• THE LOCATION OF ADJUST/CHECK POINTS ON THE RF-A UNIT
IMAGE REJECTION
Adjust point
RX SENSITIVITY
Adjust point
TX POWER
Adjust point
RX SENSITIVITY
Adjust point
MP1101
EP913
EP911
L723
R1276
C1121
MP1201
MP651
P
4 - 5
IMAGE REJECTION
Adjust point
J501
TO BPF
MIXER BALANCE/
RX SUPRIOUS
Adjust points
