Tycon Power Systems TP-SW5GNC-OUT Quick Install Manual

Outdoor poe switch

Wireless Base Stations

▫

Surveillance Systems

▫

Sensor Arrays

▫

Congratulations! on your purchase of the TP-SWxxNC-OUT

outdoor POE switches. Please take a moment to review this

Qwik Install Guide before assembly.

Recommended Tools: Phillips Screwdriver, 10mm wrench

TP-SWxxNC-OUT

Outdoor POE Switch

Table of Contents

Need help?

Do you have a question about the TP-SW5GNC-OUT and is the answer not in the manual?

Page 1 TP-SWxxNC-OUT Outdoor POE Switch Wireless Base Stations ▫ Surveillance Systems ▫ Sensor Arrays ▫ Congratulations! on your purchase of the TP-SWxxNC-OUT outdoor POE switches. Please take a moment to review this Qwik Install Guide before assembly. Recommended Tools: Phillips Screwdriver, 10mm wrench...
Page 2 Qwik Install STEP 1: Install the POE switch into the housing leaving adequate room for CAT5 cables. Velcro strips have been included for easy and secure installation of the POE switch into the housing. STEP 2: Install the switch housing to a pole using the included U-bolts or your supplied hose clamps.
Page 3: Specifications
Specifications TP—SW5GNC-OUT TP-SW8NC-OUT Operating Voltage 12 to 57 VDC POE Port Current 2A Max POE Ports 1 Uplink, 4 POE Out 1 Uplink, 7POE Out Wire Terminal Input 10A Max Current Transmission Speed 1000/100/10mb 100/10mb Self Consumption Pow- <3W <1.5W -20 to +75°C (-4 to -40 to +85°C (-40 to Operating Temperature...
Page 4: Limited Warranty
POE Powered Installation TO 110/220VAC TO LAN TO Uplink Port of POE Switch Limited Warranty The TP-SWxxNC-OUT products are supplied with a limited 24 month warranty which covers material and workmanship defects. This warran- ty does not cover the following: ▫...

Tp-sw8nc-out
