Troubleshooting; Cr175 Replacement Parts And Accessories - Lectrosonics CR175 Operating Instructions And Troubleshooting Manual

Before going through the following chart, be sure that you have a good battery in the receiver (or a properly con­
nected AC adapter). The POWER LED should glow brightly.
SYMPTOM
NO POWER LED
NO RF LED
RF LED ON BUT NO SOUND
AND NO MODULATION LEDS
MODULATION LED's ON
BUT NO SOUND

CR175 REPLACEMENT PARTS AND ACCESSORIES

Part No.
CH-12
A-185 Coax
35753
A-195RA
A195S

TROUBLESHOOTING

POSSIBLE CAUSE
1) Receiver switch in "OFF" position
2) Dead or weak battery
3) External 12 Volt power disconnected
4) CH-12 AC adapter disconnected
5) Receiver switch in wrong position for the power
source used
1) Transmitter not turned on
2) Transmitter battery dead
3) No microphone on transmitter (the microphone serves
as the antenna
4) Receiver antenna not connected
1) Transmitter switch in "MUTE"
position
2) Transmitter microphone not connected
3) Microphone switch in "OFF" position
4) Possible malfunction in the audio section of the
transmitter See transmitter manual
5) Check transmitter modulation LEDs for possible
transmitter problem
1) Receiver LEVEL control turned
down.
2) Audio cable disconnected
3) Recorder or sound system off, or not properly adjusted.
Description
110 Volt AC adapter for CR175 receiver
Remote, folded-dipole antenna with coaxial cable
System pouch
Helical, flexible ("rubber duckie")antenna with a 9inch
whip and a right angle BNC connector
Ruber Duckie Antenna
Rio Rancho, NM – USA
Compact Receiver
9
