Introduction to Your
New Mitsubishi Electric
Ecodan System
This booklet has been created to enable you to quickly personalise the
Heating System controls to provide the best operation conditions for your
home. If you require more in depth information and system settings
please refer to the instruction booklet provided with the cylinder unit.
Your heating system consists of:
Air Source
Heat Pump
(Located outside)
Heating and Hot Water
Control Panel
Cylinder Unit
