- Page 1 INSTRUCTIONS FOR INSTALLATION AND OPERATION SPIRIT Please retain this document carefully DRU VERWARMING B.V. HOLLAND 957.560.01...
- Page 2 38c-1012...
-
Page 3: Table Of Contents
• This appliance has been manufactured and tested by DRU verwarming BV of The Netherlands with utmost care. • Subject to the conditions set out on this card DRU guarantees the proper operation of this vented room heater to the original purchaser for a period of one year after date of purchase. -
Page 4: Foreword
• B.S. 6461 Part 1 installation of chimneys and flues Dear Customer, No additional ventilation is required for this appliance. We would like to thank you for buying this DRU product. Our products have been designed and produced to meet Positioning the fire... -
Page 5: Installation The Fire
The securing screws should then be tightened to lock the cover in positon. • Replace the burner plate. • Replace the tray for vermiculite. 38c-1015 cable holes Spirit... -
Page 6: Checking For Clearance Of Combustion Products
INSTRUCTIONS FOR INSTALLATION Checking for clearance of combustion Connecting the receiver products The remote control system comprises a receiver and a • Close all doors and windows in the room. remote control, packed together in one box. The receiver • Light the fire and allow to run for approximately must be connected to the appliance. -
Page 7: Operating Instructions
A to the small flame. The gas supply to the main burner will then be turned off. Switching off Turn button A to the "0" setting.The gas supply to the burners will then turned off. Spirit... -
Page 8: Installing The Fascia
INSTRUCTIONS FOR INSTALLATION INSTALLING THE FASCIA • Replace the fitting screws • Fit the flap as shown in fig. 12, screwing the two screws in the side of the flap into the bottom holes of the black • Unpack the Fascia frame. -
Page 9: General Notes
GENERAL NOTES GENERAL NOTES Use candles and oil lamps as little as possible, keeping the wick as short as possible.While they enhance the atmosphere, candles and oil lamps also cause the Flue-gas protection formation of large quantities of unhealthy soot particles in An insufficient air supply or a malfunctioning chimney duct your home. -
Page 10: Disposal
GENERAL NOTES Disposal When replacing or otherwise removing the appliance, it should be disposed of in compliance with current regula- tions. Shut off the connecting tap with coupling before com- mencing disassembly. Undo the coupling between the con- necting tap and the appliance.The whole appliance can now be disassembled and removed. -
Page 11: Installation Of The Coal
Installation of the coal Spirit... -
Page 12: Installation Of The Twigs
Installation of the twigs When installing twigs in the heater for gas G20 you have to change the flame control. • Remove the tray for vermiculite 9 10 11 • Remove the burner by remving the screw A 38c-1017 • Change the flame control for the one with the little holes Ø... - Page 13 Spirit...
-
Page 14: Installation Of The Pebbels/Driftwood
Installation of the pebbels /driftwood... - Page 15 Spirit...
-
Page 16: Conversion Instruction
CONVERSION INSTRUCTIONS The conversion must be carried out by a qualified fitter. Before commencing the conversion: 1. Close off the gas supply 2. Disconnect the gas supply Remove the tray for vermiculite Replacing the components 1 Remove the burner by removing the screw (A) Fig. -
Page 17: Technical Data
Burner pressure Mbar Nom. Load (Hs) 5.85 Nom. Load (Hi) Nom. Output Consumption on full output 468 gr/h Consumption on low output Burner injector mm Ø 2.30 1.40 Colour oxypilot kode blank black Low setting injector mm Ø 1.30 1.10 Spirit... - Page 19 Spirit...
