  • Page 1 INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS DOMINO VITROCERAMIC HOB model DE302HB distributed by DèLonghi Pty Ltd...
  • Page 2: Product Label

    Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.
  • Page 3: Before Using For The First Time

    BEFORE USING FOR THE FIRST TIME • Read the instructions carefully before installing and using the appliance. • After unpacking the appliance, make sure it is not damaged. In case of doubt, do not use the appliance and contact your supplier or a qualified engineer. •...
  • Page 4: Installation

    INSTALLATION CAUTION: This appliance shall only be serviced by authorized personnel. • This appliance is to be installed only by an authorised person according to the cur- rent local regulations and in observation of the manufacturer’s instructions. • Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal injury of damage.
  • Page 5 This cooktop can be built into a working surface 20 to 40 mm thick and 600 mm deep. In order to install the ceramic hob into the kitchen fixture, a hole with the dimensions shown in figure 1 has to be made, keeping in consideration the following: •...
  • Page 6: Fastening The Cooktop

    FASTENING THE COOKTOP Each cooktop is supplied with a set of tabs and screws to fasten it on units with a work- ing surface from 2 to 4 cm deep. The kit includes 4 tabs A and 4 self-threading screws B (fig. 4). •...
  • Page 7: Electrical Section

    ELECTRICAL SECTION IMPORTANT: Installation must be carried out according to the manufacturer's instructions. Incorrect installation may cause harm and damage to people, ani- mals or property, for which the manufacturer accepts no responsibility. Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains.
  • Page 8 Figure 5 REPAIRS Replacing the supply cable Turn the cooktop over and unhook the terminal board cover by inserting a screwdriver into the two hooks “A”. Open the cable gland by unscrewing screw “F”, unscrew the terminal screws and remove the cable. The new supply cable, of suitable type and section, is connected to the termi- nal board following the diagrams...
  • Page 9: Electric Diagram

    ELECTRIC DIAGRAM Figure 8...
  • Page 10: General Features

    VITROCERAMIC HOB Figure 9 FEATURES - Electrical insulation Class I. GENERAL FEATURES 1. Hi-light cooking zone Ø 140 mm - 1200 W 2. Double hi-light cooking zone Ø 180/120 mm - 1700/700 W CONTROL PANEL DESCRIPTION 3. Hotplate 1 control knob 4.
  • Page 11: Important Note

    How to use your Ceramic Hob The ceramic surface of the hob allows a fast transmission of heat in the vertical direc- tion, from the heating elements underneath the ceramic glass to the pans set on it. The heat does not spread in a horizontal direction, so that the glass stays “cool” at only a few centimeters from the cooking plate.
  • Page 12 HI-LIGHT DOUBLE ZONE (fig. 12) The heating element is formed of a 2 coils of resistant material which reaches the work- ing temperature quickly. These zones are controlled by a continuous energy regulator switch (fig. 13). You may choose to use the inner zone only ( ) or the fual dual cooking zone ( The heat intensity can be regulated continuously from “MIN”...
  • Page 13: Residual Heat Indicator

    RESIDUAL HEAT INDICATOR The hob also features a warning lamp which is wired to the cooking zones. When the temperature of a cooking plate is over 60°C, the warning lamp is also lit-up to warn of heat on the surface of the hob. This lamp also stays on after the cooking plates have been switched off to shown that the hob surface is still hot.
  • Page 14: Safety Hints

    SAFETY HINTS SAFETY HINTS Figure 15 • Before you switch the hob on, make • Before you switch the hob on, make sure you know which knob controls the sure you know which touch controls the DISTORTED required cooking zone. We advise you required cooking zone.
  • Page 15: Cleaning And Maintenance

    Cleaning and Maintenance Before you begin cleaning make sure that the hob is switched off. • Remove spillages and other types of incrustations. • Dust or food particles can be removed with a damp cloth. • If you use a detergent, please make sure that it is not abrasive or scouring. Abrasive or scouring powders can damage the glass surface of the hob.
  • Page 16 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs. cod.
