Polaris 2008 sportsman 800efi Service Manual page 173

3. Remove the two screws retaining the passenger backrest.
4. Remove the two pivot pins holding the backrest to the
frame.
5. Lift up on the backrest latch and tilt the backrest in towards
the cargo box and lift up to remove it.
6. For installation, reverse the removal steps.
BODY / STEERING / SUSPENSION
5
5.33
