Compliant Manager
• When a zone is selected, group numbers registered in the zone are displayed.
• Groups whose numbers are displayed are already registered.
• Even when addresses have been registered, the registration can be cancelled with the
(4) Select the unit to be registered in the group selected in step (3).
• Switch refrigeration system No.1 to 31 with the
button.
• When no system exists, indoor unit number is displayed as "- -".
• System number 31 is for a local adapter and heat exchange ventilators. An indoor unit number is always
displayed regardless of whether the unit exists or not.
(5) Press the button to register the setting or press the
(6) To continue registration, repeat steps (3) to (5).
(7) Press the button to terminate the address setting.
C Automatic setting
Set central control addresses automatically from the Compliant Manager.
(Central control addresses are set automatically in ascending order of unit number.)
(1) Press the button and ZONE
(CODE No. C1 flashes.)
(2) Press the SET TEMP.
(3) Press the button. (Central control addresses are automatically registered. This registration requires several
minutes. lights during this address setting.)
(4) goes out and the indication of C2 flashes, which shows completion of the automatic address
registration.
(5) Press the button to exit the address setting mode.
<Checking duplicate central control address>
NOTE
This function is not available for custom air conditioners.
For details, refer to the manual of the TCC-LINK adapter.
(1) Press the button and ZONE
(CODE No. C1 flashes.)
(2) Press the SET TEMP.
(3) Press the button to start checking a duplicate central control address error. (
check.)
(4) When goes out, the check has been completed.
* When nothing appears in the group number display area at the end of checking, no duplicate address error
has been detected.
* When a group number in the group number display area flashes at the end of checking, a duplicate address
error has been detected.
(Correct the duplicate address.)
button simultaneously for at least 4 seconds.
or button to change the CODE No. to C2.
button simultaneously for at least 4 seconds.
or button to change the CODE No. C3.
– 15 –
button, and then switch indoor unit No.1 to 64 with the
button to cancel the setting.
Installation Manual
button.
lights during this
14-EN
