Benefits You Can Depend On
• Energy efficient: use up to 30% less energy
• Brings you only the heat you need, when you need
it, and adjusts automatically to save you money
• You define your comfort—maintains your room
temperature within one degree
• Our most thoughtful design features:
Large digital display shows your room temperature
and heating mode
Easy, intuitive one-touch controls
Night/Away and Max/Min options for extra savings
and safety
Improve air circulation and add comfort in off-sea-
son with three fan-only speeds
Easily replaces many Com-Pak Series heaters:
C, CB, CM, CS or X
• Eliminate guesswork with smart power supply
sensor that self adjusts to your voltage
• Automatic high temperature safety shutoff
• Your Energy Plus heater has been thoroughly tested
and is guaranteed with a limited 5-year warranty
COM-PAK
TOOLS REQUIRED:
• Phillips Screwdriver
• Straight Screwdriver
• Wire Strippers
cadetheat.com
• Utility Knife
• (4) 1½" Wood Screws
• (2) Insulated Wire Connectors
• (1) Strain Relief Connector
SAVE THESE INSTRUCTIONS
Tel: 855.CADET.US
Energy Plus Heater
Owner's Guide
Energy Plus Models
Line
Voltage
120
208
240
240 only
208 only
120
208
240
Energy Plus Model With Built-In
Controller
Wall Thermostat Not Required
Rating Label
Controller with Digital Display
and Push Buttons
Side
Grill Front
73
/
"
9"
5
8
1.6 cm
22.9 cm
Wall Can Bottom
7
/
"
7
8
20 cm
3"
7.6 cm
1¾"
4.5 cm
PO Box 1675 Vancouver, WA
Models
Watts
1000
CE163T
1500
1600
CE162T
1600
CE168T
1600
500
CE083T
750
800
072xxx
73
Wall Can Side
11
/
"
12"
1
8
28.3 cm
30.5 cm
3¼"
8.3 cm
4"
10.2 cm
1¼"
3.2 cm
tested to UL standards
98668-1675
Amps
8.3
7.2
6.7
6.7
7.7
4.2
3.6
3.3
10"
25.4cm
1¼"
3.2 cm
Page 1
