Compliant Manager
10

TEST RUN

<Conducting a Test Run for the Compliant Manager>
• A test run is necessary to confirm that the Compliant Manager has recognized air conditioner units after the
central control address setting.
(1) Turn on the power of all connected air conditioners.
(2) Turn on the power of the Compliant Manager.
(3) Make sure that the number of air conditioners connected to each line (only main units when group control is
performed) equals the group number count displayed on the Compliant Manager.
(4) When these numbers are identical, there is no problem.
If they differ, set central control addresses again according to "Central Control Address (Group Number)
Setting." Also make sure that there is no incorrect wiring.
<Conducting a Test Run for Air Conditioners>
(1) Press the button for at least 4 seconds. (The "TEST" indication lights in the test run mode.)
(2) Press the button and
(3) When the test run is completed, press the
11

SPECIFICATIONS

Model
Power supply
Power consumption
Number of connectable indoor units (TCC-LINK)
Energy Monitoring Relay Interface (RS-485)
Digital Input/Output Relay Interface
Operating temperature
Dimensions
Mass
Weight
button. (Temperature cannot be set during a test run.)
button to exit the test run mode.
– 21 –
BMS-CM1280TLE
220-240 VAC 50/60Hz
3W
128 Units (LINE1 64 Units, LINE2 64 Units)
4 Units (max.)
4 Units (max.)
0 to 40°C to 90%RH
-20 to +60°C (no condensation)
120 (H) × 180 (W) × 88 (D)
1.1Kg
Installation Manual
BMS-CM1280FTLE
5W
1.2Kg
20-EN
