Compliant Manager
<Connections to External Equipment>
Input/
Designation Output
item
Alarm output
Run output
Non-voltage "A"
contacts
Status
Static
output
(Relay output)
Allowable contact
voltage/current 30
VDC, 0.3 A
All stop input
Digital
All start input
input/output
Fire alarm input
terminals
Voltage-applied
"A" contacts
All stop:
Control
All start:
input
Fire alarm: Static
(Photocoupler
input)
* Select non-
<Specifications for Wiring>
Use the following materials to connect signal lines and power lines (procured on site)
No Line
1 For TCC-LINK
2 For RS-485
3 For Power
For Digital Input/Output
4
connection
Compliant Manager side
Input/output
Terminal name
conditions
+12V
Pulse or static
Pulse or static
voltage contacts
that allow minute
current (12V,
1mA)
COM
Type
Wire size
Length
Type
Wire size
Length
Type
Wire size
Length
Type
Wire size
Length
Demarcation
terminal
0.4 to 1.2 Ø
Alarm
Run
Output common
0.4 to 1.2 Ø
All stop (+)
All start (+)
Fire alarm (+)
Input
common (–)
Description
1.25mm², 1000m max. (total length including
2.00mm², 2000m max. air conditioner area)
1.25mm², 500m max. (total length)
H07 RN-F or 245IEC66
– 7 –
Installation Manual
External equipment side
Example of Input/output
circuit
Digital
input
Wiring length:
100 m or less
(Pulse or static)
Pulse width:
(Pulse or static)
300 ms or more
Wiring length:
100 m or less
(Static)
2-wire sheld cord
2-wire sheld cord
0.75mm², 50m max.
2-wire cord
0.3mm², 100m max.
conditions
6-EN
