WARNING
▲
!
If the information in this manual is not followed exactly,
a fire or explosion may result causing property
damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF yOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier,
call the fire department.
— DO NOT RELy ON SMELL ALONE TO DETECT
LEAKS. DUE TO vARIOUS FACTORS, yOU MAy
NOT bE AbLE TO SMELL FUEL GASES.
• U.L. recognized fuel gas and CO detectors are
recommended in all applications, and their
installation should be in accordance with the
manufacturer's recommendations and/or local
laws, rules, regulations, or customs.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
WARNING
▲
!
SAFETy HAzARD
DO NOT USE THIS UNIT IF ANy PART HAS bEEN UNDER
WATER. IMMEDIATELy CALL A qUALIFIED SERvICE
TECHNICIAN TO INSPECT THE FURNACE AND TO RE-
PLACE ANy PART OF THE CONTROL SySTEM AND ANy
GAS CONTROL WHICH HAS bEEN UNDER WATER.
FAILURE TO FOLLOW THIS WARNING MAy RESULT IN
PERSONAL INJURy, PROPERTy DAMAGE, OR DEATH.
User's Information Guide
Gas Furnaces — Non-Condensing
Fan Assisted Combustion System
Upflow / Horizontal and Downflow / Horizontal
Available in French Canadian (FC)
Contents
Dangers, Warnings & Cautions
General Information
To Start the Furnace
Proper Maintenance
The Problem Solver
Regular Dealer Maintenance
Warranty
GENERAL INFORMATION
Understand the signal words WARNING and CAUTION.
These words are safety alert words. WARNING indicates
hazards which could result in personal injury or death.
CAUTION is used to indicate unsafe practices which could
result in minor injury or property damage.
IMPORTANT FACTS
The flow of combustion and ventilating air must not be ob-
structed from reaching the furnace. Air openings provided
in the casing of the furnace must be kept free of obstruc-
tions which would restrict airflow, thereby affecting effi-
ciency and safe operation of your furnace.
Also, air openings provided to the area in which the furnace
is installed and the space around the furnace shall not be
blocked or obstructed. Keep this in mind should you choose
to remodel the area which contains your furnace. If addi-
tional insulation is added after the furnace is installed, the
area around the furnace must be inspected to ensure it is
free and clear of insulation. If this furnace is installed in an
attic or other insulated space it must be kept free and clear
of all insulating materials as some insulating materials are
combustible.
Furnaces must have air for proper performance. There
must be a free flow of fresh air sufficient for efficient com-
bustion and safe ventilation of your furnace.
The combustion air for your furnace must be fresh uncon-
taminated air. Paints, varnishes, laundry bleaches, de-
tergents, many household cleaners, water softening salts,
adhesives, and all such products release fumes containing
compounds which could lead to early heat exchanger and
vent system deterioration. Do not store these types of prod-
ucts near your furnace.
32- 5063- 03
1
1
2
4
6
7
9
Advertisement
Related Manuals for Trane UC1
Summary of Contents for Trane UC1
- Page 1 32- 5063- 03 Available in French Canadian (FC) User’s Information Guide Gas Furnaces — Non-Condensing Fan Assisted Combustion System Upflow / Horizontal and Downflow / Horizontal Contents WARNING ▲ Dangers, Warnings & Cautions If the information in this manual is not followed exactly, a fire or explosion may result causing property General Information damage, personal injury or loss of life.
-
Page 2: To Start The Furnace
3. Remove the furnace front panel to gain access to the main gas valve. Gas valve On / Off Toggle Switch On/Off Switch your furnace may have a “Knob Switch” or a “Toggle Switch” to turn the gas ON or OFF. 32-5063-03 © 2009 Trane... - Page 3 User’s Information 8. When thermostat is satisfied, main burners will CAUTION ▲ extinguish. If this is done during the cold weather months, provisions 9. If main burners fail to ignite, lower thermostat setting must be taken to prevent freeze-up of all water pipes and or disconnect electrical supply, wait 5 minutes, raise water receptacles.
-
Page 4: Proper Maintenance
User’s Information Proper Maintenance Reduces Energy Use AIR FILTERS NOTE: Filters are NOT included with all Furnaces A clean filter saves money. When the furnace circulates and filters the air in your home, dust and dirt particles build up on the filter. Exces- sive accumulation can block the airflow, forcing the unit to work harder to maintain desired temperatures. - Page 5 User’s Information Upflow / Horizontal Furnace Filters Downflow/Horizontal furnaces are factory supplied with The Upflow/Horizontal furnace when installed horizontally 2 standard size permanent type air filters which may be requires a horizontal filter kit. The filters may be located located remote to the furnace or in the return air duct. remote to the furnace or in the return air duct near the fur- Check with your dealer for the location of your filters.
- Page 6 User’s Information The Problem Solver Other than performing the simple maintenance recom- mended in this manual, you should not attempt to make any adjustments to your furnace. Your dealer will be able to take care of any questions or problems you may have. A furnace is not a household appliance.
-
Page 7: Regular Dealer Maintenance
User’s Information Regular Dealer Maintenance Never stop the cooling system by shutting off CAUTION ▲ the main power. If the main power to your air conditioner is ever disconnect- Do NOT touch igniter. It is extremely hot. ed for more than three hours, turn off the thermostat. Then 4. - Page 8 User’s Information User’s Information 7. OPERATION – Your warm air furnace should not be operated in a corrosive atmosphere. Paint solvents, cleaning chemicals, spray propellants, and bleaches should not be used in the vicinity of the furnace during normal operation. 8.
- Page 9 User’s Information Base Limited Warranty Gas Furnace *UD2-9V, *DD2-9V, *UD-AFV, *DD-ACV, *UD-ACV, *UX-AFV, *UH2, *DH2, *UH3, *DH3 (Parts Only) (First letter may be preceded with an “A” or “T”) Models Less Than 20 Tons for Residential Use* This limited warranty is provided by the manufacturer to the original purchaser and to any succeeding owner of the real property to which the gas furnace is originally affixed, and applies to products purchased and retained for use within the U.S.A.
-
Page 10: Limited Warranty
User’s Information Limited Warranty Induced Draft Gas Furnace UC1, DC1, UX1, DX1, UX1-H, DX1-H, UX, DX, UY, DY, UD-R, DD-R, UD-RV, DD-RV, UD1-H, DH1, DD1-H, UD1, DD1, UE1, DE1, UH3, DH3, UX2, (First letter may be preceded DX2, UH2, DH2, UD2, DD2, UHM, DHM and UH1 by an “A”... - Page 11 User’s Information Important Product Information Registering your products helps provide you with one of the strongest manufacturer limited warranties avail- able. To register, go to the manufacturer’s website or contact your dealer. You will need the serial number, model number, and installation date for each product being registered. Your dealer may have included these on your invoice or can provide a list for you to use.
- Page 12 File name 32-5063-03 Supersedes 32-5063-02 Date 06/10 06/10 The manufacturer has a policy of continuous product and product data improvement, and it reserves the right Trane to change design and specifications without notice. 6200 Troup Highway Tyler, TX 75707...
