The Connection Ports
Main Power Switch
The main power
switch of the
product.
To turn on the
product, press 「ｌ」.
Power Receptacle
Plug the power cord.
PS/2 Mouse Port
Connect the product
to an additional
mouse (PS/2) if
required.
COM Ports
Connect the product
to an external
keyboard.
Keyboard Port
Connect the product
to an additional PS 2
keyboard if required.
4
LAN Port
Connect the product
to network with a
LAN cable.
Audio Ports (x6)
Connect the product
to audio devices.
USB Port (x4)
Connect the product
to USB devices..
Monitor Port
Connect the product
to an external
monitor if required.
