- Page 1 4-090-076-12 (1) Data Projector Operating Instructions Mode d’emploi Manual de instrucciones VPL-CS5 VPL-CX5 © 2002 Sony Corporation...
- Page 2 To prevent fire or shock hazard, do Trade Name: SONY not expose the unit to rain or Model No.: VPL-CS5/VPL-CX5 moisture. Responsible Party: Sony Electronics Inc. Address: 680 Kinderkamack Road, Oradell, To avoid electrical shock, do not NJ 07649 U.S.A. open the cabinet. Refer servicing to Telephone No.: 201-930-6972...
- Page 3 For the customers in Canada This Class B digital apparatus complies with Canadian ICES-003. Voor de klanten in Nederland Gooi de batterij niet weg maar lever deze in als klein chemisch afval (KCA). The socket-outlet should be installed near the equipment and be easily accessible.
-
Page 5: Table Of Contents
Table of Contents The INSTALL SETTING Menu ..34 Overview The INFORMATION Menu .... 35 Precautions .........6 Notes on Installation ......7 Maintenance Unsuitable Installation ....7 Unsuitable Conditions ....7 Maintenance ........36 Features ..........8 Replacing the Lamp ....36 Location and Function of Controls .10 Cleaning the Air Filter .... -
Page 6: Overview
Overview light-reflecting material. If the floor and Precautions walls are of reflecting material, it is recommended that the carpet and wall paper be changed to a dark color. On safety On preventing internal heat build- • Check that the operating voltage of your unit is identical with the voltage of your local power supply. -
Page 7: Notes On Installation
internal heat of the projector. Clean it up Notes on Installation periodically. Unsuitable Installation Do not install the projector in the following situations. These installations may cause malfunction or damage to the projector. Poorly ventilated Unsuitable Conditions Do not use the projector under the following conditions. -
Page 8: Features
(VPL-CX5) or 1800 ANSI lumen (VPL-CS5). automatically or manually................................1) The SXGA and SXGA+ signals are 3) The VPL-CS5 is preset for 25 kinds of input available for the VPL-CX5 only. signals. 2) NTSC is the color system used when 4) The application software (Projector Station) 4.43... - Page 9 800 × 600 dots (horizontal/ vertical) for RGB input, and 600 horizontal TV lines for video input. Quiet operation Because the projector uses Sony’s unique cooling mechanism, it operates more quietly. High portability • Light weight/small size/simple design This projector has been miniaturized to approx.
-
Page 10: Location And Function Of Controls
1 I / 1 (on/standby) key Location and Turns on and off the projector when the projector is in standby mode. The ON/ Function of Controls STANDBY indicator around the I / 1 key lights in green when the power is turned on. - Page 11 5 Lens protector (lens cover) How to use the powered tilt The lens protector automatically opens adjuster when the power is turned on. To adjust the height 6 Front remote control detector Adjust the height of the projector as follows: 7 Ventilation holes (exhaust) Press the The lens protector opens, and the...
-
Page 12: Control Panel
5 TEMP (Temperature)/FAN Control Panel indicator Lights up or flashes under the following conditions: – Lights up when temperature inside the projector becomes unusually high. POWER SAVING – Fashes when the fan is broken. INPUT A MENU PUSH For details, see page 41. ENTER ACCESS AUDIO... -
Page 13: Remote Commander
control the mouse function with the Remote Commander supplied Remote Commander. The supplied application software (VPL- The keys that have the same names as those CX5 only) can be installed in the on the control panel function identically. computer attached to this connector. 3 Memory Stick slot (VPL-CX5 only) The Memory Stick can be inserted. - Page 14 • You can cancel the adjustment by For details, see “To connect an IBM PC/ AT compatible computer” on page 18”. pressing the APA key again while “Adjusting” appears on the screen. 7 RESET key • The picture may not be adjusted properly Resets the value of an item back to its depending on the kinds of input signals.
- Page 15 To install batteries Push and slide to open the lid, then install the two size AA (R6) batteries (supplied) with the correct polarity. While pressing the lid, slide it. Be sure to install the battery from the side. Replace the lid. Notes on batteries •...
-
Page 16: Setting Up And Projecting
Setting Up and Projecting Installing the Projector This section describes how to install the projector. The distance between the lens and the screen varies depending on the size of the screen. Use the following table as a guide. Distance between the screen and the center of the lens Unit: m (feet) Screen size... -
Page 17: Connecting The Projector
• The projector accepts VGA, SVGA, XGA, SXGA (VPL-CX5 only) and SXGA+ (VPL-CX5 only) signals. However, we recommend that you set the output mode of your computer to XGA mode (VPL-CX5) or SVGA mode (VPL-CS5) for the external monitor. • If you set your computer, such as a notebook type, to output the signal to both your computer’s display and the external monitor, the picture of the external monitor may... - Page 18 To connect an IBM PC/AT compatible computer Left side Computer POWER SAVING INPUT A MENU to monitor output PUSH ENTER ACCESS AUDIO VIDEO S VIDEO TEMP/FAN LAMP/COVER HD D-sub 15-pin cable (supplied) to audio output Stereo audio connecting cable (not supplied) USB cable (supplied) (Connect the USB cable to use a wireless to USB connector...
-
Page 19: Connecting With A Vcr Or 15K
Connecting with a VCR or 15k RGB/Component Equipment This section describes how to connect the projector to a VCR and 15k RGB/ component equipment. For more information, refer to the instruction manuals of the equipment you are connecting. To connect a VCR Left side Video cable (not supplied) or S-Video cable POWER... - Page 20 To connect a 15k RGB/Component equipment SMF-402 Signal Cable Left side (not supplied) HD D-sub 15-pin (male) ↔ 3 × phono jack POWER SAVING INPUT A MENU Stereo audio connecting cable PUSH ENTER ACCESS AUDIO VIDEO S VIDEO (not supplied) TEMP/FAN LAMP/COVER to RGB/...
-
Page 21: Selecting The Menu Language
Selecting the Menu Language You can select one of nine languages for displaying the menu and other on- screen displays. The factory setting is English. To change the menu language, proceed as follows: Front remote control detector POWER I / 1 FREEZE MS SLIDE SAVING... - Page 22 Press the M or m key to select the MENU SETTING menu, then press the , or ENTER key. The selected menu appears. I n p u t A Press the M or m key to select “Language,” then press the , or ENTER key.
-
Page 23: Projecting
Projecting Rear remote control detector I / 1 FREEZE MS SLIDE KEYSTONE INPUT TILT MENU ENTER MUTING ON/STANDBY indicators Open the connector panel, plug the AC power cord into a wall outlet, then connect all equipment. The ON/STANDBY indicator lights in red and the projector goes into standby mode. - Page 24 Press the INPUT key to select the input source. To input from Press INPUT to display Computer connected to the INPUT A connector INPUT A Memory Stick inserted to the Memory Stick slot Video equipment connected to the VIDEO input VIDEO connector Video equipment connected to the S VIDEO input...
- Page 25 Note The auto keystone adjustment may not correct the trapezoidal distortion perfectly, depending on the room temperature or the screen angle. In this case, adjust it manually. Press the KEYSTONE key on the Remote Commander until “V Keystone” appears on the screen, and adjust the value with the M/m/</, key.
- Page 26 To turn off the power Press the I / key. “POWER OFF? Please press I / 1 key again.” appears to confirm that you want to turn off the power. Note A message disappears if you press any key except the I / 1 key, or if you do not press any key for five seconds.
-
Page 27: Effective Tools For Your Presentation
Effective Tools for Your Presentation To enlarge the image (Digital Zoom function) You can select a point in the image to enlarge. This function works when a signal from a computer is input, or when a still picture (except a movie picture) stored in a Memory Stick is projected (VPL-CX5 only). -
Page 28: Adjustments And Settings Using The Menu
Adjustments and Settings Using the Menu Press the MENU key. Using the MENU The menu appears. The menu presently selected is shown as a yellow button. The projector is equipped with an on-screen SET SETTING Input A menu for making various adjustments and settings. -
Page 29: The Picture Setting Menu
Make the setting or adjustment on an The PICTURE item. • When changing the adjustment level: SETTING Menu To increase the number, press the key. To decrease the number, press the m The PICTURE SETTING menu is used for or < key. adjusting the picture or volume. - Page 30 Gamma Mode Adjust Picture... Menu Items Selects a gamma correction curve. The unit can store the setting values of the Graphics: Improves the reproduction of following sub menu items for each halftones. Photos can be reproduced in “Dynamic” or “Standard” picture mode natural tones.
-
Page 31: The Input Setting Menu
(VPL- APA key. CX5). Adjust the picture to where it looks clearest. • When SVGA or XGA signal is input, this item will not be displayed (VPL-CS5). The INPUT SETTING Menu... -
Page 32: The Set Setting Menu
The following are for the VPL-CX5 only. Macintosh 21" 1456 1) The APA (Auto Pixel Alignment) automatically adjusts “Dot Phase,” “H Size” Sony News 1708 and “Shift” in the INPUT SETTING menu PC-9821 1600 for the input signal from a computer. -
Page 33: The Menu Setting Menu
indicates the input channel when the power The MENU SETTING is turned on or the INPUT key is pressed. Menu Input-A Signal Sel. Selects the computer, component or video GBR signal input from the INPUT A The MENU SETTING menu is used for connector. -
Page 34: The Install Setting Menu
Image Flip The INSTALL Flips the image on the screen horizontally SETTING Menu and/or vertically. Off: The image does not flip. HV: Flips the image horizontally and The INSTALL SETTING menu is used for vertically. changing the settings of the projector. H: Flips the image horizontally. -
Page 35: The Information Menu
The INFORMATION Menu The INFORMATION menu displays the horizontal and vertical frequencies of the input signal and the used time of the lamp. I N F O R M AT I O N I n p u t A Memory number of f H : 4 8 . -
Page 36: Maintenance
Bottom Screws on the lamp (3) Notes • If the lamp breaks, consult with qualified Sony personnel. • Pull out the lamp by holding the handle. If you touch the lamp, you may be burned or injured. • When removing the lamp, make sure it remains horizontal, then pull straight up. -
Page 37: Cleaning The Air Filter
Insert the new lamp all the way in until Cleaning the Air Filter it is securely in place. Tighten the screws. Fold the handle. The air filter should be cleaned every 300 hours. Remove dust from the outside of the ventilation holes with a vacuum cleaner. - Page 38 Remove the air filter. Wash the air filter with a mild detergent solution and dry it in a shaded place. Attach the air filter and replace the cover. Notes • If you neglect to clean the air filter, dust may accumulate, clogging it. As a result, the temperature may rise inside the unit, leading to a possible malfunction or fire.
-
Page 39: Troubleshooting
Troubleshooting If the projector appears to be operating erratically, try to diagnose and correct the problem using the following instructions. If the problem persists, consult with qualified Sony personnel. Power Symptom Cause and Remedy The power is not turned on. • The power has been turned off and on with the I / 1 key at a short interval. - Page 40 Symptom Cause and Remedy “Please check INPUT-A • Setting of “Input-A Signal Sel.” in the SET SETTING menu is setting.” appears in spite of incorrect. c Select “Computer,” “Video GBR” or “Component” correctly inputting the correct signal from INPUT A. according to the input signal (see page 33).
-
Page 41: Warning Messages
Wait for 90 seconds to cool down the lamp and turn on the power again (see page 26). The TEMP/FAN indicator • The fan is broken. c Consult with qualified Sony personnel. flashes. The TEMP/FAN indicator • The internal temperature is unusually high. -
Page 42: Caution Messages
Caution Messages Use the list below to check the meaning of the messages displayed on the screen. Message Meaning and Remedy Not applicable! • You have pressed the wrong key. c Press the appropriate key. Troubleshooting... -
Page 43: Other
VPL-CX5: 750 horizontal TV Specifications lines (Video input) 1,024 × 768 dots (RGB input) Acceptable computer signals VPL-CS5: fH: 19 to 72 kHz Optical characteristics fV: 48 to 92 Hz Projection system VPL-CX5: fH: 19 to 92 kHz 3 LCD panels, 1 lens, projection... -
Page 44: Optional Accessories
For details, please consult your nearest NEMKO (EN60950), CE Sony office. (LVD, EMC), C-Tick 1) VPS-50C may not be available in some areas. General For details, please consult your nearest Sony 285 × 68 × 228 mm (11 × Dimensions office. × 9 inches) (w/h/d) -
Page 45: Input Setting Menu
H Size – – – – Shift – – – – Scan – – – – Converter (VPL-CS5: lower than VGA, VPL-CX5: lower than SVGA) Wide – Mode z : Adjustable/can be set – : Not adjustable/cannot be set Specifications... - Page 46 Preset signals Memory Preset signal fH (kHz) fV (Hz) Sync SIZE Video 60 Hz 15.734 59.940 Video 50 Hz 15.625 50.000 15k RGB/Component 60 Hz 15.734 59.940 S on G/Y or Composite Sync 15k RGB/Component 50 Hz 15.625 50.000 S on G/Y or Composite Sync 640 ×...
- Page 47 63.981 60.020 H-pos, V-pos 1685 Memory No. 1 to No. 26 (VPL-CS5) Memory No. 1 to No. 38, No. 52 (VPL-CX5) Notes • Whan a signal other than the preset signals shown above is input, the picture may not appear properly.
-
Page 48: Index
notes ......7 Precautions ....... 6 Index unsuitable conditions ..7 unsuitable installation .. 7 Remote Commander ..13 location and function of Adjusting Lamp Mode ....34 controls ....13 memory of the settings 29 Lamp replacement ..36 Remote control detector the picture ....29 Lamp Timer ....
