SECTION 2.
• THE VIEW FROM THE BOTTOM OF CHASSIS
VARIABLE
CAPACITORS
YGR AMP
(IC201)
PRE-AMP
(Q532)
BPF UNIT
PRE-AMP
(Q511, Q512)
5 V REGULATOR
(IC121)
SERIAL-PARALLEL
CONVERTER
(IC103)
SERIAL-PARALLEL
CONVERTER
(IC104)
1ST TX/RX LO FILTER
(FI401)
PLL IC
(IC201)
LEVEL CONVERTER
(IC353)
32 MHz REFERENCE
FREQUENCY
OSCILLATOR
(X151)
INSIDE VIEWS
PROGRAMMABLE
CLOCK GENERATOR
(IC662)
8 V REGULATOR
(IC124)
NETWORK UNIT
BPF UNIT
CONNECT UNIT
PLL UNIT
3.3 V REGULATOR
(IC122)
2 - 1
VCA
AF LPF
(IC301)
(IC211)
USB HUB
(IC902)
USB CODEC
(IC551)
USB BRIDGE
(IC901)
BUS BUFFER
(IC901)
