OWNER'S GUIDE
B
ASEBOARD
SENSIBLE, QUIET HEAT STARTS HERE
For how-to videos or more information, please visit:
http://cadetheat.com/install/bb
ESPAÑOL ver la guía del propietario en
Thank you for your purchase! Question or problem? Let us solve it with a
single phone call, email or online chat! We'll save you a trip back to the store!
Cadet Customer Service
855.CADET.US (855.223.3887)
Phone:
email:
customerservice@cadetheat.com
Live chat: cadetheat.com (contact us)
cadetheat.com
855.CADET.US
Vancouver, Washington
cadetheat.com/espanol/bb
tested to UL standards

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BASEBOARD and is the answer not in the manual?

Questions and answers

Related Manuals for Cadet BASEBOARD

Summary of Contents for Cadet BASEBOARD

  • Page 1 ESPAÑOL ver la guía del propietario en cadetheat.com/espanol/bb Thank you for your purchase! Question or problem? Let us solve it with a single phone call, email or online chat! We’ll save you a trip back to the store! Cadet Customer Service 855.CADET.US (855.223.3887) Phone: email: customerservice@cadetheat.com...

  • Page 2: Important Instructions

    IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read all instructions before install- 5. Do not insert or allow foreign objects ing or using this heater.

  • Page 3: Installation Instructions

    Locate or route electrical supply wires STEP 1 • For best results, install your baseboard heater under a window, along an outside wall, or as close as possible to an outside door. • Install only in a horizontal position, not in a vertical position.
  • Page 4 • All baseboard heaters require three supply wires. For 120 volt baseboard wiring you will have 1 hot, 1 neutral and 1 ground. For 240 and 208 volt baseboard wiring you will have 2 hots and 1 ground; no neutral needed.
  • Page 5 8F2025 ONLY - CHANGING WATTAGE All model 8F2025 model baseboard heaters are factory set for 2500 watts. If you want to change to 2000 watts, follow the diagrams in Figure 9b or 10b, depending on which side you’re wiring. If you do not want to change your baseboard heater’s wattage, proceed to STEP 4 Finish installation.

  • Page 6: Warranty

    #1. C. For baseboard #1, connect each of the cut baseboard wires to one of the supply wires going to the thermostat, and one of the supply wires going to the other baseboard. They both must have a 3-wire connection.

  • Page 7: Troubleshooting

    If you have an electronic thermostat, follow the instructions in the programming and operating guide included with your thermostat. High-temperature safety shutoff All baseboard heaters come with a built-in high-temperature safety shutoff that stops electricity flow- ing to the heater if it gets too hot inside. This automatically resets after cooling. Reduce-Reuse-Recycle This product is made primarily of recyclable materials.

  • Page 8: Maintaining Your Heater

    8F2025 8F2025 INTERNAL HEATER WIRING DIAGRAMS 8F2025 ONLY Connected to Left Connected to Left 8F2025 Connected to Right Wired on the left side 8F2025 Connected to Right Wired on the right side ©2017 Cadet Printed in USA Rev 08/03/17 #720001...
