CR187

Replacement Parts and Accessories

Part No. Description
CH-12
110 Volt AC adapter for CR187 receiver
A-185 Coax Remote, folded-dipole antenna with
coaxial cable
35753
System pouch
A-195RA Helical, flexible ("rubber duckie") antenna
with a 9inch whip and a right angle BNC
connector
A-185-BNC Telescoping 1/4 wave whip on a swiveling
BNC connector

Specifications and Features

Operating Frequencies:
Sensitivity:
Signal/Noise Ratio:
Squelch Quieting:
AM Rejection:
Modulation Acceptance:
Image and Spurious Rejection:
Third Order Intercept:
Audio Outputs:
Antenna Input:
Controls:
Indicators:
Power Requirements:
Power consumption:
Battery Life:
Weight:
Dimensions:
Specifications subject to change without notice.
10
150MHz to 216MHz, crystal controlled
Better than 0.6uV for 20dB quieting without compandor;
1.9uV for 50dB S/N ratio with compandor
102dB A weighted
greater than 100dB
-60dB (10uV to 0.1 Volts)
±15kHz
greater than 100dB
+6dBm
XLR: 200 Ohms balanced; 100mV max.
Headphone: 2 Volts RMS into 100 Ohms
BNC; 50 Ohms impedance
XLR front panel output attenuator control
Recessed trim-pot headphone control
3 position power/function switch
Red LED for power "ON" (Battery status)
2 LEDs for modulation level
"RF" LED for transmitter "ON"
12 Volts DC external (either polarity)
110 VAC via CH-12 AC adapter
Single 9 Volt alkaline battery
55mA
5 hours with alkaline
11 ounces including battery
1.1" x 2.75" x 5.2"
LECTROSONICS, INC.
