Power Supply Type
The choices: AT, ATX.
ACPI Function
The ACPI standard (Advanced Configuration and Power Interface) allows the operat-
ing system to directly check the functions of energy saving and the PnP (Plug and
Play) functionality. The ACPI functions are normally activated by the BIOS. The
choices are: Enabled and Disabled.
Power Management
This category allows you to select the type (or degree) of power saving and is directly
related to the following modes: HDD Power Down, Doze Mode and Suspend Mode
Min. Saving: Minimum power management
Max Saving: Maximum power management
User Define: Allows you to set each mode individually
Video Off Method
This determines the manner in which the monitor is blanked. There are three choices:
1. V/H SYNC+Blank: This selection will cause the system to turn off the vertical and
horizontal synchronization port and write blanks to the video buffer.
2. Blank Screen: This option only writes blanks to the video buffer.
3. DPMS Support: Select this option if your monitor supports the Display Power
Management signaling (DPMS) standard of the Video Electronics Standard to
select video power management values.
Video Off In Suspend
This determines the manner in which the monitor is blanked. The choices: Yes, No.
Suspend Type
Select the Suspend Type.
The Choices: PwrON Suspend, Stop Grant.
MODEM Use IRQ
This determines the IRQ in which the MODEM can use.
The Choices: 3, 4, 5, 7, 9, 10, 11, NA.
44
