DigitalBox IMPERIAL HD 2 basic Installation Manual page 27

8. USING RECEIVER
Now follow these steps: TP List submenu.
Press the green function key on your
remote control. The „Add TP" screen
opens.
Enter a frequency of 10836 using the
number keys (0-9) on the remote control.
Enter a symbol rate of 22000 using the
number keys (0-9) on the remote control.
Set the polarisation H for horizontal using
the and buttons.
Save your entries by confirming the „Save"
screen with OK.
The transponder you have just created is
now added to the end of the transponder list
for ASTRA 19.2° East and appears accord-
ingly on the transponder list.
Press the blue function key on your
remote control. The „ TP Search" screen
opens.
Set the search filters described above.
Start the search by confirming the „OK"
screen with the OK button.
The search results are added to the end
of the general satellite list. The procedure
is now finished.
27 DVB-S Receiver
GB
