Additional safety instructions for batteries and
Never attempt to open for any reason.
Do not expose the battery to water.
Do not store in locations where the temperature may
exceed 40 °C.
Charge only at ambient temperatures between 10 °C and
Charge only using the charger provided with the tool.
When disposing of batteries, follow the instructions given
in the section "Protecting the environment".
Use your Black & Decker charger only to charge the
battery in the tool with which it was supplied. Other
batteries could burst, causing personal injury and damage.
Never attempt to charge non-rechargeable batteries.
Have defective cords replaced immediately.
Do not expose the charger to water.
Do not open the charger.
Do not probe the charger.
The charger is intended for indoor use only.
Read the instruction manual before use.
The charger automatically shuts off if the ambient
temperature becomes too high. The thermal cut out
operates only once and then requires complete
Your charger is double insulated; therefore no earth
wire is required. Always check that the mains
voltage corresponds to the voltage on the rating
plate. Never attempt to replace the charger unit with
a regular mains plug.
If the supply cord is damaged, it must be replaced by the
manufacturer or an authorised Black & Decker Service
Centre in order to avoid a hazard.
1. Forward/reverse switch
2. Handle adjustment button
3. Spindle lock collar
4. Bit holder
6. Bit storage
7. Charger socket
8. Charger plug
Fitting and removing a screwdriver bit (fig. B)
This tool uses screwdriver bits with a 1/4" (6.35 mm)
To fit a bit, insert the bit shaft (10) into the bit holder (4).
To remove a bit, pull the bit shaft out of the bit holder.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
Injuries caused by touching any rotating/moving
Injuries caused when changing any parts, blades or
Injuries caused by prolonged use of a tool. When
using any tool for prolonged periods ensure you take
Impairment of hearing.
Health hazards caused by breathing dust developed
when using your tool (example:- working with wood,
especially oak, beech and MDF.)
Warning! Let the tool work at its own pace. Do not overload.
Charging the battery (fig. A)
The battery needs to be charged before first use and
whenever it fails to produce sufficient power on jobs that were
easily done before. When charging the battery for the first
time, or after prolonged storage, it will only accept an 80%
charge. After several charge and discharge cycles, the battery
will attain full capacity. The battery may become warm while
charging; this is normal and does not indicate a problem.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C. Recommended charging
temperature: approx. 24 °C.
To charge the battery, insert the charger plug (8) into the
charger socket (7).
Plug in the charger (9).
