- Page 1 ® Multi-Channel, Class D, OWNER’S MANUAL >> 70 Watt Amplifier EA-AMP-12D-70A EA-AMP-8D-70A 12 CHANNEL 8 CHANNEL...
- Page 3 SERVICEABLE PARTS INSIDE. The exclamation point within an equilateral triangle is intended REFER SERVICING TO QUALIFIED to alert the user to the presence of important operating SERVICE PERSONNEL. and maintenance (servicing) instructions in the literature accompanying the appliance. pg.3 © 2012 Episode...
-
Page 4: Power Mode
RACK-MOUNTABLE Each Episode amplifier includes an accessory package of rack ‘ears’ that may be attached to the amplifier. The amplifier feet can be easily removed for clean rack mounting. The amplifier chassis and rack ears are NOT designed to support anything other than the amplifier. - Page 5 Allows independent gain for each pair of inputs 4. BRIDGED SWITCH Easily couple two channels together for increased power NOTE: 8-ohm minimum when using bridge mode 5. LINE INPUTS Individual channel inputs for use with multi-channel preamps/ or dedicated sources pg.5 © 2012 Episode...
- Page 6 EA-AMP-70 Installation and Users Manual EA-AMP-8D-70 6. INPUT SWITCH Choose between global inputs and individual inputs for each channel 7. SPEAKER OUTPUTS 8. MASTER POWER SWITCH Disables power to the amplifier 9. POWER MODE SWITCH Sets the amplifiers power mode: On –...
-
Page 7: Speaker Outputs
POSITIONING YOUR EPISODE AMPLIFIER Episode amplifiers are designed to help deliver a great audio experience that makes your music come alive for years to come. However, where you place the amplifier can have a large effect on the performance that you receive and the life of the unit. -
Page 8: Verifying Phase
EA-AMP-70 Installation and Users Manual VERIFYING PHASE When proper polarity is not maintained, the speakers play at the opposite ‘time’ from each other, or out of phase. The result is audio with lack of bass and vocals that sound thin or distant. If during or after calibrating your receiver you suspect the sound is not right and you cannot see any markings on the wire to verify polarity is correct, try this simple test: 1. -
Page 9: Input Selection
Be sure set the volume at a level that does not clip or cause distortion when the volume is at the maximum level. This can cause damage to the speakers and the amplifier. pg.9 © 2012 Episode... - Page 10 EA-AMP-70 Installation and Users Manual EPISODE MULTI-ROOM INSTALLATION ® OUTPUT CD PLAYER RECEIVER OUTPUT INPUT INPUT INPUT OUTPUT IPOD OUTPUT DVD PLAYER ROOM 1 ROOM 2 ROOM 3 ROOM 4 ROOM 5 ROOM 6 GLOBAL A GLOBAL B OUTPUT SONOS...
- Page 11 SWITCHER TUNER INPUT INPUT INPUT INPUT ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 pg.11 © 2012 Episode...
- Page 12 EA-AMP-70 Installation and Users Manual EPISODE HOME THEATER/MULTI-ROOM INSTALLATION ® HOME THEATER RECEIVER SPEAKER SUBWOOFER MULTIROOM OUTPUTS OUTPUT OUTPUT INPUT INPUT INPUT REAR REAR LEFT CENTER RIGHT LEFT RIGHT OUTPUT OUTPUT DVD PLAYER OUTPUT CD PLAYER ROOM 1 ROOM 2...
- Page 13 •The power switch on the back panel must be on. not turn on. •Ensure 12V is present if using the trigger input. Front Power Button •Set the Power Mode Switch to ON. Inoperative For Technical Support, call 1.866.838.5052 pg.13 © 2012 Episode...
-
Page 14: Specifications
*All specifications are subject to change without notice WARRANTY 2-Year Limited Warranty Episode Amplifier Products have a 2-Year Limited Warranty. This warranty includes parts and labor repairs on all ® components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified or disassembled. - Page 16 ® 130213-1420 © 2013 Episode...
