Interface
Set-up
allows you
to set
your
printer
interface
parameters.
Defines I/O Interface
Functions
Possible Values
n= Test, ANSI X3.64,
Mode:
Epson*, Bar Codes,
Proprinter, LA-120, TTY,
Printek, Barberpole, or
Hex Dump
I/O:
Parallel*, Serial, CX/TX or
IPDS
Baud Rate:
150, 300, 600, 1200, 2400,
4800, 9600*, or 19200
Data Bits:
7 or 8*
Parity:
None*, Ignore, Odd or
Even
Busy:
Low* or High
DTR:
Power*, Online, or Busy
XON/XOFF:
Off* or On
ETX/ACK:
Off* or On
Auto CR:
Off* or On
Auto LF:
Off* or On
Long Line:
Wrap* or Trunk
Left Edge:
Fixed or Float*
FF at TOF:
Yes* or No
Scroll Delay:
0, 1*, 2 through 15
Fault:
Break Pg*, Reprint Pg,
Finish Pg
Page Size:
256* or 512 through
28160
Chars:
Control* or Printable
INTERFACE
Description
Selects current emulation mode, barbermode, or
hex dump mode (Test mode for factory use only) .
Selects active I/O port. If CX/TX interface is
(CX/TX & IPDS optional) installed, CX/TX also
selects Parallel port (Not available when RS-422 or IPDS
interface is installed) .
Selects baud rate for serial interface (Not
available when Parallel, CX/TX or IPDS is selected) .
Selects number of data bits in Serial character
frame and the number of significant data bits
in each character received via all other interfaces.
Selects parity checking requirements for Serial
data bits (Not available when Parallel,
CX/TX, or IPDS is selected).
Selects polarity of busy signal (pin 11 of RS-
232C interface). Available only when RS-232C
interface is installed and Serial is selected.
Selects condition reflected by DTR signal (pin 20
of RS-232C interface). Available only when RS-
232C interface is installed and Serial is selected.
Enables or disables transmission of XON and XOFF
characters from printer to host to control data
flow to printer (Not available when Parallel, CX/TX
or IPDS is selected).
Enables or disables ACK response to receipt of
ETX character (Not available when Parallel, CX/TX
or IPDS is selected).
Enables or disables automatic Carriage Returns
(CR) when a Line Feed (LF), Vertical Tab (VT), or
Form Feed (FF) is received.
Enables or disables automatic Line Feed (LF)
when a Carriage Return (CR) is received.
Sets whether characters beyond right margin
are wrapped to next line or truncated.
Sets whether left edge of line is printed 1/2" from
detected paper edge or is fixed at "0" on ruler.
Sets whether Form Feed (FF) occurs when
received from host computer if paper is already
positioned at top of form (TOF).
Sets number of seconds to delay before
scrolling top of form to tear bar when printer
is idle and form boundary has been reached.
Selects whether a paper-out condition causes
Page Break or allows you to reprint page.
Sets page size in characters, when Page Reprint
is selected. When you don't use Page Reprint,
leave value set to 256.
Selects whether certain control character
symbols are printed (emulation dependent) or
are treated as control characters.
*Factory Default Setting
3
