- Page 1 TYCON TP-SSW5(-NC) 5 port PoE Endspan (Switch) USER’S MANUAL TYCON POWER SYSTEM...
-
Page 2: Table Of Contents
User’s Manual TYCON TP-SSW5(-NC) 1. General Information.............. 2. Hardware Description............LED Indicators..................Power Wiring ..................Ethernet Port Wiring................PD Port Wiring..................3. Technical Specification............TYCON POWER SYSTEMS... -
Page 3: General Information
2. Hardware Description *LED Indicator There are 11 LEDs on the PoE switch to indicate the power and operational status. The following section describes the functions of each LED indicator. Front panel detail Link/Act TYCON POWER SYSTEMS... - Page 4 Blinking This port is transmitting to, or receiving @43ms package from another device at 100Mbps. Blinking This port is transmitting to, or receiving @120ms package from another device at 10Mbps. No device is detected. TYCON POWER SYSTEMS...
-
Page 5: Power Wiring
The PoE ports will deliver output of DC over the spare pairs of the RJ45 connection: * TX on lines 1 and 2 * RX on lines 3 and 6 * V+ on line 4 and 5 * V- on line 7 and 8 TYCON POWER SYSTEMS... -
Page 6: Ethernet Port Wiring
(pair 4,5 and pair7,8) to the PD. The following tables depict the wiring diagram of straight-through and crossover cabling. The crossover cables simply cross-connect the transmit lines at each end to the receive lines at the opposite end. TYCON POWER SYSTEMS... - Page 7 If a port LED is off, go back and check for connectivity problems between that port and the network device it is connected to. The maximum cable length for 10/100BaseT with Cat5 twisted pair cables is typically 100 meters (328 ft.). TYCON POWER SYSTEMS...
-
Page 8: Pd Port Wiring
3. Technical Specifications Standards IEEE802.3/IEEE802.3u standards(10 base-T/100base-T) Ports 5 ports with 4 PoE(PSE), supports auto-crossover & auto-polarity Transmission speed 100 Mbps(100base-T),10 Mbps(10base-T) Auto-negotiation Switch technology store-and-forward Protocols CSMA/CD TYCON POWER SYSTEMS... - Page 9 *Link/Activity (Green ON/ Green Blinking every 43ms @100Mbps/ Green Blinking every 120ms @10Mbps) *PoE(Yellow) On-PoE output *POWER Green-normal, Red-alarm Power input DC(10V~57V). Power consumption less than 5W when without PD loading Input Voltage Input Current 0.032A 0.022A 0.019A 0.019A TYCON POWER SYSTEMS...
- Page 10 User’s Manual TYCON TP-SSW5(-NC) Operating temperature -40℃~ 85℃ Operation humidity 90% relative humidity, non-condensing Storage temperature -55℃~+105℃ Dimension 40mm(H)x116mm(W)x90mm(D) (main body) TYCON POWER SYSTEMS...
