PARTS NAME

Power cord
Plug

CONTROL PANEL

FIX THE OPERATION COVER BY SCREW

If necessary, operation cover can be fi xed by accessary screw.
washer
screw
Louvers
(Air outlet of Plasmacluster Ion)
High density Plasmacluster Ion is discharged
forward. (Do not put anything in front of the unit.)
Plasmacluster Ion Generating Unit
(Inside)
Please open the cover only when replacing the
Plasmacluster Ion Generating Unit.
(See page E-9)
Filter (Air Intake)
* Clean the fi lter periodically.
* Do not block the air intake or do not put
anything into the unit.
FILTER CLEAN Light
UNIT REPLACEMENT Light
HIGH
Fan Speed
MED
Indicator
LOW
OPERATION Button
UNIT RESET Button
Press this button for 3 seconds after replacing
the Plasmacluster Ion Gennerating Unit.
Don't press it for any other purposes.
FILTER RESET Button
After cleaning the fi lter, plug the power cord and
press the FILTER RESET button for 3 seconds.
AUTO RESTART Switch
rubber cover
E-3
(yellow)
(red)
