AXIOMTEK IFO2175-850-FL Series User Manual

17” fanless touch panel computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IFO2175-850-FL Series
17" Fanless Touch Panel Computer
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IFO2175-850-FL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMTEK IFO2175-850-FL Series

Summary of Contents for AXIOMTEK IFO2175-850-FL Series

  • Page 1 IFO2175-850-FL Series 17” Fanless Touch Panel Computer User’s Manual...
  • Page 2 AXIOMTEK does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document. AXIOMTEK does not make any commitment to update the information in this manual.
  • Page 3 Safety Approvals CE Marking FCC Class A FCC Compliance This equipment has been tested in compliance with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are meant to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Safety Precautions

    Safety Precautions Before getting started, read the following important safety precautions. The IFO2175-850-FL Series does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer. Be sure to ground yourself to prevent static charge when installing the internal components.

  • Page 5: Classification

    input/out or other connectors, shall comply with relevant UL/IEC standard. 11. Do not open the system’s back cover. If opening the cover for maintenance is a must, only a trained technician is allowed to do so. Integrated circuits on computer boards are sensitive to static electricity.

  • Page 6: General Cleaning Tips

    General Cleaning Tips You may need the following precautions before you begin to clean the computer. When you clean any single part or component for the computer, please read and understand the details below fully. When you need to clean the device, please rub it with a piece of dry cloth.
  • Page 7 Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas in your keyboard, mouse, and other locations. Foam swabs: Whenever possible it is better to use lint free swabs such as foam swabs. Note We strongly recommended that you should shut down the system before you start to clean any single components.

  • Page 8: Scrap Computer Recycling

    Trademarks Acknowledgments AXIOMTEK is a trademark of AXIOMTEK Co., Ltd. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.

  • Page 9: Table Of Contents

    Table of Contents Disclaimers ..............ii Safety Approvals............iii Safety Precautions............. iv Classification .............. v General Cleaning Tips ..........vi Scrap Computer Recycling ........viii CHAPTER 1..............1 INTRODUCTION ............1 General Description ........1 Features ............2 System Specifications ........2 Dimensions ..........
  • Page 10 Chipset Menu ..........50 Exit Menu ........... 53 CHAPTER 4..............55 System ............55 Touch Screen..........56 4.2.1 Specification..........56 4.2.2 Driver Installation- Windows XP/CE.NET/XP-Embedded ........57 MEMO...

  • Page 11: Chapter 1

    IFO2175-850-FL Series Panel PC User’s Manual CHAPTER 1 INTRODUCTION This chapter contains general information and detailed specifications of the IFO2175-850-FL Series. Chapter 1 includes the following sections: General Description Features System Specification Dimensions I/O Outlets Package List General Description The IFO2175-850-FL is an ultra slim panel computer equipped with 17-inch 380 nits high brightness SXGA LCD display and supports ®...

  • Page 12: Features

    IFO2175-850-FL Series Panel PC User’s Manual with super slim, professional outlook, better user interface, and excellent protection at once! This safe, reliable & user-friendly panel computer can ensure customer’s project success and best suited for PIO/POS/kiosk, media content display, and HMI solutions.
  • Page 13 IFO2175-850-FL Series Panel PC User’s Manual ® SOCKET P FOR INTEL CORE 2 DUO/ ® CELERON PROCESSOR WITH FSB 667/800/1066 MHz ® CHIPSET INTEL GM/GL45+ICH9M MAIN SYSTEM SUPPORTS 1 DDR3 SYSTEM SODIMM MEMORY UP TO MEMORY 1 x 2.5" SATA HDD DRIVE...
  • Page 14 IFO2175-850-FL Series Panel PC User’s Manual OPERATION TEMPERATURE: 0ºC~40ºC (32ºF~104ºF) ENVIRONMENTA RELATIVE HUMIDITY: 10%~95%, NON- CONDESING SHOCK: 10G PEAK ACCELERATION (11 SEC. DURATION) CERTIFICATION NOTE All specifications and images are subject to change without notice. Introduction...

  • Page 15: Dimensions

    IFO2175-850-FL Series Panel PC User’s Manual Dimensions The following diagrams show you dimensions and outlines of the IFO2175-850-FL Series. Introduction...

  • Page 16: I/O Outlets

    IFO2175-850-FL Series Panel PC User’s Manual I/O Outlets The following figures show you the locations of the IFO2175-850-FL Series I/O outlets. ○ 2 ○ 1 ○ 3 Introduction...
  • Page 17 IFO2175-850-FL Series Panel PC User’s Manual I/O Outlets CONNECTOR BRIGHTNESS ADJUST BUTTONS VOLUME ADJUST BUTTONS POWER SWITCH DC-IN POWER CONNECTOR COM 1 (RS-232) ETHERNET x 2 USB 2.0 x 2 PS/2 K/B + M/S COM 3 (RS-232) (OPTIONAL) COM 2 (RS-232)

  • Page 18: Packing List

    IFO2175-850-FL Series Panel PC User’s Manual Packing List The package bundled with your IFO2175-850-FL Series should contain the following items: IFO2175-850-FL Series Unit x 1 12V AC-DC Power Adaptor Power Cord x 1 CD x 1 (For Driver and User’s Manual)
  • Page 19 IFO2175-850-FL Series Panel PC User’s Manual MEMO Introduction...

  • Page 20: Chapter 2

    IFO2175-850-FL Series Panel PC User’s Manual CHAPTER 2 HARDWARE INSTALLATION The IFO2175-850-FL Series are convenient for your various hardware configurations, such as CPU (Central Processing Unit) and HDD (Hard Disk Drive). The chapter 2 will show you how to install the hardware. It...
  • Page 21 IFO2175-850-FL Series Panel PC User’s Manual Step 3 Please open the back cover by lifting the joint part as marked. Step 4 Locate the CPU socket. Before installing your CPU, please check and confirm all jumpers are correctly set. Locate the socket on the board.
  • Page 22 IFO2175-850-FL Series Panel PC User’s Manual Step 5 Align pins of the CPU with pin holes of the socket. Be careful of the CPU’s orientation that you need to align the arrow mark on the CPU with the arrow key on the socket. Place the CPU into the socket, and use a screwdriver to lock it onto the socket.
  • Page 23 IFO2175-850-FL Series Panel PC User’s Manual Step 7 Close the back cover to the chassis, and fasten all screws. Hardware Installation...

  • Page 24: Installing The The Hard Disk Drive

    IFO2175-850-FL Series Panel PC User’s Manual Installing the the Hard Disk Drive The IFO2175-850-FL Series offers a convenient drive bay module for users to install HDD. The system offers users one 2.5” Hard Disk Drive for installation. Please follow the steps: Step 1 Turn off the system, and unplug the AC power-cord.
  • Page 25 IFO2175-850-FL Series Panel PC User’s Manual Step 3 Please open the back cover by lifting the joint part as marked. Step 4 Locate the HDD socket as marked. Hardware Installation...
  • Page 26 IFO2175-850-FL Series Panel PC User’s Manual Step 5 Use assembly parts to fix HDD with the bracket. HDD Bracket x1 2.5 inch Hard-disk Screw x 4 Assembly the HDD with the bracket. ATTENTION Please follow the direction of Hard-disk installation.
  • Page 27 IFO2175-850-FL Series Panel PC User’s Manual Step 6 Install the HDD bracket inside the system. Plug the SATA and Power cables in HDD. Power connector SATA connector Step 7 Close the back cover to the chassis, and fasten all screws.

  • Page 28: Mountings - Wallmount/Vesa

    IFO2175-850-FL Series Panel PC User’s Manual Mountings – Wallmount/VESA The mountings for IFO2175-850-FL Series are Wallmount and VESA- Arm as below: Hardware Installation...

  • Page 29: Installing Desktop Stand (Optional)

    IFO2175-850-FL Series Panel PC User’s Manual Installing Desktop Stand (Optional) The IFO2175-850-FL Series provides you with an optional Desktop Stand that you can follow the steps below: Step 1 Prepare all parts for installing the desktop stand. Assemble the desktop stand by using screws to fix the backplane.
  • Page 30 IFO2175-850-FL Series Panel PC User’s Manual Step 2 Assemble the desktop stand by fixing it onto the system. Step 3 Fix the desktop stand fimly. Rear View Hardware Installation...
  • Page 31 IFO2175-850-FL Series Panel PC User’s Manual Front View Hardware Installation...

  • Page 32: Installing Wireless Module (Optional)

    IFO2175-850-FL Series Panel PC User’s Manual Installing Wireless Module (Optional) You can follow the steps below to install an optional wireless module. Step 1 Turn off the system, and unplug the AC power-cord. Step 2 Locate and release these screws to open the back cover.
  • Page 33 IFO2175-850-FL Series Panel PC User’s Manual Step 3 Please open the back cover by lifting the joint part as marked. Step 4 Prepare all parts for installing the wireless module and antenna. Hardware Installation...
  • Page 34 IFO2175-850-FL Series Panel PC User’s Manual Step 5 Install the wireless module as figures below: Hardware Installation...
  • Page 35 IFO2175-850-FL Series Panel PC User’s Manual Step 6 Assemble the antenna and connect it through COM 3 port. Follow the figures to connect the antenna. Hardware Installation...
  • Page 36 IFO2175-850-FL Series Panel PC User’s Manual Step 7 Connect the antenna. Step 8 Close the back cover to the chassis, and fasten all screws. Hardware Installation...
  • Page 37 IFO2175-850-FL Series Panel PC User’s Manual MEMO Hardware Installation...

  • Page 38: Chapter 3

    IFO2175-850-FL Series Panel PC User’s Manual CHAPTER 3 AMI BIOS SETUP UTILITY This chapter provides users with detailed description how to set up basic system configuration through the AMI BIOS setup utility. Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del>...

  • Page 39: Navigation Keys

    IFO2175-850-FL Series Panel PC User’s Manual Navigation Keys The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot keys can be used at any time during the setup navigation process. These keys include <F1>, <F10>, <Enter>, <ESC>, <Arrow> keys, and so on.

  • Page 40: Advanced Menu

    IFO2175-850-FL Series Panel PC User’s Manual Advanced Menu The Advanced menu allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus:...
  • Page 41 IFO2175-850-FL Series Panel PC User’s Manual CPU Configuration This screen shows the CPU Configuration, and you can change the value of the selected option. Max CPUID Value Limit You can enable this item to let legacy operating systems boot even without support for CPUs with extended CPU ID functions.
  • Page 42 IFO2175-850-FL Series Panel PC User’s Manual IDE Configuration You can use this screen to select options for the IDE Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen. For items marked with “...
  • Page 43 IFO2175-850-FL Series Panel PC User’s Manual SuperIO Configuration You can use this screen to select options for the SuperIO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 44 IFO2175-850-FL Series Panel PC User’s Manual Hardware Health Configuration This screen shows the Hardware Health Configuration, and a description of the selected item appears on the right side of the screen. H/W Health Function You can select this item Enabled for the Hardware Health Monitoring Device.
  • Page 45 IFO2175-850-FL Series Panel PC User’s Manual ACPI Configuration You can use this screen to select options for the ACPI Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 46 IFO2175-850-FL Series Panel PC User’s Manual APM Configuration You can use this screen to select options for the APM Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 47 IFO2175-850-FL Series Panel PC User’s Manual Power Button Mode This option specifies how the externally mounted power button on the front of the computer chassis is used. The default setting is On/Off. Pushing the power button turns the computer on or On/Off off.
  • Page 48 IFO2175-850-FL Series Panel PC User’s Manual This option places the monitor into suspend mode after the specified period of display inactivity has expired. This means the monitor is not off. The screen will Suspend appear blacked out. The standards do not cite specific...
  • Page 49 IFO2175-850-FL Series Panel PC User’s Manual Set this value to allow the computer system to enter 5 Min suspend mode after being inactive for 5 minutes. Set this value to allow the computer system to enter 10 Min suspend mode after being inactive for 10 minutes.
  • Page 50 IFO2175-850-FL Series Panel PC User’s Manual MPS Revision Use this item to select MPS (Multi Processor Specification) Revision 1.1 or 1.4. The default setting is 1.4. PCI Express Configuration This screen shows the PCI Express Configuration, and you can change its value. A description of the selected item appears on the right side of the screen.
  • Page 51 IFO2175-850-FL Series Panel PC User’s Manual Active State Power-Management Use this item to enable or disable the function of Active State Power-Management to provide you with lower power consumption. The default setting is Disabled. AMI BIOS Setup Utility...
  • Page 52 IFO2175-850-FL Series Panel PC User’s Manual USB Configuration You can use this screen to select options for the USB Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.

  • Page 53: Pci Pnp Menu

    IFO2175-850-FL Series Panel PC User’s Manual PCI PnP Menu The PCI PnP menu allows users to change the advanced settings for PCI/PnP devices. Plug & Play O/S When the setting is No, Use this item to configure all the devices in the system. When the setting is Yes and if you...

  • Page 54: Boot Menu

    IFO2175-850-FL Series Panel PC User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. You can select any of the items in the left frame of the screen to go to the sub menus:...
  • Page 55 IFO2175-850-FL Series Panel PC User’s Manual Boot Settings Configuration Quick Boot Enabling this item lets the BIOS skip some power on self tests (POST). The default setting is Enabled. AddOn ROM Display Mode This item selects the display mode for option ROM. The default setting is Force BIOS.
  • Page 56 IFO2175-850-FL Series Panel PC User’s Manual Lan Boot Settings Configuration The Lan Boot Settings Configuration can enable or disable Lan Boot ROM [1] or ROM [2] to allow the system boot on LAN. Boot Device Priority The Boot Device Priority screen specifies the order in which the system checks for the device to boot from the available devices.
  • Page 57 IFO2175-850-FL Series Panel PC User’s Manual Hard Disk Drives Use this screen to view the hard disk drives in the system. AMI BIOS Setup Utility...

  • Page 58: Security Menu

    IFO2175-850-FL Series Panel PC User’s Manual Security Menu The Security menu allows users to change the security settings for the system. Supervisor Password This item indicates whether a supervisor password has been set. If the password has been installed, Installed displays.
  • Page 59 IFO2175-850-FL Series Panel PC User’s Manual Clear User Password Select this option and press <Enter> to access the sub menu. You can use the sub menu to clear the user password. Boot Sector Virus Protection This option is near the bottom of the Security Setup screen.

  • Page 60: Chipset Menu

    IFO2175-850-FL Series Panel PC User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: North Bridge Configuration South Bridge Configuration For items marked with “...
  • Page 61 IFO2175-850-FL Series Panel PC User’s Manual North Bridge Configuration Boot Graphic Adapter Priority This item allows you to select the graphics controller as the primary boot device. Internal Graphics Mode Select This item allows you to select the amout of system memory used by the internal graphics device.
  • Page 62 IFO2175-850-FL Series Panel PC User’s Manual South Bridge Configuration USB Function/USB 2.0 Controller/HAD Controller These items, respectively, allow you to enable or disable USB/USB 2.0/HAD function/controller. AMI BIOS Setup Utility...

  • Page 63: Exit Menu

    IFO2175-850-FL Series Panel PC User’s Manual Exit Menu The Exit menu allows users to load your system configuration with optimal or failsafe default values. Exit Saving Changes When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect.
  • Page 64 IFO2175-850-FL Series Panel PC User’s Manual Select Load Optimal Defaults from the Exit menu and press <Enter>. Load Fail-Safe Defaults It automatically sets all Setup options to a complete set of default settings when you Select this option. The Fail-Safe settings are designed for maximum system stability, but not maximum performance.

  • Page 65: Chapter 4

    IFO2175-850-FL Series Panel PC User’s Manual CHAPTER 4 DRIVER INSTALLATION System IFO2175-850-FL supports Windows XP/ Windows Vista to facilitate the installation of system driver, please carefully read the instructions in this chapter before start installing. Insert Driver CD in the disk, and select the \IFO2175-850- FL\Driver\..

  • Page 66: Touch Screen

    IFO2175-850-FL Series Panel PC User’s Manual Touch Screen 4.2.1 Specification Touch Screen For 5-wire analog resistive type Touch Screen Controller PenMount 6000 microcontroller Communications USB Full-speed, 12Mbps Baud Rate 19200/ 9600 Resolution 1024 x 1024 Power Input Power Consumption Standby Mode : 13.4mA; Active Mode: 24.6mA...

  • Page 67: Driver Installation- Windows Xp/Ce.net/Xp-Embedded

    IFO2175-850-FL Series Panel PC User’s Manual 4.2.2 Driver Installation- Windows XP/CE.NET/XP- Embedded The IFO2175-850-FL Series provides a driver of the touch screen that users can install it under operating system Windows XP/ Windows Vista. To facilitate this touch screen driver installation, users should read the instructions in this chapter carefully before start the installation.
  • Page 68 IFO2175-850-FL Series Panel PC User’s Manual Click the “Standard Calibration” button. Calibration: To adjust the display with touch panel, click “Calibration” and follow the calibrate point to do calibration; there are five points on screen for calibration. Press OK. Driver Installation...
