- Page 1 TP-MS4x4 4 Port Gigabit PoE Injector USER’S MANUAL TYCON POWER SYSTEMS...
-
Page 2: General Information
TP-MS4x4 V5 1. General Information The TP-MS4x4 is a DC/DC PoE (Power over Ethernet) Injector, provide up to 4 different voltage DC input and four different voltage PoE output, output power maximum 1A/port, data rate can be 10M/100M/1000M. The polarity of each PoE output can be reversed if you need to reverse the output polarity. -
Page 3: Led Indicator
User’s Manual TP-MS4x4 V5 *LED Indicator There are 4 LEDs on the front panel to indicate the input and output power status of each port. STATUS Description Green A valid power device is detected on this port. Active current is 80mA. -
Page 4: Power Input
TP-MS4x4 V5 *Power Input The input voltage of TP-MS4x4 is 12VDC to 57VDC, it is common negative design, the green terminal (CON1) on rear panel is used for power input wiring, it can be connected to maximum 4 different sources with 4 different voltages, the jumper A, B, C, of JP1 on rear panel controls the input/output connection, its setting as below. - Page 5 * Data pair D plus V- on line 7 and 8 *Output Polarity Reverse (for technician operation only) The TP-MS4x4 may deliver PoE output with reverse polarity. Just move related jumpers from pin 1-2 to pin 2-3, and then * Data pair C carry V- on line 4 and 5...
-
Page 6: Technical Information
User’s Manual TP-MS4x4 V5 4. Technical Information Data Rate 10M/100M/1000M Input voltage: 12VDC to 57VDC Maximum PoE power Current limited – 1A/port PoE protection over-current, over/under voltage LEDs: Green-PD detect, Red-Power ready, Off-No power apply Operating temperature -40℃~ +75℃ Operation humidity...
