• FRONT CPU (DISPLAY BOARD: IC401)
Pin
Line
No.
Name
LCD contrast control. (segement area)
1
CNT2V
(1–2.3 V)
LCD contrast control. (dot area)
2
CNT1V
(1–2.3 V)
Front CPU Reset.
10
FRES
L=Reset.
19
RITDBK
[RIT/ TX] dial phase-B.
20
RITDAK
[RIT/ TX] dial phase-A.
21
MAINDAK [MAIN] dial phase-A.
22
MAINDBK [MAIN] dial phase-B.
TX LED control.
23
TDS
H=Lights. (While transmitting)
24
BKLV
LCD backlight control. (PWM)
29
DTXD
UART port (TX)
30
DRXD
UART port (RX)
Data output (UART) for the communication
33
LTXD
with the main CPU.
Data input (UART) for the communication with
34
LRXD
the main CPU.
35
DOTK
Ele-key input. (Dot)
36
DSHK
Ele-key input. (Dash)
Headphones connection detect.
37
PHNK
H=Connected.
38
NOTK
[NOTCH] input. (Pull-up)
40
LOCKK
[LOCK] input. (Pull-up)
43
PBCLK
[PBT-CLK] input. (Pull-up)
45
RITCLK
[CLEAR] input. (Pull-up)
46
DTXK
[ TX] input. (Pull-up)
47
FILK
[FILTER] input. (Pull-up)
48
XFCK
[XFC] input. (Pull-up)
49
MENUK
[MENU] input. (Pull-up)
50
RITK
[RIT] input. (Pull-up)
51
F5K
[F-5] input. (Pull-up)
52
F4K
[F-4] input. (Pull-up)
53
F3K
[F-3] input. (Pull-up)
54
F2K
[F-2] input. (Pull-up)
55
F1K
[F-1] input. (Pull-up)
56
NBK
[NB] input. (Pull-up)
57
NRK
[NR] input. (Pull-up)
58
ANTK
[ANT] input. (Pull-up)
59
TUNK
[TUNER] input. (Pull-up)
61
TRAK
[TRANSMIT] input. (Pull-up)
63–
LD7–LD0 LCD segment ports.
70
83
PBT2BK
[PBT] outer dial phase-B.
84
PBT2AK
[PBT] outer dial phase-A.
85
PBT1BK
[PBT] inner dial phase-B.
86
PBT1AK
[PBT] inner dial phase-A.
88
PITCHL
[CW PITCH] dial input.
90
NRL
[NR] dial input.
91
NOTL
[NOTCH] dial input.
92
MUDL
[MIC] Up/Down input.
98–
ASL2–
Analog SW (CD4501) control.
100
ASL0
Description

3-5 VOLTAGE BLOCK DIAGRAM

I/O
DC-IN
HV
13.8V
O
O
I
I
I
I
I
O
O
O
I
O
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
O
I
I
I
I
I
I
I
I
O
3 - 8
H3.3V
H3.3V
"PWRK "
FRONT
REG
CPU
"PWRS"
H14V
SW
+5V
+5V
REG
+1.2V
+3.3V
DC-DC
+3.3V
+1.2V
–8V
+3.3V
–8V
+13.8V
+8V
+8V
REG
+5V
+5V
REG
–12V
DC-DC
FRONT
POWER SW
LOGIC
CIRCUITS
ANALOG
CIRCUITS
