ADB BOLERO Instruction Manual

Hide thumbs Also See for BOLERO:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
BOLERO
Instruction Manual
Manuel d'instruction
Handleiding
Bedienungsanleitung
Lighting Technologies
M 1030
1106.01.030

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BOLERO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADB BOLERO

Summary of Contents for ADB BOLERO

  • Page 1 BOLERO Instruction Manual Manuel d'instruction Handleiding Bedienungsanleitung Lighting Technologies M 1030 1106.01.030...
  • Page 2 BOLERO Instruction Manual Page Revision : 002 Lighting Technologies...

  • Page 3: Table Of Contents

    BOLERO Summary Installation Signal Connections Technical Specifications Options and Accessories Unpacking the desk Precautions Caution Connecting to the back panel «GRAND MASTER» Manual Section Flash Keys Generating Manual Output Dual Preset Effect Section The Channel Buttons Speed Control START/STEP Button...
  • Page 4 To obtain full benefits of the safety measures, the equipment shall be installed and serviced by skilled and trained personnel exclusively. Don't make any modification to the equipment. ADB shall not accept any liability for material damages or injuries which may result from unauthorised modifications. Important Notice for Power Cables Power supply cables and connectors are an important part of your equipment and contribute to its safety.

  • Page 5: Installation

    It is absolutely forbidden to apply any voltage to the connections of the BOLERO (Aux, DMX and Analogue outputs). Connections to inappropriate sources may inadvertently damage the BOLERO and may be dangerous to the user.

  • Page 6: Unpacking The Desk

    BOLERO Unpacking the desk After removing the desk from it's box, check that the following items are included : • 1 BOLERO desk • 1 User manual (this document) • 1 * 5 pin XLR male connector for DMX512/1990 signal If any of the previous items are missing contact your supplier immediately.

  • Page 7: Grand Master

    BOLERO «GRAND MASTER» USING THE Grand Master SECTION The Grand Master section controls the output of the desk. If the «ON/OFF» button is pressed then all output from the desk is off, and the LED above the button is off.

  • Page 8: Generating Manual Output

    BOLERO Generating Manual Output Each group of Preset faders has a master control fader and on/off button. The master for Preset B works in reverse of that for Preset A, i.e. 100% is at the bottom and 0% is at the top of its travel, for Preset B. The «ON/OFF» buttons work in a similar fashion to the Grand Master «ON/OFF»...

  • Page 9: Dual Preset

    BOLERO Dual Preset Dual Presets allow for the creation of two output settings on two different banks of faders, Preset A and Preset B. Either or both presets may be output from the desk with the highest value of each channel taking precedence.The active Preset(s) are shown by illuminating the corresponding LED.

  • Page 10: Effect Section

    BOLERO 12 or a BOLERO 24 is being used. For the BOLERO 12 chase patterns 1 to 12 are available. On the BOLERO 24 patterns 1 to 24 may be used. The channels over which the chase runs may be individually selected.

  • Page 11: On/Off Button

    Simply press the «MODE» button once and then the «FLASH» button corresponding to the pattern required. On both the BOLERO 12 and BOLERO 24 «FLASH» buttons 1 to 12 select chase patterns 1 to 12. On the BOLERO 24 the additional «FLASH» buttons are used to select patterns 13 to 24 on «FLASH»...
  • Page 12 BOLERO Chase Pattern 1 Chase Pattern 13 Step 1 Step 1 Step 2 Step 2 Step 3 Step 3 Chase Pattern 2 Chase Pattern 14 Step 1 Step 1 Step 2 Step 2 Step 3 Step 3 Chase Pattern 3...

  • Page 13: Remote Control (Option)

    BOLERO Remote Control (option) One of the options available for the BOLERO is the ability to remotely use the Effect AUX DIN 5 section START/STEP button. This operation is identical to that button on the desk itself, and is detailed in the relevant section of the manual.

  • Page 14: Analogue Output Card Installation Instruction

    BOLERO Analogue Output Card Installation Instruction This assembly and desk contain static sensitive components. Installation should be undertaken using appropriate precautions. Turn the desk over onto it ' s front and remove the rear cover plate. Put this and the screws carefully to one side, to refit later.
  • Page 15 BOLERO Rear View Front View 15 16 19 20 29 30 11 12 17 18 22 23 Page Revision : 002 Lighting Technologies...

  • Page 16: Controls, Indicators And Connectors

    BOLERO Controls, Indicators and Connectors Rep. Description POWER socket (230 V) DMX 512/1990 output connector (5 pin female 'D' type XLR) AUX input socket (5 pin female DIN connector) Analogue output connectors (optional) SERIAL No Preset A manual faders Preset B manual faders...

  • Page 17: In Case Of Difficulty

    BOLERO In Case of Difficulty FAULT POSSIBLE REMEDIES Desk fails to come on. Is power supply plugged into desk correctly ? Is power supply connected to mains supply ? Is mains supply switched on ? Manual section faders do not produce an output Has the Manual section been blacked out ? (ON/OFF) when pushed up.
  • Page 18 Fax : 33.1.42.53.54.76 E-Mail : adb.fr@adblighting.com Factory & group logistics centre: Zone industrielle Rouvroy F-02100 Saint-Quentin Tel : 33.3.23.06.35.70 Fax : 33.3.23.67.66.56 E-Mail : adb.fr@adblighting.com ADB - Your Partner for Light - ISO 9001 : 2000 certified Lighting Technologies www.adblighting.com...
