Trane TUD-R9V User's Information Manual

IMPoRTanT: users MuST read all instructions in the manual.
all manuals MuST be kept for future reference.
SaFeTy SeCTIon
Safety signal words are used to designate a degree or level
of seriousness associated with a particular hazard. The
signal words for safety markings are WaRnInG, and
CauTIon.
a. WaRnInG indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
b. CauTIon indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury. It is also used to alert against unsafe practices
and hazards involving only property damage.
WaRnInG
▲
!
If the information in this manual is not followed exactly,
a fire or explosion may result causing property
damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids or combustible materials in the
vicinity of this or any other appliance.
— WhaT To Do IF you SMeLL GaS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier,
call the fire department.
— Do noT ReLy on SMeLL aLone To DeTeCT
LeaKS. Due To vaRIouS FaCToRS, you May
noT be abLe To SMeLL FueL GaSeS.
• u.L. recognized fuel gas and Co detectors are
recommended in all applications, and their
installation should be in accordance with the
manufacturer's recommendations and/or local
laws, rules, regulations, or customs.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
user's Information Guide
Gas Furnaces — non-Condensing
Fan assisted Combustion System
upflow / horizontal
with Whole house air Cleaner
Contents
Safety Section
General Information
To Start the Furnace
Proper Maintenance
The Problem Solver
Regular Dealer Maintenance
Warranty
WaRnInG
▲ !
SaFeTy WaRnInG
Do noT uSe ThIS unIT IF any PaRT haS been un-
DeR WaTeR. a FLooD DaMaGeD unIT IS eXTReMeLy
DanGeRouS. aTTeMPTS To uSe The FuRnaCe Can
ReSuLT In FIRe oR eXPLoSIon. a quaLIFIeD SeR-
vICe aGenCy ShouLD be ConTaCTeD To InSPeCT
The FuRnaCe anD To RePLaCe aLL GaS ConTRoLS,
ConTRoL SySTeM PaRTS, eLeCTRICaL PaRTS ThaT
have been WeT oR The FuRnaCe IF DeeMeD neCeS-
SaRy.
FaILuRe To FoLLoW ThIS WaRnInG CouLD ReSuLT In
PRoPeRTy DaMaGe, PeRSonaL InjuRy oR DeaTh.
WaRnInG
▲ !
SaFeTy WaRnInG
In The evenT ThaT eLeCTRICaL, FueL oR MeChanI-
CaL FaILuReS oCCuR, The oWneR ShouLD IMMe-
DIaTeLy TuRn oFF The GaS SuPPLy aT The ManuaL
GaS vaLve LoCaTeD In The buRneR CoMPaRTMenT
anD eLeCTRICaL PoWeR To The FuRnaCe anD Con-
TaCT SeRvICeR.
FaILuRe To FoLLoW ThIS WaRnInG CouLD ReSuLT In
PRoPeRTy DaMaGe, PeRSonaL InjuRy oR DeaTh.
WaRnInG
▲ !
SaFeTy WaRnInG
ShouLD oveRheaTInG oCCuR, oR The GaS SuPPLy
FaIL To ShuT oFF, ShuT oFF The ManuaL GaS vaLve
To The FuRnaCe beFoRe ShuTTInG oFF The eLeC-
TRICaL SuPPLy.
FaILuRe To FoLLoW ThIS WaRnInG CouLD ReSuLT In
PRoPeRTy DaMaGe, PeRSonaL InjuRy oR DeaTh.
32- 5052- 06
Available in French Canadian (FC)
