Consumables and Replacement Cycle

The following table shows the consumables and their standard replacement cycle.
Consumables
ADF Friction Roller Assembly
P/N 002-5966A-0-SP
ADF Pick-Up Roller Assembly
P/N 002-5949A-0-SP
Print Cartridge (Black Ink)
P/N 008-0236A-09-SP
Attract Ink box Assembly
002-5944A-0-SP
The replacement cycles above are rough guidelines for the case using A4/Letter
sized woodfree or wood containing paper of 80 g/m
vary according to the type of paper used and how frequently the product is used
and cleaned. Please replenish the consumables from the store where you purchased
the product or a Avision authorized service provider.

Replacing the ADF Friction Roller Assembly

1. Pull the ADF Handle and open the ADF cover with a light force.
Standard Replacement Cycle
100,000 sheets
200,000 sheets
Over 7 million characters (economical,
non-stop printing)
or 6 months after the package is opened
2 years
ADF Handle
114
2
(20 lbs) in weight. These cycles
ADF Cover
