1.4 Checklist
After opening the package of the PEAK7220VL2G, please check and make sure
you have all of the following items:
One PEAK7220VL2G SBC
(A mechanical drawing of this model is shown below.)
One PEAK7220VL2G Quick Reference Guide
One 50CM Cable JST 2.5mm 3 pin to 3 pin (5V standby ATX Power-on
Cable)
One Y Cable for Keyboard and Mouse
One 180 mm AUX Power Cable (for J2)
One Cable Set (FDD x1, SIO+PIO x1, SIO x1/Keyboard x1/IDE66 x1)
One USB Cable with Bracket
One Driver Manual CD
Figure 1-2: Mechanical Drawing of PEAK7220VL2G
