLDING INSTRUCTIONS………………………………………………………………..7 QUICK RELEASE DECK………………………………………………………………………8 INTERGRADED SEAT BASE…………………………………………………………………8 BATTERIES……………………………………………………………………………………. 8 MULTI-FUNCTION LED………………………………………………………………………..9 RIDING………………………………………………………………………………………….10 FOLDING AND STORAGE…………………………………………………………………..10 CHARGING SYSTEM…………………………………………………………………………10 RECOMMENDED TOOLS……………………………………………………………………11 BRAKING SYSTEM………………………………………………………………………….. -
Page 6: Getting To Know Your Bladez Power Board
GETTING TO KNOW YOUR BLADEZ POWER BOARD Before operating your BLADEZ Power Board, please get acquainted with all of the features: 1. Accelerator Lever (Variable Speed) 8. 450W Electric Motor 2. Brake Lever 9. Power Panel Charger Plug 3. Folding Handle 10. -
Page 7: Unfolding Instructions
Place handle bar onto the Billet cap with the hole facing down towards the threaded bolt as shown with arrow in (FIG. 2) Fig. 3 Place the Billet Stem on top of the handle bar and the cap and tighten the bolts to secure the handle bar onto the cap as shown in (Fig. -
Page 8: Quick Release Deck
Charging Your XTR-Street II should come charged out of the box. Bladez still recommends charging the unit for 6-8 hours prior to first use! Bladez also recommends charging your XTR-Street II after every use and prior to storage. Warning: DO NOT allow your Powerboard to go into deep discharge! –... -
Page 9: Multi-Function Led
Charging Instructions Charging Fig. 6 1. Make sure the unit is turned OFF. 2. Open the charging plug by rotating the safety cover clockwise as shown by arrow in (Fig. 9) 3. Locate the AC CHARGER and plug it into wall. Insert the charger (the end with the prongs inside of it) into the charging plug. -
Page 10: Riding
RIDING Before going for a joy ride, makes sure that all of the bolts and screws are tightened. Put switch to the ON position, green light will come on indicating the unit is turned on with full charge. (Fig. 11) NOTE: If the unit is at the ON position for over 10- 15 minutes without moving, Smart Power will shut the unit OFF. -
Page 11: Charging System
CHARGING PLUG as described in GET STARTED Charging section. Your Power Board is now fully charged and ready for use. RECOMMENDED TOOLS To adjust and service the Bladez XTR-Street II Power Board you will need the following tools: Allen Keys: 3/4/5/6mm. -
Page 12: Tires And Wheels
With continued use, the squeak should go away. TIRES AND WHEELS The Bladez XTR-Street II uses an identical rim and tires assembly on the front and rear wheels, which means that the tires can be rotated. The wheels are actually two wheel halves (split rim) bolted together to make it easier to remove and replace the tire. -
Page 13: Chain Care
Adjusting the Head Unit The head unit should come adjusted from the factory. However, riding on rough terrain and general use may cause the head unit to become loose over time. It may be necessary to adjust the head unit from time to time. To adjust the head unit: 1. -
Page 14: Troubleshooting Guide
If you have any additional questions, please contact Bladez Customer Service Department at (866) 325-2339 x 1 Thank you for purchasing a Bladez Power Board and please tell your friends about how much fun you had on the Bladez Power Board. - Page 15 Page 15...
