• MAIN UNIT
(TOP VIEW)
D/A CONVERTER
(IC3204)
3RD TX IF MIXER
(IC3621)
AGC BUFFER
(IC4601)
VOX BUFFER
(IC4403)
MAIN CPU
(IC1201)
CI-V LINE BUFFER
(IC1001)
MAIN CPU
(IC1201)
TX POWER LEVEL BUFFER
(IC1163)
CPLD
(IC1261)
2 - 3
DC-DC CONVERTER
(IC2001, D2001, D2002)
S/P CONVERTER
(IC3201)
DC AMP
(IC3271)
CURRENT AMP
(IC3251)
DC AMP
(IC3675)
AGC LEVEL DETECT
(IC3532)
VCA
(IC3401)
VOX LPF
(IC3452)
CODEC IC
(IC4461)
DSP
(IC4001)
EEPROM
(IC4202)
