Cadet Perfectoe UC072 Owner's Manual

Hide thumbs Also See for Perfectoe UC072:

Advertisement

Available languages

Available languages

Table of Contents

Benefits You Can Depend On
• Slim design with space saving comfort for:
Toekick areas in your kitchen and bath cabinets
Recreational vehicles
Stairwells
Fireplace Hearths
• Safe for you and your family
Peace of mind with automatic high
temperature shutoff feature
• Common sense components designed with you
in mind
1. NO sharp edges
2. Corrosion resistant
3. Rugged, reliable element for instant warmth
4. Easy to install
• Your Cadet heater has been thoroughly tested
and is guaranteed with a 2 year extended
warranty
Wall Can Top
14½"
36.83
Grill Side
Grill Front
.375"
.952
45.7
cadetheat.com
8¼"
21
Wall Can Side
3½"
8.9
18"
SAVE THESE INSTRUCTIONS
Tel: 360-693-2505
http://www.cadetheat.com/wall-heaters/perfectoe
Line
Voltage
240
(2)
120
(1) Standard built-in thermostat is single pole and has no "OFF" position.
(2) 240 volt models can be used at 208 volts. Wattage equals 75% of 240v rated
wattage.
(3) For installations above 7000 feet, highest wattage recommended is 750 watts.
Note: Optional built-in thermostat kits sold separately
Perfectoe Models With Thermostat
*Wall Thermostat Not Required
Perfectoe Models Without Thermostat
*Wall Thermostat Required
8¼"
21
TOOLS REQUIRED:
• Phillips Screwdriver
• Straight Screwdriver
• Wire Strippers
PO Box 1675 Vancouver, WA
Perfectoe Heater
Owner's Manual
Perfectoe Models
Model w/
Model w/o
Thermostat
Thermostat
(1)
UC072
UC102
(3)
UC051
UC101
(3)
UC101T
(3)
Reset Button
Grill Front
17"
43.18
Built-in Thermostat
Grill Front
17"
43.18
• Utility Knife
• (4) 1 1/2" Wood Screws
• Insulated Wire Connectors
• (1) Strain Relief Connector
98668-1675
Watts
Amps
750
3.13
1000
4.17
500
4.17
1000
8.33
3½"
8.89
Rating Label
3½"
8.89
Page 1
