AXIOMTEK IFO2225-851 Series User Manual

22” tft fanless touch panel computer with intel○r coretm 2 duo processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IFO2225-851 Series
22" TFT Fanless Touch Panel Computer
TM
○
with Intel
Core
2 Duo Processor
R
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IFO2225-851 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMTEK IFO2225-851 Series

Summary of Contents for AXIOMTEK IFO2225-851 Series

  • Page 1 IFO2225-851 Series 22” TFT Fanless Touch Panel Computer ○ with Intel Core 2 Duo Processor User’s Manual...
  • Page 2 AXIOMTEK does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document. AXIOMTEK does not make any commitment to update the information in this manual.

  • Page 3: Safety Approvals

    Safety Approvals CE Marking FCC Class A FCC Compliance This equipment has been tested in compliance with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are meant to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Safety Precautions

    Safety Precautions Before getting started, read the following important safety precautions. The IFO2225-851 Series does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer. Be sure to ground yourself to prevent static charge when installing the internal components.

  • Page 5: Classification

    input/out or other connectors shall comply with relevant UL/IEC standard. 11. Do not open the system’s back cover. If opening the cover for maintenance is a must, only a trained technician is allowed to do so. Integrated circuits on computer boards are sensitive to static electricity.

  • Page 6: General Cleaning Tips

    General Cleaning Tips You may need the following precautions before you begin to clean the computer. When you clean any single part or component for the computer, please read and understand the details below fully. When you need to clean the device, please rub it with a piece of dry cloth.
  • Page 7 Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas in your keyboard, mouse, and other locations. Foam swabs: Whenever possible it is better to use lint free swabs such as foam swabs. Note We strongly recommended that you should shut down the system before you start to clean any single components.

  • Page 8: Scrap Computer Recycling

    If the computer equipments need the maintenance or are beyond repair, we strongly recommended that you should inform your Axiomtek distributor as soon as possible for the suitable solution. For the computers that are no longer useful or no longer work well, please contact your Axiomtek distributor for recycling and we will make the proper arrangement.

  • Page 9: Table Of Contents

    Table of Contents Disclaimers ................ii Safety Approvals..............iii Safety Precautions..............iv Classification ..............v General Cleaning Tips ............vi Scrap Computer Recycling ..........viii CHAPTER 1 INTRODUCTION ........1 General Description ..........1 Features.............. 2 System Specifications......... 2 Dimensions ............5 I/O Outlets............6 Packing List ............
  • Page 10 Exit Menu............60 CHAPTER 4 DRIVER INSTALLATION ......62 System.............. 62 Touch Screen ........... 63 4.2.1 Specification.............. 63 4.2.2 Driver Installation ............64...
  • Page 11 MEMO...

  • Page 13: Chapter 1 Introduction

    IFO2225-851 Series User’s Manual CHAPTER 1 INTRODUCTION This chapter contains general information and detailed specifications of the IFO2225-851 Series. Chapter 1 includes the following sections: General Description Features System Specification Dimensions I/O Outlets Package List General Description The IFO2225-851 is an ultra slim panel computer equipped with 22- inch 300nits high brightness WSXGA+ LCD display and supports ○...

  • Page 14: Features

    IFO2225-851 Series Panel PC User’s Manual Features 22” ( 300nits) WSXGA+ TFT LCD ® ○ Fanless socket P Intel Core 2 Duo or Intel Celeron M processor Spill and dust resistant design (front panel: IP65, whole enclosure: IPX1) Optional 1 PCI or PCIe x 4 expansion slot Built-in 1.3 mega pixels camera...
  • Page 15 IFO2225-851 Series User’s Manual ○ Intel Core 2 Duo processor up to 2.53 GHz with FSB 667/800/1067MHz ® CHIPSET INTEL GM/GL45+ICH9M SYSTEM SUPPORTS 2 DDR3 SODIMM MAIN SYSTEM MEMORY MEMORY UP TO 8 GB 1 x 2.5" SATA HDD DRIVE BAY...
  • Page 16 IFO2225-851 Series Panel PC User’s Manual OPERATION TEMPERATURE: 0ºC~40ºC (32ºF~104ºF) ENVIRONMENTA RELATIVE HUMIDITY: 10%~95%, NON- CONDESING SHOCK: 10G PEAK ACCELERATION (11 SEC. DURATION) CERTIFICATION CE, FCC classB, EN6060101, UL60601-1 NOTE All specifications and images are subject to change without notice.

  • Page 17: Dimensions

    IFO2225-851 Series User’s Manual Dimensions The following diagrams show you dimensions and outlines of the IFO2225-851 Series. Introduction...

  • Page 18: I/O Outlets

    IFO2225-851 Series Panel PC User’s Manual I/O Outlets The following figures show you the locations of the IFO2225-851 Series I/O outlets. ○ 1 ○ 2 ○ 3 Introduction...
  • Page 19 IFO2225-851 Series User’s Manual I/O Outlets CONNECTOR BRIGHTNESS ADJUST BUTTONS VOLUME ADJUST BUTTONS POWER LED COM 2 (RS-232) COM 1 (RS-232/422/485) ETHERNET X 2 USB 2.0 X 2 Audio (Line-out / Mic-in) Power connector PCI or PCIe slot USB 2.0 X 2...

  • Page 20: Packing List

    IFO2225-851 Series Panel PC User’s Manual Packing List The package bundled with your IFO2225-851 Series should contain the following items: IFO2225-851 Series Unit x 1 AC-DC Power Adaptor Power Cord x 1 CD x 1 (For Driver and User’s Manual)
  • Page 21 IFO2225-851 Series User’s Manual MEMO Introduction...

  • Page 22: Chapter 2 Hardware Installation

    IFO2225-851 Series Panel PC User’s Manual CHAPTER 2 HARDWARE INSTALLATION The IFO2225-851 Series are convenient for your various hardware configurations, such as CPU (Central Processing Unit) and HDD (Hard Disk Drive). The chapter 2 will show you how to install the hardware. It...
  • Page 23 IFO2225-851 Series User’s Manual Step 3 Please open the back cover by lifting the joint part as marked. Step 4-1 Open the back cover and find main board and locate the SO-DIMM socket and CPU cooler. Hardware Installation...
  • Page 24 IFO2225-851 Series Panel PC User’s Manual Step 5-1 Release these screws as marked. Step 5-2 Align pins of the CPU with pin holes of the socket. Be careful of the CPU’s orientation that you need to align the arrow mark on the CPU with the arrow key on the socket.
  • Page 25 IFO2225-851 Series User’s Manual Step 5-3 Place the heat sink on the CPU, and lock it down as marked. Step 6-1 Push down latches on each side of the SO-DIMM socket. Hardware Installation...
  • Page 26 IFO2225-851 Series Panel PC User’s Manual Step 6 Install the memory module into the socket and push it firmly down until it is fully seated. The socket latches are levered upwards and clipped on to the edges of the SO-DIMM.

  • Page 27: Hard Disk Drive Installation

    IFO2225-851 Series User’s Manual Hard Disk Drive Installation The IFO2225-851 Series offers a convenient drive bay module for users to install HDD. The system offers users one 2.5” Hard Disk Drive for installation. Please follow the steps: Step 1 Turn off the system, and unplug the Power cord.
  • Page 28 IFO2225-851 Series Panel PC User’s Manual Step 3 Please open the back cover by lifting the joint part as marked. Step 4 Find the HDD bracket on accessory package and fine HDD socket on main board as marked. Hardware Installation...
  • Page 29 IFO2225-851 Series User’s Manual Step 5 Use assembly parts to fix HDD with the bracket. HDD Bracket x1 2.5 inch Hard-disk Screw x 4 Fix four screw holes on the bracket, and assembly the HDD with the bracket. ATTENTION Please follow the direction of Hard-disk installation.
  • Page 30 IFO2225-851 Series Panel PC User’s Manual Step 6 Install the HDD bracket inside the system. Plug the HDD in the SATA connector on main board. Step 7 Fix two screw holes on main board as marked. Hardware Installation...
  • Page 31 IFO2225-851 Series User’s Manual Step 8 Close the back cover to the chassis, and fasten all screws. Hardware Installation...

  • Page 32: Cf Card Installation

    IFO2225-851 Series Panel PC User’s Manual CF Card Installation The IFO2225-851 series provides one CF slot for users to install ™ CompactFlash card. Please refer to the following instructions for installation: Step 1 Turn off the system, and unplug the Power cord.
  • Page 33 IFO2225-851 Series User’s Manual Step 3 Please open the back cover by lifting the joint part as marked. Step 4 Locate the CompactFlash socket, and insert the card into the socket. Hardware Installation...
  • Page 34 IFO2225-851 Series Panel PC User’s Manual Step 5 Close the back cover to the chassis, and fasten all screws. Hardware Installation...

  • Page 35: Serial Ports Interface

    IFO2225-851 Series User’s Manual Serial Ports Interface The IFO2225-851 series has three serial ports, COM1 (RS-232/ 422/ 485) and COM2 / COM3 (RS-232). The following table shows you the pin assignments of this connector: Signal Signal Data Carrier Detect (DCD)
  • Page 36 IFO2225-851 Series Panel PC User’s Manual When COM1 is set to RS-422 or RS-485, the pin assignments are listed below: Signal Name Pin # RS-422 RS-485 DATA- DATA+ No connector No connector No connector No connector No connector No connector...

  • Page 37: Wireless Module Installation (Optional)

    IFO2225-851 Series User’s Manual Wireless Module Installation (Optional) You can follow the steps below to install an optional wireless module. Step 1 Turn off the system, and unplug the Power cord. Step 2 Locate and release these screws to open the back cover.
  • Page 38 IFO2225-851 Series Panel PC User’s Manual Step 3 Please open the back cover by lifting the joint part as marked. Step 4 Open the back cover and find main board. Hardware Installation...
  • Page 39 IFO2225-851 Series User’s Manual Step 5 The socket latches are clipped on to the edges of the Mini card. Install wireless LAN card to the socket. ○ ○ Step 6 Find the built-in Antenna cable which is tied with other cables on the bottom of the device.
  • Page 40 IFO2225-851 Series Panel PC User’s Manual Step 7 Close the back cover to the chassis, and fasten all screws. Hardware Installation...

  • Page 41: Add-On Card Installation (Optional)

    IFO2225-851 Series User’s Manual Add-on card Installation (Optional) You can follow the steps below to install an optional add-on card. Step 1 Turn off the system, and unplug the Power cord. Step 2 Locate and release these screws to open the back cover.
  • Page 42 IFO2225-851 Series Panel PC User’s Manual Step 3 Please open the back cover by lifting the joint part as marked. Step 4 Release the screw as marked. And remove plates. Hardware Installation...
  • Page 43 IFO2225-851 Series User’s Manual Step 5 Insert the add-on card in the socket firmly until it is completely seated. Step 6 Fasten the screw as marked Hardware Installation...
  • Page 44 IFO2225-851 Series Panel PC User’s Manual Step 7 Close the back cover to the chassis, and fasten all screws. Hardware Installation...

  • Page 45: Mount

    IFO2225-851 Series User’s Manual Mount There are several mounting ways for the IFO2225-851 Series, Wall mount, VESA and Desktop mountings as below: 2.6.1 Wall mount The mounting for IFO2225-851 Series is Wall mount as below: Step 1 Prepare all parts for installing the wall mount kit.

  • Page 46: Vesa Mount

    IFO2225-851 Series Panel PC User’s Manual 2.6.2 VESA Mount The mounting for IFO2225-851 Series is VESA-Arm as below: Assemble the VESA-Arm by using screws to fix the backplane. Hardware Installation...

  • Page 47: Desktop Stand (Optional)

    IFO2225-851 Series User’s Manual 2.6.3 Desktop Stand (Optional) The IFO2225-851 Series provides you with an optional Desktop Stand that you can follow the steps below: Step 1 Prepare the parts of desktop stand. Screw A Screw B Screw C Hinge Cover...
  • Page 48 IFO2225-851 Series Panel PC User’s Manual Step 2 Assemble the desktop stand. Fix the screws as marked on the bottom side of chassis. (Use Screw A) Step 3 Assemble the desktop stand by fixing it onto the system. (Use Screw B).
  • Page 49 IFO2225-851 Series User’s Manual Step 4 Assembly the hinge cover and fix the screws as marked on the back side of chassis (Use Screw C). Step 4 Fix the desktop stand finish. Rear View Hardware Installation...
  • Page 50 IFO2225-851 Series Panel PC User’s Manual Front View Hardware Installation...
  • Page 51 IFO2225-851 Series User’s Manual MEMO Hardware Installation...

  • Page 52: Chapter 3 Bios Setup Utility

    IFO2225-851 Series Panel PC User’s Manual CHAPTER 3 BIOS SETUP UTILITY This chapter provides users with detailed description how to set up basic system configuration through the AMIBIOS8 BIOS setup utility. Starting To enter the setup screens, follow the steps below: 1.
  • Page 53 IFO2225-851 Series User’s Manual The <F10> key allows you to save any changes you have made and exit Setup. Press the <F10> key to save your changes. The <Esc> key allows you to discard any changes you have made and exit the Setup. Press the <Esc>...

  • Page 54: Main Menu

    IFO2225-851 Series Panel PC User’s Manual Main Menu When you first enter the Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options.

  • Page 55: Advanced Menu

    IFO2225-851 Series User’s Manual Advanced Menu The Advanced menu allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus:...
  • Page 56 IFO2225-851 Series Panel PC User’s Manual CPU Configuration This screen shows the CPU Configuration, BIOS Setup Utility...
  • Page 57 IFO2225-851 Series User’s Manual IDE Configuration You can use this item to change options for the IDE Configuration,. The available options appear on the right side of the screen. For items marked with “ ”, please press <Enter> for more options.
  • Page 58 IFO2225-851 Series Panel PC User’s Manual Super IO Configuration You can use this item to set up the SuperIO configuration. Serial Port1 Address This option specifies the base I/O port address and Interrupt Request address of serial port 1. The Optimal setting is 3F8/IRQ4.
  • Page 59 IFO2225-851 Series User’s Manual Serial Port2 Address This option specifies the base I/O port address and Interrupt Request address of serial port 2. The Optimal setting is 2F8/IRQ3. The Fail-Safe setting is Disabled. Serial Port3 Address This option specifies the base I/O port address and Interrupt Request address of serial port 2.
  • Page 60 IFO2225-851 Series Panel PC User’s Manual Hardware Health Configuration This item shows the Hardware Health Configuration. BIOS Setup Utility...
  • Page 61 IFO2225-851 Series User’s Manual ACPI Setting You can use this item to set up ACPI Configuration. General ACPI Configuration Scroll this item and press <Enter> to view the General ACPI Configuration sub menu, which contains General ACPI (Advanced Configuration and Power Management Interface) options for your configuration.
  • Page 62 IFO2225-851 Series Panel PC User’s Manual Advanced ACPI Configuration You can use this item to set up advanced ACPI. BIOS Setup Utility...
  • Page 63 IFO2225-851 Series User’s Manual AHCI Configuration You can use this item to set up AHCI configuration.. AHCI BIOS Support You can enable or disable this item to control the AHCI function of the SATA controller. BIOS Setup Utility...
  • Page 64 IFO2225-851 Series Panel PC User’s Manual USB Configuration You can use this item to set up the USB Configuration. Legacu USB Support Use this item to enable or disable support for USB device on legacy operating system. The default setting is Enabled.

  • Page 65: Boot Menu

    IFO2225-851 Series User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. You can select any of the items in the left side of the screen to go to the sub menus: Boot Settings Configuration For items marked with “...
  • Page 66 IFO2225-851 Series Panel PC User’s Manual Boot Settings Configuration Quick Boot Enabling this item lets the BIOS skip some power on self tests (POST). The default setting is Enabled. AddOn ROM Display Mode This item selects the display mode for option ROM. The default setting is Force BIOS.

  • Page 67: Security Menu

    IFO2225-851 Series User’s Manual Security Menu The Security menu allows users to change the security settings for the system. Supervisor Password This item indicates whether a supervisor password has been set. If the password has been installed, Installed displays. If not, Not Installed displays.
  • Page 68 IFO2225-851 Series Panel PC User’s Manual Change User Password Select this option and press <Enter> to access the sub menu. You can use the sub menu to change the user password. Boot Sector Virus Protection This option is near the bottom of the Security Setup screen.

  • Page 69: Chipset Menu

    IFO2225-851 Series User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left side of the screen to go to the sub menus: North Bridge Configuration South Bridge Configuration For items marked with “...
  • Page 70 IFO2225-851 Series Panel PC User’s Manual North Bridge Configuration Memory Hole You can reserve this area of system memory for ISA adapter ROM. When this area is reserved it cannot be cached. Check the user information of peripherals that need to use this area o f system memory for the memory requirements.
  • Page 71 IFO2225-851 Series User’s Manual You can press <Enter> for the sub-menu to set up video function. South Bridge Configuration USB Controller This item allows you to enable or disable USB function/controller. Restore on AC Power Loss This item controls how the PC will behave once power is restored following a power outage, or other unexpected shutdown.

  • Page 72: Exit Menu

    IFO2225-851 Series Panel PC User’s Manual Exit Menu The Exit menu allows users to load your system configuration with optimal or failsafe default values. Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect.
  • Page 73 IFO2225-851 Series User’s Manual Discard Changes Use this item to abandon all changes. Load Optimal Defaults It automatically sets all Setup options to a complete set of default settings when you select this option. The Optimal settings are designed for maximum system performance, but may not work best for all computer applications.

  • Page 74: Chapter 4 Driver Installation

    IFO2225-851 Series Panel PC User’s Manual CHAPTER 4 DRIVER INSTALLATION System IFO2225-851 supports Windows XP/ Windows Vista to facilitate the installation of system driver, please carefully read the instructions in this chapter before start installing. Insert Driver CD in the disk, and select the \IFO2225-851\Driver\..

  • Page 75: Touch Screen

    IFO2225-851 Series User’s Manual Touch Screen 4.2.1 Specification Touch Screen For 5-wire analog resistive type Touch Screen Controller PenMount 6000 microcontroller Communications Resolution 1024 x 1024 Power Input Power Consumption Standby Mode : 13.4mA; Active Mode: 24.6mA (VCC=5V, Top sheet Panel Resistance: 274...

  • Page 76: Driver Installation

    IFO2225-851 Series Panel PC User’s Manual 4.2.2 Driver Installation The IFO2225-851 Series provides a driver of the touch screen that users can install it under operating system Windows XP/ Windows Vista. To facilitate this touch screen driver installation, users should read the instructions in this chapter carefully before start the installation.
  • Page 77 IFO2225-851 Series User’s Manual Calibration: To adjust the display with touch panel, click “Calibration” and follow the calibrate point to do calibration; there are five points on screen for calibration. Press OK. Driver Installation...
