- Page 1 TP-SW8(-NC) 8 port PoE Endspan (Switch) (Extend Ethernet and PoE) USER’S MANUAL TYCON POWER SYSTEMS...
-
Page 2: Table Of Contents
User’s Manual TP-SW8 1. General Information.............. 2. Hardware Description............LED Indicators..................Power Wiring ..................Ethernet Port /PD Port Wiring …………..........3.Network Application……............4.Model information………….………........5.Technical Specification………..........TYCON POWER SYSTEMS... -
Page 3: General Information
*LED Indicator There are 18 LEDs on the PoE switch to indicate the power and operational status. The following section describes the functions of each LED indicator. Front panel detail the port number is as the diagram shows. TYCON POWER SYSTEMS... - Page 4 100Mbps. Yellow A network device is detected at 10Mbps, but no communication activity is detected. Yellow This port is transmitting to, or receiving Blinking package from another device at 10Mbps. No device is detected. TYCON POWER SYSTEMS...
-
Page 5: Power Wiring
* Data pair A plus V+ /V- on lines 1 and 2 * Data pair B plus V-/V+ on lines 3 and 6 * V+/V- on line 4 and 5 * V-/V+ on line 7 and 8 TYCON POWER SYSTEMS... -
Page 6: Ethernet Port/Pd Port Wiring
Port 1 to port 7 also provides PSE function which delivers DC power through the spare pairs (pair 4,5 and pair7,8) to the PD. Port 8 provides PD function that receive power from 4 pairs or 2 pairs Ethernet cable. TYCON POWER SYSTEMS... -
Page 7: Network Application
The PoE Switch can receive power from PoE midspan and provide power to the PD. It will power 802.3af compliant devices if it is powered at 48VDC although it will not perform the 802.3af handshake with the client device. The PoE Switch can be installed in a more appropriate position TYCON POWER SYSTEMS... - Page 8 User’s Manual TP-SW8 for better performance to extend Ethernet to 200 meters. The following figure is an example of a network application for PoE Switch. (TP-SW8-NC added the repeater function since S/N 127000375A) TYCON POWER SYSTEMS...
-
Page 9: Model Information
Flow control IEEE802.3x(full-duplex),back pressure(half-duplex) Data transmission rate 148800pps for 100base-T, 14880pps for 10base-T Address table 2K MAC address table, self-learning Connect RJ-45 PoE port Port 1-7, Pin assignment: TX(1,2), RX(3,6), V+(4,5), V-(7,8) Port 8, 4 pairs PD TYCON POWER SYSTEMS... - Page 10 DC(12V~57V) from rear panel or DC(44V~57V) from port 8 from midspan (or network switch) Power consumption 5W without PD loading Input Voltage Input Current 0.058A 0.037A 0.032A 0.032A Operating temperature -40℃~ +85℃ Operation humidity 90% relative humidity, non-condensing Storage temperature -40℃~+85℃ Dimension 40mm(H)x118mm(W)x159mm(D) DIN rail mountable TYCON POWER SYSTEMS...
- Page 11 <3pF (VR = 0V, f = 1MHz, I/O pin to GND) Max. Shut Capacitance < 1.5 pF (VR = 0V, f = 1MHz, Between I/O pins) IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact) IEC COMPATIBILITY (EN61000-4) IEC61000-4-4 (EFT) 40A (5/50ns) IEC61000-4-5 (Lightning) 20A (8/20µs) TYCON POWER SYSTEMS...
