PolyVision eno one Installation Manual

Fixed wall arm
Hide thumbs Also See for eno one:

Advertisement

Quick Links

Fixed Wall Arm
Installation Guide
Part number 2002003-001 Rev A
©2010 PolyVision Corporation
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eno one and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PolyVision eno one

  • Page 1 Fixed Wall Arm Installation Guide Part number 2002003-001 Rev A ©2010 PolyVision Corporation All rights reserved...
  • Page 2: Table Of Contents

    Image location (left to right) ........................23 Image tilt..............................23 Image location (up and down)........................ 24 Image location (up and down)........................ 24 Final check ............................25 Step 14: Install the PolyVision Driver Projector Add-in ................25 Index ................................26 Installation and Operation Guide...
  • Page 3: Overview

    These instructions and any hardware provided by PolyVision are for convenience only and are not an indication of what may be required by your local Code.
  • Page 4: Tools And Supplies

    ēno one Fixed Wall Arm Tools and supplies What comes in the box 1 Wall bracket 2 Breakaway plate 3 Cover 4 Boom arm 5 PJ905 Projector 6 Projector mount and Projector adaptor plate 7 Wall template 8 Quick start guide 9 CD 10 USB Cable 11 Projector power cable...
  • Page 5: Required Items

    • 7/16” (11mm) wrench • #2 Phillips screw driver • Measuring tape • Bubble level • Step ladder • Wall mounting hardware for your wall type and local code • Tape (For temporarily attaching template to the wall) 7/16” PolyVision...
  • Page 6: Suggested Hardware For The Wall Bracket

    ēno one Fixed Wall Arm Suggested hardware for the wall bracket Note: These instructions guide you through installing the wall bracket on wall of a sheetrock, brick, or concrete. Use these instructions as a guideline but install appropriate anchors to secure the wall mounting assembly according to all local codes and protocols.
  • Page 7: Install The Fixed Wall Arm

    1. Using a tape measure, locate and mark the center of the interactive whiteboard. 2. If installing on a sheetrock wall, use a stud finder to locate and mark the position of the wall stud nearest the center mark. PolyVision...
  • Page 8: Step 2: Locate And Mark Fastener Locations On The Wall

    ēno one Fixed Wall Arm Step 2: Locate and mark fastener locations on the wall ēno classic interactive whiteboards Note: Use the wall template provided to assure proper location of the wall mount. Failure to do so will result in difficulty focusing and aligning the projected image. To locate and mark fastener locations on the wall: 1.
  • Page 9: Ēno Click Interactive Whiteboards

    1. Use the wall template (for ēno classic) or wall bracket (for ēno click) to mark the position of the cable exit hole that does align with a wall stud. 2. Drill a hole in the sheetrock at that location. PolyVision...
  • Page 10: Step 3: Fasten The Wall Bracket To The Wall

    ēno one Fixed Wall Arm Step 3: Fasten the wall bracket to the wall To fasten the wall bracket to the wall: 1. Position the wall bracket on the wall matching the marks on the wall with bolt hole locations in the bracket.
  • Page 11: Metal Stud Installation

    2. Bolt either the remaining top two bolt holes or opposite corner locations of the wall bracket assembly to the sheetrock wall using two of the toggle bolts and fender washers or equivalent, as noted on page 7. PolyVision...
  • Page 12: Hollow Concrete/Brick Wall Installation

    ēno one Fixed Wall Arm Hollow concrete/brick wall installation 1. Bolt the wall bracket assembly to the wall on the four corner bolt locations using four of the toggle bolts and fender washers or equivalent, as noted on page 7. Note: Ensure that the top and bottom row of bolt holes on the wall bracket assembly do not sit on top of mortar joints.
  • Page 13: Step 4: Assemble The Boom Arm, Cover, And Breakaway Plate

    To assemble the boom arm, cover, and breakaway plate: 1. Slide the cover onto the boom arm. Ensure that the front of the cover (noted by the PolyVision logo) is facing towards the front foot of the boom as shown below.
  • Page 14: Step 5: Fasten The Breakaway Plate To The Boom Arm

    ēno one Fixed Wall Arm Step 5: Fasten the breakaway plate to the boom arm Caution: Two alternative locations are provided for fastening the boom arm to the breakaway plate. Assure the proper positioning of the boom arm based on whether you are installing with the ēno classic ēno click interactive whiteboard.
  • Page 15: Step 6: Fasten The Boom Arm/Breakaway Assembly To The Wall Bracket

    2. Bolt the breakaway plate to the wall bracket using two ¼” – 20 nylon nuts and two washers provided in the hardware bag. Step 7: Prepare the projector adapter plate Disassemble the projector adapter plate from the projector mount by removing the two thumbscrews as shown below. NOTE: Retain the thumbscrews for use in step 10 PolyVision...
  • Page 16: Step 8: Fasten The Projector Mount To The Boom Arm

    ēno one Fixed Wall Arm Step 8: Fasten the projector mount to the boom arm To fasten the projector mount to the boom arm: 1. Slide the the projector mount onto the boom arm. 2. Align the projector mount so that the bolt is centered in the adjustment slot as shown below. 3.
  • Page 17: Step 9: Fasten The Projector Adapter Plate To The Projector

    2. Fasten the plate to the projector using three thumb screws provided in hardware bag. Two of the screw holes in the projector adapter plate are elongated slots. Assure that the screws are centered in the elongated slots. PolyVision...
  • Page 18: Step 10: Fasten The Projector To The Boom Arm

    ēno one Fixed Wall Arm Step 10: Fasten the projector to the boom arm To fasten the projector to the boom arm: 1. Align the front folded edge of the projector adapter plate with the front keyed section of the projector mount and suspend the projector from the boom arm.
  • Page 19: Step 11: Connect Cables To The Projector And Add The Magnetic Icon Strip To The Whiteboard

    1. Locate one cable tie provided in the hardware bag. 2. Loop the cable tie through the cable tie location provided on the wall bracket. 3. Ensure that a 1” (25mm) loop of excess cable is left for clearance. PolyVision...
  • Page 20: Step 12: Power On The Projector

    4. Secure the cables to the wall bracket. 5. Slide the cover down the boom arm and snap it onto the wall bracket. Ensure that the PolyVision logo is properly oriented as shown below. Step 12: Power on the projector Connect the projector power cord to an AC outlet and press the power button on the projector.
  • Page 21: Projector Adjustment And Driver Installation

    Projector adjustment and driver installation Step 13: Troubleshooting projector focus and alignment Once the projector is powered on and warmed up, a PolyVision splash screen appears automatically on the ēno interactive whiteboard. The following steps describe how to adjust the focus and position of the splash screen if necessary.
  • Page 22: Image Location (Left To Right)

    ēno one Fixed Wall Arm Image location (left to right) To adjust the splash screen location from left to right: 1. Loosen the two exposed projector adaptor plate thumbscrews (see Step 9). 2. Rotate the projector to move the splash screen image. 3.
  • Page 23: Image Location (Up And Down)

    2. Raise the projector boom arm upwards. 3. Ensure that both nuts have been adjusted the same and the boom arm is perpendicular to the wall. 4. Tighten the front nylon nuts (clockwise) to capture the breakaway plate location. PolyVision...
  • Page 24: Final Check

    Step 14: Install the PolyVision Driver Projector Add-in To get started using the PolyVision ēno one fixed wall arm mounting solution for the PolyVision PJ905 projector: 1. Ensure that the PolyVision Driver 2.1 (or newer) has been installed on the teacher’s computer prior to completing the next step.
  • Page 25: Index

    Cable strain relief, 19 Metal stud wall, 6 Cable tie, 19 PJ-905 Projector, 3, 4 Clearance, 7 PolyVision Driver 2.1, 24 Clearance height, 3 Power button, 20 Concrete block or hollow brick wall, 6 Projector adapter plate, 15, 17, 18...
